Dell B2375dfw Quick Reference Manual

Identifying the Location of Paper Jams

The paper jams may occur at any of the locations shown below:
CAUTION: To avoid permanent damage to your printer, do not attempt to clear paper jams using any tools or
instruments.
1 2
7 6

Printing the Printer Setting

1 Press My Settings → Machine Setup → Reports → Printer Settings from the home screen.
2 Press Start ( ) on screen.
3 The Printer Settings page prints out.

Cleaning the Printer

Vertical blanks in prints
➥ See "Cleaning Your Printer" in the User's Guide
HMCWMA00
JC68-03031A00
1 Scanner Unit
2 DADF Cover
3 Levers
4 Fusing Unit
5 Rear Cover
6 Front Cover
7 Multipurpose Feeder (MPF)
5 4 3
Replacing Toners
To replace toners
➥ See "Maintenence" in the User's Guide
Setting Up Wireless Connection
(Dell™ B2375dfw Mono MFP only)
To set up wireless connection
➥ See "Networking" in the User's Guide
www.dell.com/support
Dell™ B2375dfw / B2375dnf Mono MFP
Quick Reference Guide

About Your Printer

1
14 13 12 11
1 Operator Panel
3 Document Width Guide
5 Document Output Tray
7 Control Board Cover
9 Output Tray
11 Tray 1
13 Paper Output Extension
Locating the Service Tag
Service Tag XXXXXXX
October 2013
2 3 4 5
10 9 8 7 6
2 Duplex Automatic Document Feeder (DADF)
4 Document Input Tray
6 Document Glass
8 USB Memory Port
10 Front Cover
12 Multipurpose Feeder (MPF)
14 Toner Cartridge
Service Tag
XXXXXXX
000 000 000 00
Express Service Code
1
