Liquid Propane Dual Burner Station Owner's Guide
Vieluxe
®
Slide-In Dual Burner Station
(Model #: 36251)
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fire department.
Leaking gas may cause a fire or
explosion which can cause serious
bodily injury or death, or damage to
property.
WARNING
1. Do not store spare liquid propane
cylinder within 10 feet (3m) of this
appliance.
2. Do not store or use gasoline or other
flammable liquids or vapors within
25 feet (8m) of this appliance.
Y
OU MUST READ THIS
O
'
G
WNER
S
UIDE BEFORE OPERATING YOUR BURNER STATION
Vieluxe
®
Countertop Dual Burner Station
(Model #: 37251)
WARNING: Follow all leak-check
procedures carefully in this manual
prior to burner station operation. Do
this even if burner station was
dealer-assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
THIS GAS APPLIANCE IS DESIGNED
FOR OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
61267 0204

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vieluxe Slide-In Dual Burner Station and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber Vieluxe Slide-In Dual Burner Station

Summary of Contents for Weber Vieluxe Slide-In Dual Burner Station

  • Page 1 Liquid Propane Dual Burner Station Owner’s Guide Vieluxe ® Slide-In Dual Burner Station Vieluxe ® Countertop Dual Burner Station (Model #: 36251) (Model #: 37251) DANGER WARNING: Follow all leak-check procedures carefully in this manual If you smell gas: prior to burner station operation. Do 1.
  • Page 2 DANGER Failure to follow the Dangers, Warnings and Cautions contained in this Owner’s Manual may result in serious bodily injury or death, or in a fire or an explosion causing damage to property. WARNINGS Do not store a spare or disconnected liquid propane cylinder under or near this burner station. Improper assembly may be dangerous.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS WARRANTY GENERAL INSTRUCTIONS STORAGE OPERATING CLEANING GAS INSTRUCTIONS LIGHTING THE LEFT & RIGHT SIDE BURNERS 11 TO EXTINGUISH MANUALLY LIGHTING THE LEFT & RIGHT BURNERS TO EXTINGUISH GENERAL MAINTENANCE CHECK FOR GAS LEAKS REMOVE CONTROL PANEL REINSTALL CONTROL PANEL REINSTALL BURNER CONTROL KNOBS &...

  • Page 4: Warranty

    Customer Service Toll Free at 1-866-VIELUXE If Weber-Stephen confirms the defect and approves the claim, Weber-Stephen will elect to replace such parts without charge. If you are required to return defective parts, transportation charges must be prepaid. Weber-Stephen ®...

  • Page 5: General Instructions

    WARNING: The LP pressure regulator and hose assembly supplied with the outdoor cooking gas appliance must be used. Replacement LP pressure regulators and hoses must be obtained from Weber-Stephen Product Co.. Cleaning WARNING: Turn your Vieluxe ®...

  • Page 6: Gas Instructions

    DANGER NEVER store a spare LP Cylinder under or near this grill. NEVER fill the tank beyond 80% full. Your Weber ® gas grill is equipped with a cylinder supply system designed for vapor withdrawal. WARNING: Only use this grill outdoors in a well- ventilated area.
  • Page 7 We utilize various LP tank manufacturers. Some of the Note: This is a new type of connection. It tightens tanks have differing top collar assembles. (The top clockwise and will not allow gas to flow unless the collar is the metal protective ring around the valve.) connection is tight.
  • Page 8 Check for gas leaks Check: 1) Hose-to-manifold connection. After a period of nonuse, we recommend that you 2) Regulator-to-Cylinder connection. perform the following maintenance procedures for your WARNING: If there is a leak at connection (1), safety. retighten the fitting with a wrench and recheck WARNING: Check the hose before each use of for leaks with soap and water solution.
  • Page 9 Refilling the Liquid Propane Cylinder Checking the fuel level in your tank We recommend that you refill the LP cylinder before it Check the fuel level by viewing the color indicator level is completely empty. line on the side of the tank scale. Removal of the LP cylinder Empty 1) Close cylinder valve (turn clockwise).
  • Page 10 Safe handling tips for Liquid Propane Gas Liquid Propane (LP) Cylinder(s) ■ The joint where the hose connects to the LP Cylinders ■ Liquid Propane (LP) gas is a petroleum product as cylinder must be leak tested each time the LP cylinder is reconnected.

  • Page 11: Lighting The Left & Right Side Burners

    LIGHTING THE LEFT & RIGHT BURNERS Summary lighting instructions are located on the inside of the burner station lid. WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only Vieluxe ®...

  • Page 12: Manually Lighting The Left & Right Burners

    MANUALLY LIGHTING THE LEFT & RIGHT BURNERS Summary lighting instructions are located on the inside of the burner station lid. DANGER: Both burners valves must be in the OFF position before turning on the gas supply. If the valves are not in the OFF position, gas will flow to the burners. This condition can cause a fire or explosion resulting in serious bodily injury or death.

  • Page 13: General Maintenance

    GENERAL MAINTENANCE Check for gas leaks WARNING The gas connections of your Vieluxe ® burner station have been factory tested. We do however recommend that you leak check all gas connections before operating your Vieluxe ® burner station. Remove control panel Tool required: Screwdriver Remove the burner control knobs (1).
  • Page 14 GENERAL MAINTENANCE Completely remove the control panel from the cooking box assembly exposing the valves, burners, igniters, and manifold. Countertop Burner Station Slide-In Burner Station DANGER Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for leaks.

  • Page 15: Reinstall Control Panel

    GENERAL MAINTENANCE Reinstall control panel Parts required: control panel, screws, and burner control knobs. Place the control panel back onto the control panel brackets on either side of the front of the burner station. Line up screws with screw holes on both the control panel and control panel brackets. Tighten screws. Slide-In Burner Station Countertop Burner Station Control Panel...

  • Page 16: Flame Pattern

    GENERAL MAINTENANCE Flame pattern The Vieluxe ® burners have been factory set for the correct air and gas mixture. The correct flame pattern is shown at right. 1) Burner tube 2) Tips occasionally flicker yellow 3) Light blue 4) Dark blue Check that all burner components are in place.

  • Page 17: Burner Station Troubleshooting

    BURNER STATION TROUBLESHOOTING WARNING: Before attempting any troubleshooting steps, all gas controls and supply valves should be in the OFF position. Problem Check Cure Burner does not light. Is gas supply off? Turn supply on. Flame is low in HIGH position. Is fuel hose bent or kinked? Straighten hose.

  • Page 18: Burner Station Exploded View

    Burner assembly consists of: Burner cap, burner ring, burner head, and burner base. © 2004 Weber-Stephen Product Co. Vieluxe ® , Flavorizer ® and Crossover ® are registered U.S. trademarks; Gas Catcher ™ , is a trademark,all of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL 60067-6266. U.S.A. 1-866-VIELUXE.
