- Page 1 PXL3280W LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Front View of the Product ............................7 Rear View of the Product ..............................8 Quick Installation ................................9 Basic Operation and Calibration/Reset Instructions..................10 Advanced Operation—OSD Menu......................... 12 Supporting Timing Modes ............................15 Technical Information ..............................16 Wall-Mount Installation Instructions........................17 Troubleshooting................................18 Planar Support ................................19... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the PXL3280W LED LCD monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 Please recycle or dispose of all electronic waste in accordance with local, state, and federal laws. Additional resources can be found online at http://www.planar.com/about/green/. The crossed-out wheelie bin symbol is to notify consumers in areas subject to Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU that the product was placed on the market after August 13, 2005 and must not be disposed of with other waste.
-
Page 5: Unpacking Instructions
Unpacking Instructions Remove the LED LCD Monitor out of the package and take off the plastic bag and Polystyrene Foam. Pull the base from Parallel versus Panel to Vertical. Adjust the Panel between -5° leaning forward and 10° leaning backward. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 6: Consignes De Sécurité
Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à... -
Page 7: Package Overview
Package Overview LED LCD Monitor Stand Power Cord HDMI Cable Display Port Cable User’s Guide... -
Page 8: First Setup
First Setup Install the stand base 1. Lay the LED LCD Monitor flat on a table with the LED screen face down. To prevent the monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set. 2. -
Page 9: Front View Of The Product
Front View of the Product ①②③④ ⑤ ⑥ ① OSD Turn On/ Off ② Scroll Down/ Adjust Decrease/ Brightness * ③ Scroll UP/ Adjust Increase/ Blue Light Reducer * ④ Input select/ Confirm Selection ⑤ Power On/ Off ⑥ LED Indicator * Hot keys Instructions please see “Using the OSD Menu”... -
Page 10: Rear View Of The Product
Rear View of the Product ① ② ③ ④ ⑤ ① DVI Input (DVI 24 pin) (Dual link) ② HDMI-1 input (HDMI 19 pin) ③ DisplayPort Input (DisplayPort 20 pin) ④ Headphone Jack ⑤ Power Input... -
Page 11: Quick Installation
Quick Installation Connect either DVI, HDMI or DisplayPort Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Please note. The monitor ships with HDMI and DisplayPort cable. DVI-dual link cable may be sourced separately from a cable supplier. -
Page 12: Basic Operation And Calibration/Reset Instructions
Basic Operation and Calibration/Reset Instructions Before using the LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD Monitor on/off: Press button on the front. The power LED indicator light will be blue when the LED LCD Monitor is on. - Page 13 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED LCD Monitor will show a “Power Button Locked” message for 3 seconds and the message will disappear automatically.
-
Page 14: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use ▲ or ▼ to select the desired OSD menu. Short Cuts Function from the button(s) Picture Adjust: To manually adjust the Contrast, Brightness, ECO Mode and OD of screen image. - Page 15 Color Adjust: To select the color for improving brightness and color saturation between Cool, Normal, Warm, User Color and Preset Mode. Cool: Adds blue to screen image for cooler white. Normal: Adds red to screen image for warmer white and richer red. Warm: Adds green to screen image for a darker color.
- Page 16 OSD Time Out: To automatically turn off On Screen Display (OSD) after a preset period of time. OSD Background: Allows the user to turn the OSD background On or Off. DisplayPort 1.2: To adjust the DisplayPort version. Memory Recall: To recall factory settings for Video & Audio controls. Press button 2 to select the Memory Recall menu option.
-
Page 17: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA 800 x 600 @ 75Hz 832 x 624 @ 75Hz... -
Page 18: Technical Information
Technical Information Panel 31.5” TFT (with LED backlight) Power Management On: 59 Watts (typical), 65 Watts (maximum) Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution QHD 2560 x 1440 max. Vertical Frequency 60Hz max. Compatibility Support up to 2560 x 1440 (non-interlaced) Mac®... -
Page 19: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. -
Page 20: Troubleshooting
Troubleshooting No power Make sure A/C power cord is securely connected to the power supply is firmly connected to the LED LCD Monitor . Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. Make sure all signal cables are installed. -
Page 21: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 22 Planar, a Leyard company 08/2016 Planar, a Leyard company. © Planar is a registered trademark of Planar, a Leyard company. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
