Fluke Ti50FT-20 Datasheet

Ti50 and Ti55 IR FlexCam
Thermal Imagers
The professional's choice when
demanding the highest sensitivity
Choose the Fluke Ti5x models when you need the best images.
They feature 320 x 240 detectors with industry leading thermal
sensitivity (≤ 0.05 °C NETD) for high resolution, ultra high-
quality images. In addition, with a 60 Hz detector acquisition rate
temperatures are displayed live on the large 5-inch color display.
Features
High resolution, low noise VOx detector for high quality images
Temperature range to cover broad industrial applications
High thermal sensitivity for viewing even the smallest
temperature differences
180° articulating fl exible lens to view images in every situation
Choice of 3 interchangeable lenses to cover every application
Large 5" high contrast color LCD for a clear picture independent
of lighting conditions
Fully radiometric for detailed temperature analysis and tracking
SmartFocus for best image quality and accurate temperature
measurements
Windows CE based menu structure for ease of use
®
Personalized instrument set-up for multiple use
CompactFlash memory cards to store over 1000 IR images plus
fully radiometric temperature data
SmartView reporting and analysis software included
AutoCapture for making intermittent problems visible
On-board analysis functions
User defi ned text annotations for simplifi ed reporting
Built-in visible light (digital) camera
IR-Fusion blending thermal and visible light images to easily
pinpoint suspect components
IR/Visible Alarm function
Laser pointer for easy targeting
Flash and torch light for high quality images in dark
environments

Typical applications

•
Predictive maintenance – Identify electrical and mechanical problems before they cause
failure
•
Power/utilities – Real-time analysis of substations, transmission lines and equipment
•
Process monitoring – Real-time observation to ensure efficient and safe operation
•
Research and development – Quantify heat patterns to improve product designs
•
Electronic design – Close up circuit board analysis
Ti55FT Ti55 Ti50FT
320 x 240
-20 to +600 C -20 to +350
o
≤0.05 ≤0.07
o C
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ● ●
● ●
● ●
● ●
● ●
● ●
●
● ●
● ●
®
Ti50
C
o
o C
●
●
●
●
●
●
●
●
●
Printed circuit board
Power/utilities
Electrical system
