ASSIGN IP ADDRESS AND NETWORK CLASS
1. Click the Start button on the Task Bar and select Programs ➜ Lantronix ➜
DeviceInstaller ➜ DeviceInstaller. The DeviceInstaller window displays.
Figure 1. DeviceInstaller Window
2. Click the IP icon . The Device Identification window displays.
Figure 2. Device Identification
6
Q u i c k S t a r t G u i d e
U D S 1 1 0 0
ASSIGN IP ADDRESS CONTINUED...
3. Enter the hardware or Ethernet address of the device. The address is on the
label on the underside of the unit.
4. Select Assign a specific IP address to assign a static IP address to the device,
or select Obtain an IP address automatically to enable BOOTP, DHCP, or
Auto IP on the device. Click Next.
Figure 3. Assignment Method
