Related Manuals for Daewoo KOG-63GP
Summary of Contents for Daewoo KOG-63GP
- Page 1 MICROWA VE OVEN KOG-63GP OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Earthing Instructions
EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed. -
Page 4: Specifications
SPECIFICATIONS POWER SUPPLY 220~240V 50Hz, SINGLE PHASE WITH EARTHING MICROWAVE 1200 W POWER GRILL 1050 W CONSUMPTION COMBINATION 2200 W MICROWAVE ENERGY OUTPUT 800W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (W x H x D) 465 x 279 x 346mm CAVITY DIMENSIONS (W x H x D) 290 x 208 x 306mm NET WEIGHT APPROX. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1. -
Page 6: Features Diagram
FEATURES DIAGRAM q 0 9 1. Door seal - Door seal maintains the microwave 8. Roller guide - This must always be used for energy within the oven cavity and prevents cooking together with the glass cooking tray. microwave leakage. 9. - Page 7 FEATURES DIAGRAM ( continued ) 12. Display- Cooking time, power level, indicators 18. Clock- Used to set clock. and present time are displayed. 19. Timer- Used to set a minute timer. 13. Time set pads- Used to set the cooking time and the present time.
-
Page 8: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. a. Plug power supply cord into a 220~240V 50Hz power outlet. b. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 9: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will show “ 88:88 ”. If the AC power ever turns off, the display shows “ 88:88 ” when the power comes back on. 1. Press Clock pad. Display will show “24H”. -
Page 10: Multi-Stage Cooking
MULTI-STAGE COOKING The oven has 3 stage memory, so you can program up to 3 different instructions and the oven will switch automatically from power to power except timer function (Repeat steps 1 and 2 above but only press Start after all stages have been entered). NOTE: Auto Weight/Defrost key can be in 1st stage only. -
Page 11: Auto Weight Cook Program
AUTO WEIGHT COOK PROGRAM This feature allows you to cook or reheat five foods by setting the weight only. The oven determines the Microwave power level and the cooking time automatically. Select the category of food and then just enter the weight. The weight can be entered in grams or pounds and ounces. The Auto Weight Programs are designed to take the guesswork out of cooking or reheating your food. -
Page 12: Power Save Mode
4. Fresh Veg. (200g - 1000g) 1. Press Fresh Veg. pad. The Auto indicator lights and 4 is displayed. 2. Set the weight by pressing UP or DOWN pad. The weight will change in 10g increments. 3. Press Start pad. 5. -
Page 13: Grill Cooking
GRILL COOKING This function allow you to brown food quickly. The heating element is located in the top of the oven. There is no pre-heating the oven for grill cooking. Place food inside the oven when setting the controls. The Grill indicator lights and “ : 0” is displayed. 1. -
Page 14: To Stop The Oven While The Oven Is Operating
TO STOP THE OVEN WHILE THE OVEN IS OPERATING 1. Press Stop/Cancel pad. • You can restart the oven by pressing Start pad. • Press Stop/Cancel pad once more to erase all instructions. • You must enter in new instructions. 2. -
Page 15: Cooking Utensils
COOKING UTENSILS Only use utensils that are suitable for use in microwave ovens. Microwave energy is produced by high frequency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy. Listed below are the suggested cooking utensils for this microwave oven and when to use them. -
Page 16: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to the following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3.
