Weber Vieluxe Slide-In Dual Burner Station Owner's Manual

Weber Vieluxe Slide-In Dual Burner Station Owner's Manual

Natural gas dual burner station
Hide thumbs Also See for Vieluxe Slide-In Dual Burner Station:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Installation Manual
Natural Gas Dual Burner Station Owner's Guide
Vieluxe
®
Slide-In Dual Burner Station
(Model #: 36152)
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
Leaking gas may cause a fire or
explosion which can cause serious bodily
injury or death, or damage to property.
WARNING: Do not store or use gasoline
or other flammable liquids or vapors
within 25 feet (8m) of this appliance.
Y
OU MUST READ THIS
O
'
G
WNER
S
UIDE BEFORE OPERATING YOUR BURNER STATION
Vieluxe
®
Countertop Dual Burner Station
(Model #: 37152)
WARNING: Follow all leak-check
procedures carefully in this manual
prior to burner station operation. Do
this even if burner station was
dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
61318 0204

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vieluxe Slide-In Dual Burner Station and is the answer not in the manual?

Questions and answers

Related Manuals for Weber Vieluxe Slide-In Dual Burner Station

Summary of Contents for Weber Vieluxe Slide-In Dual Burner Station

  • Page 1 Natural Gas Dual Burner Station Owner’s Guide Vieluxe ® Slide-In Dual Burner Station Vieluxe ® Countertop Dual Burner Station (Model #: 36152) (Model #: 37152) WARNING: Follow all leak-check DANGER procedures carefully in this manual If you smell gas: prior to burner station operation. Do 1.
  • Page 2 DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. WARNINGS Do not store a spare or disconnected liquid propane cylinder under or near this burner station. Improper assembly may be dangerous.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS WARRANTY GENERAL INSTRUCTIONS STORAGE OPERATING GAS SUPPLY TESTING CLEANING LIGHTING THE LEFT & RIGHT BURNERS TO EXTINGUISH MANUALLY LIGHTING THE LEFT & RIGHT BURNERS TO EXTINGUISH GENERAL MAINTENANCE CHECK FOR GAS LEAKS REMOVE CONTROL PANEL REINSTALL CONTROL PANEL REINSTALL BURNER CONTROL KNOBS &...

  • Page 4: Warranty

    Customer Service Toll Free at 1-866-VIELUXE If Weber-Stephen confirms the defect and approves the claim, Weber-Stephen will elect to replace such parts without charge. If you are required to return defective parts, transportation charges must be prepaid. Weber-Stephen ®...

  • Page 5: General Instructions

    GENERAL INSTRUCTIONS • Not for use by children. • If there are local codes that apply to gas grills, you will have to conform to them. If there are no local codes, you must conform to the latest edition of the National Fuel Gas Code: ANSI Z 223.1/NFPA 54. •...

  • Page 6: Lighting The Left & Right Burners

    LIGHTING THE LEFT & RIGHT BURNERS Summary lighting instructions are located on the inside of the burner station lid. DANGER: Both burner valves must be in the OFF position before turning on the gas supply. If the valves are not in the OFF position, gas will flow to the burners. This condition can cause a fire or explosion resulting in serious bodily injury or death.

  • Page 7: Manually Lighting The Left & Right Burners

    MANUALLY LIGHTING THE LEFT & RIGHT BURNERS Summary lighting instructions are located on the inside of the burner station lid. DANGER: Both burners valves must be in the OFF position before turning on gas supply. If the valves are not in the OFF position, gas will flow to the burners. This condition can cause a fire or explosion resulting in serious bodily injury or death.

  • Page 8: General Maintenance

    GENERAL MAINTENANCE Check for gas leaks WARNING The gas connections of your Vieluxe ® burner station have been factory tested. We do however recommend that you leak check all gas connections before operating your Vieluxe ® burner station. Remove control panel Tool required: Screwdriver Remove the burner control knobs (1).
  • Page 9 GENERAL MAINTENANCE Completely remove the control panel from the cooking box assembly exposing the valves, burners, igniters, and manifold. Countertop Burner Station Slide-In Burner Station DANGER Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for leaks.

  • Page 10: Reinstall Control Panel

    GENERAL MAINTENANCE Reinstall control panel Parts required: control panel, screws, and burner control knobs. Place the control panel back onto the control panel brackets on either side of the front of the burner station. Line up screws with screw holes on both the control panel and control panel brackets. Tighten screws. Slide-In Burner Station Countertop Burner Station Control Panel...

  • Page 11: Flame Pattern

    GENERAL MAINTENANCE Flame pattern The Vieluxe ® burners have been factory set for the correct air and gas mixture. The correct flame pattern is shown at right. 1) Burner tube 2) Tips occasionally flicker yellow 3) Light blue 4) Dark blue Check that all burner components are in place.

  • Page 12: Burner Station Troubleshooting

    Burner assembly consists of: Burner cap, burner ring, burner head, and burner base. © 2004 Weber-Stephen Product Co. Vieluxe ® , Flavorizer ® and Crossover ® are registered U.S. trademarks; Gas Catcher ™ , is a trademark, all of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL 60067-6266. U.S.A. 1-866-VIELUXE.
