3. Specification

GPS Module
GPS Chipset
Frequency
Channel
C/A Code
chipset Fix time
(Open sky)
Accuracy
Interface Protocol
DGPS
WAAS
Dynamics
Altitude
Velocity
MCU
Antenna
Active Antenna RF
Connector
External Antenna
input Voltage
Power
Voltage Type
Screw Hole type
Antenna Detect function
Interface
Connector
Physical and Environment
Dimension
Weight
Temperature
- REB-3570 /LP
- Star III GPS Gsc3f/LP chipset
- L1 1,575.42 MHz
- 20 channels
- 1,023 MHz
- Reacquisition: less than 0.1s
- Hot start: 1 sec
- Warm start: 35 sec
- Cold start: 35 sec
- Position: within 10m for 90%
- Velocity: 0.1m/s
- NMEA 0183 ver 3.0, GGA, GSA, GSV (5), RMC
- SiRF Protocol + DR protocol + Map Matching Protocol
- 38400 bps, 8 data bits, no parity, 1 stop bits
- Default is Disable
- Default WAAS is Disable
- 18,000 meter maximum
- 514 meter/second maximum
- Silicon Lab C8051F353
- MCX (Male Head), 180 degree 8mm (standard)
- Option for any kind of RF Connector
- Recommend using 2.7V~3.3V
- DC +5V ± 1%
GPIO; Follow customer GPS antenna detector protocol
Port 2 baud Rate: 38400bps
1: YES / 0:NO
20 Pin Header，2.0 mm pitch (J2) Male seat
- 71±0.3mm(L) x 40.8±0.3mm(W) x 18.6mm
-
≦17(g)
- Operating : -40 ~ 85℃
- Storage : -40 ~ 85℃
RDR-3100 User Manual
±0.3mm
4
(H)
