SECTION 6—SEAT AND BACK
After any adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely. Otherwise injury or damage may occur.
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely - otherwise injury or damage may occur.

Replacing Back Upholstery

NOTE: For this procedure, refer to FIGURE 6.1.
1. Remove the eight mounting screws and
washers that secure the existing back
upholstery to the back canes.
2. Remove existing back upholstery from
the back canes.
3. Securely tighten the new back
upholstery to the back canes with the
phillips screws and washers.The
following chart determines the number
of mounting screws for each seat depth.

Replacing Seat Upholstery

NOTE: For this procedure, refer to FIGURE 6.2.
1. Remove the eight phillips screws and
washers that secure the existing seat
upholstery to the crossbraces.
2. Remove the existing seat upholstery
from the crossbraces.
3. Ensure positioning of seat positioning
strap (if used). Refer to Installing the
Seat Positioning Strap on page 54.
4. Install new seat upholstery by
reversing STEPS 1-2.
