C5.
MOUNT THE MICROWAVE
OVEN (cont.)
5 Insert 2 self-aligning screws
through outer top cabinet
holes. Turn two full turns on
each screw.
7
Tighten the outer two screws to the top of the
microwave oven. (While tightening screws, hold
the microwave oven in place against the wall and
the top cabinet.)
8
Install grease filter. See the Owner's Manual
packed with the microwave.
Installation Instructions
6
Tighten center
screw completely.
22
C6.
INSTALLING THE
CHARCOAL FILTER
1 On 1400 and 1600 Series models, remove screws
on front of grille using a #1 Phillips screwdriver.
On 1800 Series models, remove screws on top
front of grille using a #2 Phillips screwdriver.
2 Open the door.
3 Remove the grille.
On 1400 and 1600 Series models, pull the grille
straight off.
On 1800 Series models, slide the grille to the left
and pull it straight off.
4
Install the charcoal filter. When properly installed,
the wire mesh of the filter should be visible from
the front.
5
Replace the grille and the screws.
6 Close the door.
Insert mesh-side up
Charcoal
Filter
