TP-Link TL-ANT2415D Specifications

2.4Hz 15dBi Outdoor
Omni-directional Antenna
TL-ANT2415D
Features：
15dBi Omni-directional operation highly enlarges the
wireless coverage
N female connector, compatible with most of the
wireless equipments
Weather proof design, suitable for all weather condition
Provided mounting kits enable easy installation for
various environments
Description：
TL-ANT2415D operates in the 2.4-2.5 GHz band and provides 15dBi Omni-directional operation, which largely
extends the wireless range and delivers much better wireless performance. The antenna o ers the N female
connector guaranteeing wider compatibility with most of the wireless equipments. Also, the weather proof
design ensures that it can work normally for various demanding outdoor solutions.

Radiation Patterns:

H-Plane Co-Polarization Pattern
2450MHz
90
5
135
-5
-15
-25
-35 -25 -15 -5 5
180
225
270
V-Plane Co-Polarization Pattern
2450MHz
45 135
0 180
315 225
90
5
45
-5
-15
-25
-35 -25 -15 -5 5
0
315
270
