Planar PCT2485 Specification

The Planar® Helium™ PCT2485 is a 24" multi-touch
monitor with an edge-to-edge glass surface, wide
viewing angle and built-in HD webcam. The monitor
include the sleek, easily-adjustable and
ergonomically-friendly Helium Stands for comfortable
and controlled user experiences. The Planar
PCT2485 is optimized for the all-new touch interface
of Microsoft Windows® 7 and 8 and is ideal for use by
software developers and designers, corporate power-
users, enthusiasts and retailers.
SPECIFICATION
Product Name
Planar Part Number
Viewable Size
Touchscreen Type
Number of Touch Points
Touchscreen Interface
Transmissivity
Contrast Ratio (typ)
Viewing Angle (typ)
Response Time (typ)
Brightness
(w/touchscreen)
Brightness (w/o
touchscreen)
Brightness (Typical)
Display Type
Display Resolution
Aspect Ratio
Tilt Range
Palette
Planar PCT2485
24" Touch Screen Monitor
DETAIL
PCT2485
997-7052-00
23.6" diagonal (20.52" horizontal x 11.54" vertical)
Multi-Touch Projected Capacitive (up to 10 touch points)
10
USB
N/A
1000:1
178° H,V
14 ms
220 cd/m²
250 cd/m²
N/A
LED
1920 x 1080, full HD
16:9
+15° to +70° and flat
16.7 million colors
