RoyalTek RN1 Reference Manual

Portable navigation device
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RoyalTek RN1 Portable Navigation Device
Reference Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RN1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RoyalTek RN1

Summary of Contents for RoyalTek RN1

  • Page 1 RoyalTek RN1 Portable Navigation Device Reference Manual...

  • Page 2: Legal Notices

    NOTE：Record the device ID, serial number, purchase date, and place of purchase information in the space provided below. The serial number is indicated on the label affixed to your RoyalTek device. All correspondence concerning your unit should include the serial number, device ID, and purchase information.

  • Page 3: Warnings And Notices

    Warnings and Notices For your safety, do not operate the controls of the product while driving. GPS satellite signals cannot typically pass through solid materials (except glass). GPS location information is not typically available inside buildings, tunnels, or underground parking lots. A minimum of 4 GPS satellite signals is needed to calculate your GPS position.

  • Page 4: Fcc Warning

    FCC Warning The RN1 PND has been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in Part 15 of FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Table Of Contents

    Front Panel ...11 2.1.3 Car holder...12 Using the mounting bracket...13 Additional Application with the Optional SKU ...15 Chapter 3 Using the RN1 ...16 RN1 Operating Basics...16 To turn on the device:...16 To configure system settings:...16 Additional System settings ...18 Reset ...18 System Information ...21...
  • Page 6 5.1.8. Can’t I see my photos...30 5.1.9. Takes longer than normal time to get a GPS fix...30 5.1.10. Factory reset does mean a GPS reset...31 5.2. Maintenance ...31 5.2.1. Storage precautions...31 5.2.2. Accessories and repair precautions ...31...

  • Page 7: Chapter 1 Features And Specifications

    Chapter 1 Features and Specifications RoyalTek RN1 PND features The RoyalTek RN1 Portable Navigation Device is a powerful multifunction GPS/multimedia navigation and entertainment device. • Compact size and lightweight • Integrated GPS receiver for GPS navigation • High-resolution color LCD •...
  • Page 8 Category Item Battery General 500mA, Li-Polymer Power On (Default setting after factory reset) About 5 hours charge from empty to full. Recharge Time Power OFF About 2.5 hours charge from empty to full. Audio Earphone Yes (option) Speaker 1.0W mono speaker Hardware Button\Slot Micro SD Supports Micro SD...

  • Page 9: Chapter 2 Getting Started

    Chapter 2 Getting Started This chapter describes the hardware interface of the RoyalTek RN1 and its peripherals. Instructions for setting up the device and some basic system operations are also discussed. NOTE: Although the RN1 rechargeable Li-Polymer battery comes approximately 30% charged, before using, it is best to connect the AC adapter (Optional Accessory) or USB cable by PC connect and plug to power socket and fully charge the battery.
  • Page 10 USB cable(Option Accessory) Earphone (Option Accessory) AC adaptor (Option Accessory) Dashboard (Option Accessory) TMC Antenna (Optional Accessory). User’s manual DVD./ CD Portable Navigation Device Quick Start Guide. Portable Navigation Device Warranty statement.

  • Page 11: Front Panel

    2.1.2 Front Panel Figure 1: Top and Left/Rights side views Table 2-1: Top and Left/Right side controls Function Power button Standby mode by pressing the button for sleep/wake. Indicated the battery charging status. Power status LED Accepts Micro SD storage cards, allows you use audio, image files stored Micro SD in it for use with internal applications.

  • Page 12: Car Holder

    2.1.3 Car holder Figure 2: Car holder side views Table 2-2: Car holder No Function For USB port： Only serves as the power connector of charging, but mass USB Port/Docking storage function. Also, it can connect to external TMC module (Option connector part).

  • Page 13: Using The Mounting Bracket

    Using the mounting bracket. The RN1 comes with a car mount kit and a car charger to help install your device in your vehicle. The car mount kit uses a suction cup on the windshield to offer flexible mounting options for the RN1.
  • Page 14 Tap Navigation, you will see the map screen displayed. Please read the User’s Guide of Navigation software for the detail setting information. Please be noted, the first time turning on your RN1 may take some time to obtain a valid GPS fix. Figure 2-3-3...

  • Page 15: Additional Application With The Optional Sku

    Please visit: Please connect the TMC accessory to the USB port of RN1 car holder for the TMC application and be placing the TMC accessory in a place which will not interfere to the driving safe. (See Figure 2-4-1) Please refer to the User’s Guide of Navigation software for the detail TMC operating information.

  • Page 16: Chapter 3 Using The Rn1

    Chapter 3 Using the RN1 RN1 Operating Basics After fully charging the RN1, it is ready to be used. You can now turn it on and proceed to system settings configuration. To turn on the device: Sliding the battery switch to “ON”. (Default status OFF) Turn on your device by pressing the power button on the top right panel of the device.
  • Page 17 Tap “Language” on the System page. It will display current language in central area. To drag wheel scroll language tags. To set the system time zone, tap “Time Zone” in System Menu. Tap the icon to set up the function of daylight saving s time. represent enable the function of daylight savings time.

  • Page 18: Additional System Settings

    System Menu. Reset GPS Reset:：When user wonder if GPS receiver perform properly or not .( ex : Change the region) Factory Reset：The factory reset function not only resets the operating system settings to default factory values, but also reset the GPS settings.
  • Page 20 Tap the “Factory Reset” icon in the Reset Menu. Tap the “YES” to do the Factory Reset. Tap the “Calibration” icon in the Reset Menu. Tap on the center of the target. Repeat as the target moves around the screen.

  • Page 21: System Information

    System Information 1. Tap the Sys Info. icon in the System Menu. 2. You can view the OS version, GPS firmware version and other system information.. Volume Tap the Volume icon in the System Menu. To adjust the volume by drag the wheel. Drag to left will become silent else will become noisy.

  • Page 22: Backlight

    Backlight 1. Tap the Backlight icon in the System Menu. 2. Adjust the Backlight brightness by drag triangle icon. 3. Drag to left will become dark, drag to right will become light.

  • Page 23: To Set The Favorite Application Category

    To set the favorite application category: Otherwise, provide more organized and friendly application management interface for user organize their own favorite application category by drag-and-drop, the maximum number of favorite application shortcut is 6. Add icon to the favorite page Drag the icon to the category bar of favorite.

  • Page 24: Chapter 4 Entertainment

    The RN1 is a fully capable multimedia player that can enhance your portable entertainment. In addition to its navigating function, the RN1 is also a mobile entertainment tool to let you enjoy digital music, view photos. These functions make the RN1 a true multimedia device.
  • Page 25 The MP3 player window below controls playback. Table 4-3-2-1: MP3 player functions Function Return Return to list page Songs List all song by alphabet Album List all albums by alphabet. Artist List all Artists by alphabet Search Current play list ○...
  • Page 26 Tap the song on the music list. Tap bottom information bar will switch to song’s progress.
  • Page 27 ○ 9 ○ 7 ○ 5 ○ 6 Table 4-3-2-2: Play sound functions Function Play/Pause Forward Previous Stop Repeat Random Sound bar Bottom info. bar Return ○ 8 ○ 1 ○ 2 ○ 3 ○ 4 P/ay/Pause song Forward to next song. Reword to previous song Stop music play.

  • Page 28: Photo Viewer

    4.3. Photo Viewer The RN1 has a great photo viewing option that makes it easy to share and view digital photos anywhere on the go. The program features: • Support for JPEG files (Support Max. 500 photos) • Auto-scanning of supported files in the device’s Micro SD card & Flash disk •...
  • Page 29 Tap specific thumbnail will enlarge thumbnail. Tap the screen will cause control bar display ○ 1 ○ 2 ○ 3 ○ 4 Table 4-3-4-1: Photo Album Viewer Function Return Previous page Auto Play mode Next page Rotate ○ 5 Return to thumbnail page Display previous photo.

  • Page 30: Chapter 5 Troubleshooting And Maintenance

    Chapter 5 Troubleshooting and Maintenance 5.1. General troubleshooting 5.1.1. If your device does not respond, do a “hard reset.” To do a “hard reset,” Disconnect all cables, including the AC adapter, from your device. By sliding the hard reset switch on the primary ON/OFF switch on the right side of the device form OFF to ON position then tap the power button.

  • Page 31: Accessories And Repair Precautions

    will also take significantly longer than the standard TTFF time to get a GPS fix. This is due to the nature of the GPS algorithm and rotational velocity between the satellites and planet Earth, and deemed normal. Perform a GPS reset in the main/system/system info menu to get a faster GPS fix. 5.1.10.
