American Dynamics RAS915 Operator's Manual Supplement

American Dynamics RAS915 Operator's Manual Supplement

Speeddome ultra vii camera dome configuration utility
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
SpeedDome

Camera Dome

Configuration Utility

Operator's Manual Supplement
RAS915/RAS916/RAS917 Series
Contents
About this Supplement .......................................... 1
New SpeedDome Ultra VII Features..................... 1
Quick Set Menu..................................................... 2
Scan Limits............................................................ 4
AD Up-the-Coax Protocol...................................... 5
Controllers ........................................................ 6
Specifications-SDU VII ........................................ 10
Specifications-22X Camera................................. 11
Declarations ........................................................ 13
© 2004 Sensormatic
SPEEDDOME ULTRA VII CAMERA DOME CONFIGURATION UTILITY
OPERATOR'S MANUAL SUPPLEMENT
Ultra VII
®

About this Supplement

This supplement provides detailed information
about SpeedDome Ultra VII camera dome features
that are not currently covered in your operator's
manual. This supplements information found in the
following manuals:
•
22x Camera Dome Configuration Utility
Operator's Manual, 8200-0184-02
•
Day/Night Camera Dome Configuration Utility
Operator's Manual, 8200-0184-04
NOTE:
Keep this supplement with your operator's
manual for reference purposes.
If you need assistance...
Contact your Sales Representative.
New SpeedDome Ultra VII
Features
SpeedDome Ultra VII provides the following
features with firmware version 0710-0147-0106
and newer.
• Quick Set Menu for accessing commonly used
dome settings
• Auto Iris/Auto Focus resume settings
• Scan Limits for establishing start and stop points
for monitoring a specific area
• AD Up-the-Coax protocol for compatible
American Dynamics controllers
In addition, updated information is provided for the
following:
• SensorNet and RS-422 matrix switchers and
controllers
• Preset programming instructions for the
Panasonic WJ-SX550 multiplexer and
WV-CU550A controller
1 of 13
8200-0184-09, REV. A
