Fluke TiR32 Thermal Imager
Fluke TiR32 Thermal Imager (Work in Progress)
T
hermographic cameras
or infrared cameras are cameras that form an
image using
infrared radiation
military use and have slowly migrated into other fields as varied as
medicine and archeology. In the building industry it has different usages,
for example we can use thermal cameras to detect leakage or thermal
bridges. You can use the the facultys TiR32 Thermal imager to analyze
the thermal radiance of any building, object or even people. The picture on
the right shows an interior corner in infrared as well as the device itself.
There is also a general overview here of the things you need to
understand prior to using a thermal imager in order to understand the
results.
The data can be stored either as a JPG file or as an IS2 file, which is the
equivalent of a RAW format on modern dSLR cameras. While the first
enables you to make fast files for presentation purposes, the latter can be
accessed with the free SmartView software and explored, either you goal
is to extract temperatures in exact positions or you need a report from a
set of images.
Contents
Fluke TiR32 Thermal Imager (Work in Progress)
Pre-requisites, access and learning to use the Fluke
Health and Safety
Additional pages
Pre-requisites, access and learning to use the Fluke TiR32
Thermal Imager
The TiR32 is fairly easy to use, but it is not a toy (i.e. it is also not cheap).
You can borrow it as long as you are a responsible person and need the
device for your studies. In this case you should study this page carefully,
going through all the videos and when you come to pick up the device for
the first time, you need to answer some questions to ensure that you are
familiar with the device and also show that you know how to use it. After
you have shown that you can use the device, you will receive booking
access for it in the equipment booking system. If a group wants to borrow
the device, one person still needs to be responsible for the device.
Health and Safety
Batteries contain hazardous chemicals that can cause burns or
explode. If exposure to chemicals occurs, clean with water and
get medical aid.
. IR cameras were originally developed for

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TiR32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fluke TiR32

Summary of Contents for Fluke TiR32

  • Page 1: Table Of Contents

    Pre-requisites, access and learning to use the Fluke TiR32 Thermal Imager The TiR32 is fairly easy to use, but it is not a toy (i.e. it is also not cheap). You can borrow it as long as you are a responsible person and need the device for your studies.

  • Page 2: Tir32 Thermal Imager

    These objects pose a burn hazard. Use the product only as specified, or the protection supplied by the product can be compromised. TiR32 Thermal Imager IR image of an interior corner and window. General Information Infrared Photography...

  • Page 3: Thermographic Camera

    Thermal imagers used for preventive and predictive maintenance, equipment troubleshooting, repair verification, building inspections, restoration and remediation work, energy audits, and weatherization purposes. Fluke TiR32, is a thermal camera which is optimized for building envelope inspections and building diagnostics.

  • Page 4: Uncooled Infrared Camera

    Uncooled infrared camera There are two types of infrared camera, cooled and uncooled. Fluke TiR32 is the uncooled camera. This kind of camera use a sensor which is operating at normal temperature, or a sensor stabilized at a temperature close to ambient using small temperature control elements. All of the...

  • Page 5: Fluke Tir32 And Operation

    Fluke TiR32 and operation Infrared energy (temperature) images can be taken with fluke thermal imager. This device is able to amalgamate observable light with the energy of infrared images on the same screen. The process of discovering temperature changes (heat patterns) in articles is called thermography or thermal imaging.

  • Page 6: Using Camera

    Using Camera Open the front Lens Cover Press F2 and hold it for a second to turn it on Wait up to camera calibrating By three softkeys F1, F2 and F3 provide access for thermal image display, saving and viewing stored images, and setting features Press Green button (Image Capture Trigger) for taking image You can change the focus by Focus Control Ring...

  • Page 7: File Format

    4. To capture an image, squeeze and release the trigger once. File Format Fluke TiR32 can display, blend and store a full visual image (640 X 480) with each IR image. Thermal and visual images can be presented simultaneously as a full thermal image or as a Picture-In-Picture (PIP) image in various blend modes which was explained before in IR-fusion technology.

  • Page 8: Making Accurate Temperature Measurements

    1. Press the softkey labeled Table 2. Press the softkey labeled Down to move between the materials in the list. The emissivity value for each material is shown on the screen as the selection moves between the different materials 3. Press the softkey labeled Done to select the highlighted material.
  • Page 9 Fluke website http://www.fluke.com/fluke/usen/Support /Software/ti-update.htm and after registration you can download and follow the download instructions. Specification Windows ® XP SP2/Vista/7 A web browser for product registration and web updates. Internet Explorer 8.0 or newer 512 MB of RAM minimum (1 GB for Vista or 7)

  • Page 10: Starting Smartview

    Rotate images and videos Extensive annotation possibilities Add annotations to images in the camera or in the PC software Review IR PhotoNotes™ Input information such as locations, problem description, recommended actions, and other notes Reference images can be linked together for good/bad and before /after analysis Annotations can be automatically included in reports Review voice annotations captured in the field by the imager...

  • Page 11: Setting Preferences

    References "Fluke IR-Fusion® Technology." Fluke IR Fusion Infrared Thermal Imaging Technology for Image Analysis . N.p., n.d. Web.
