- Page 1 MICROWA VE OVEN KOR-6N1G3 OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 13. -
Page 4: Federal Communications Commission Radio Frequency Interference Statement(U.s.a. Only)
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT(U.S.A. ONLY) WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception. It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation. -
Page 5: Installation
INSTALLATION 1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. 2. Level, flat location. Install the microwave oven on a level, flat surface. 3. -
Page 6: Specifications
SPECIFICATIONS POWER SUPPLY 120V~ / 60Hz, SINGLE PHASE WITH GROUNDING POWER CONSUMPTION 1000 W MICROWAVE OUTPUT POWER 700 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 465 X 279 X 324 mm (18.3 X 11.0 X 12.8 in.) CAVITY DIMENSIONS (W X H X D) 301 X 219 X 283 mm (11.9 x 8.6 x 11.2 in) NET WEIGHT... -
Page 7: Features Diagram
FEATURES DIAGRAM 1 Door latch-When the door is closed it will 6 Door release button-Pushing this button automatically shut off. If the door is stops oven operation and opens the door. opened while the oven is operating, the 7 Glass cooking tray-Made of special heat magnetron will automatically shut off. - Page 8 FEATURES DIAGRAM (continued) M/W DEF TIMER LOCK lb 1. BREAD 2. SOUP 3. BAKED POTATO 4. FRESH VEGETABLE 5. FROZEN VEGETABLE AUTO COOK MORE LESS FROZEN DINNER POPCORN PIZZA PLATE AUTO DEFROST MEAT POULTRY FISH 1 2 3 POWER 4 5 6 7 8 9 DEFROST KITCHEN...
-
Page 9: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a standard 3-pronged 15 Amp, 120V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 10: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “:0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on. 1. -
Page 11: Weight Defrosting
WEIGHT DEFROSTING AUTO DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. The lb indicator light and “ 1.0 ” is displayed. MEAT 2. Select the desired defrosting The display will show what you touched. -
Page 12: Cooking In One Stage
COOKING IN ONE STAGE 1. Touch POWER pad. The M/W indicator lights. POWER (Select the desired power level.) The display will show what you touched. Note : If steps 1 is omitted, the oven will cook at full power. 2. Touch number pads for the cooking The display will show what you touched. -
Page 13: Kitchen Timer Mode
KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking. However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1. -
Page 14: Speedy Cook
SPEEDY COOK SPEEDY COOK allows you to reheat for 30 seconds at full power by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. 1. -
Page 15: Auto Cook
ONE TOUCH COOKING (continued) 1. Touch DINNER PLATE pad once When you touch DINNER PLATE pad once, “ 12 ” DINNER for 12 oz of dinner plate or twice for is displayed. PLATE 15 oz of dinner plate. After 1.5 seconds, the display is changed into cooking time and the oven starts cooking. -
Page 16: Less, More
LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE.(except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 seconds. The overall one touch cooking time can be increased to a maximum of 59 minutes 50 seconds. Press LESS/MORE to decrease/increase the cooking time in multiples of 1 minute. -
Page 17: Utensil Test
Dishes that do not absorb microwave energy are best for microwave cooking. Lock on the label to verify that particular cups, glasses, plates are indeed suitable, especially paper goods. If you are not sure, try this utensil test to check. UTENSIL TEST •... -
Page 18: Defrosting Frozen Foods Chart
DEFROSTING FROZEN FOODS CHART Item and Weight Defrosting Time Standing Time Special Techniques BEEF Break apart and remove thawed Mineed beef 10-12 min. 5-7 min. portions with fork. 454g (1 lb.) Stew Meat Separate and rearrange once. 9-11 min. 5-7 min. 681 (1 1 /2 lbs.) Turn over after half the time. -
Page 19: Cooking Chart
COOKING CHART MEAT ITEM POWER LEVEL COOKING TIMER PER 500g Beef Standing/rolled Rib - Rare P-80 9-11 min. - Medium P-80 10-12 min. - well done P-80 12-14 min. Ground Beef(to brown for casserole) P-HI 5-7 min. Hamburgers, Fresh or defrosted (4 oz. -
Page 20: Reheating Chart
VEGETABLE ITEM POWER LEVEL PREPARATION QUANTITY COOKING TIME STANDING TIME asparagus, fresh P-HI 11/2-in.pieces 500g(1 lb.) 7-9 min. 3 min. asparagus, frozen P-HI Whole spears 280g(10 oz. pkg) 7-9 min. 3 min. broccoli, fresh P-HI Spears 500g(1 lb.) 7-9 min. broccoli, frozen P-HI Whole or cut... - Page 21 ITEM QUANTITY POWER LEVEL COOKING TIME SPECIAL INSTRUCTION 2 pieces P-HI 3-5 min. Arrange, on paper tower lined Fried chicken 4 pieces P-HI 4-6 min. paper plate, covered with paper 6 pieces P-HI 5-7 min. tower. 2 fillets P-HI 3-4 min. Fried fresh fillets 4 fillets P-HI...
-
Page 22: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. Keep the inside of the oven clean. When food spatters or spilled liquids adhere to oven walls, wipe with a damp cloth. -
Page 23: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY GENERAL USE Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads. Do not subject the oven door strain or weight such as a child hanging on an open door. -
Page 24: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to the following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3. - Page 25 QUESTIONS AND ANSWERS (continued) * Q : Why this standing time recommended after the cooking operation has been completed? A : Standing time is very important. With microwave cooking, the heat is in the food, not in the oven. Many foods build up enough internal heat to allow the cooking process to continue, even after the food is removed from the oven.
