- Page 1 Airborne Particle Counter Getting Started PN 4136462 March 2012 © 2012 Fluke Corporation. All rights reserved. Printed in U.S.A. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period is one year and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days. This warranty extends only to the original buyer or end-user customer of a Fluke authorized reseller, and does not apply to fuses, disposable batteries, or to any product which, in Fluke's opinion, has been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions of operation or handling.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ........................1 How to Contact Fluke .....................1 Safety Information ......................2 Battery..........................3 Product Overview......................3 The Buttons .......................5 Product Connections ....................6 Charge Base Connections..................7 Product Test ......................8 How to Purge the Product Sensor ................8 How to Take a Sample ....................8 Navigation Menu......................9... - Page 4 Getting Started Maintenance ........................11 Specifications ........................ 12 General ........................12 Environmental ......................13...
-
Page 5: Introduction
Use the supplied USB cable, an Ethernet connection, or a Canada: 1-800-36-FLUKE (1-800-363-5853) flash USB drive (not supplied) to download data to a PC. Europe: +31 402-675-200 See the 985 Users Manual on the Product CD for Japan: +81-3-6714-3114 complete use instructions. Singapore: +65-6799-5566 Anywhere in the world: +1-425-446-5500 Or, visit Fluke's website at www.fluke.com. -
Page 6: Safety Information
Use the Product only as specified or Do not dispose of this product as unsorted municipal waste. Go to Fluke’s hazardous laser radiation exposure can website for recycling information. occur. Do not open the Product. The laser beam Conforms to European Union directives. -
Page 7: Battery
Airborne Particle Counter Battery An amber light on the front of the Charge Base shows Battery that the base is powered. The light changes to green After you unpack and examine the Product, fully charge when the Product is connected to the base. the battery before the first use. - Page 8 Getting Started gud003.eps Figure 1. Product Components...
-
Page 9: The Buttons
International Power Plug Adapters Communication Setup also have submenus. 985 Getting Started Enter/Select- Push to select a menu 985 User Manual CD option. Also use to start and stop a Product Carrying Case sample when in the Sample Screen. -
Page 10: Product Connections
Getting Started Product Connections Power and data connections are on the bottom of the Product and on the rear of the Charge Base. The Ethernet connection is only available on the base. Table 4 and Figure 2 show you the Product connections. Table 4. -
Page 11: Charge Base Connections
Airborne Particle Counter Product Overview Charge Base Connections Power and data connections are also on the rear of the Charge Base. The Ethernet connection is only available on the base. Table 5 and Figure 3 show you these connections. " 1.2A Table 5. -
Page 12: Product Test
Getting Started Product Test How to Purge the Product Sensor Electrical noise, sensor leakage, or other interference can Particles must be purged (removed) from the Product cause the Product to give incorrect data. sensor before use in a clean room or clean environment, and after each high-sampling count. -
Page 13: Navigation Menu
Airborne Particle Counter Product Overview Navigation Menu Sample Setup Submenus The navigation menu lets you move through the five The Sample Setup Menu includes three submenus. different sections of the Product software. To go to the Submenu icons are shown in Table 7 and the subsequent Navigation menu, push . -
Page 14: Communication Setup Submenus
Getting Started Communication Setup Submenus Sample Screen Menu The Communication Setup Menu includes two submenus. The sample screen is the default screen that shows after Submenu icons are shown in Table 8 and the subsequent the Product is turned-on. The screen shows the current sections tell you about these submenus. -
Page 15: Maintenance
Airborne Particle Counter Maintenance For safe operation and maintenance of the Maintenance product: XWWarning Repair the Product before use if the To prevent possible electrical shock, fire, or battery leaks. personal injury: Connect the battery charger to the mains Have an approved technician repair the power outlet before the Product. -
Page 16: Specifications
Getting Started Specifications General Particle-Size Range ........(0.3, 0.5, 1.0, 2.0, 5.0, 10.0) µm Channels ............6 Flow Rate ............0.1 cfm (2.83 L/min) Light Source ..........775 nm to 795 nm, 90 mW class 3B laser Calibration ............. PSL particles in air (NIST Traceable) Counting Efficiency ........ -
Page 17: Environmental
Airborne Particle Counter Specifications Weight ............680.39 g (1.5 lb) Environmental IP Rating ............40 Operating Humidity........<95 % RH non-condensing Protection Class ..........Pollution Degree 2 Operating Temperature ......... 10 °C to 40 °C (50 °F to 104 °F) Operating Altitude.......... - Page 18 Getting Started...
