- Page 1 BASS AMPLIFIER Hartke Systems 2000/3500...
-
Page 2: Table Of Contents
Model 2000 Front Panel 5 Model 2000 Rear Panel 7 Model 3500 Front Panel 9 Model 3500 Rear Panel 11 Setting Up and Using the Model 2000/3500 13 About Equalization 15 About Compression 17 Appendix A: Impedance vs. Expected Power 18... -
Page 3: Introduction
The two models covered by this manual differ in the following ways: • The Model 2000 provides 200 watts of power (into 4 ohms), while the Model 3500 provides 350 watts of power (into 4 ohms). -
Page 4: Features
Here are some of their main features: • Power to spare—in the case of the Model 2000, 200 watts into 4 ohms, and, in the case of the Model 3500, a full 350 watts into 4 ohms. -
Page 5: Guided Tour
8KHz 1. Passive Input jack - If your bass guitar has passive circuitry, connect it to the Model 2000 here. This standard 1/4” unbalanced jack provides a high impedance (100 k Ohms) input sensitivity of 20 millivolts. 2. Active Input jack - If your bass guitar has active circuitry,* connect it to the Model 2000 here. - Page 6 (30 Hz, 64 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 3 kHz, 5 kHz, and 8 kHz), affecting the main output signal of the Model 2000. When a slider is at its center detented (“0”) position, the selected frequency area is unaffected (it is said to be flat).
-
Page 7: Model 2000 Rear Panel
2. AC input - Connect the supplied standard 3-pin “EEC” plug here. 3. Fan - The fan provides vital cooling to your Model 2000. Make sure that it is kept free of all obstructions and that cool, fresh air is accessible at all times. - Page 8 6. Effect Send jack - Use this 1/4” unbalanced jack to send low impedance (600 ohm) signal from the Model 2000 to a professional outboard effects proces- sor such as a reverb, echo, chorus, flanger, or harmonizer device.* Output level is approximately 0 dB to +4 dB and is post-EQ and post-compression but unaffected by the setting of the Master Volume control.
-
Page 9: Model 3500 Front Panel
Guided Tour - Model 3500 Front Panel Hartke Systems MODEL 3500 350 WATTS ransient Attack GRAPHIC EQUALIZER INPUT PRE AMP CONTOUR MASTER 30Hz 64Hz 125Hz 250Hz 500Hz 1KHz 2KHz 3KHz 5KHz 8KHz PASSIVE ACTIVE VOLUME POWER LOW PASS HIGH PASS... - Page 10 Guided Tour - Model 3500 Front Panel 6. Compression control - This determines the amount of compression (peak signal reduction) by simultaneously adjusting both threshold and compression ratio (which ranges from 2:1 to infinity [limiting]). At the fully counterclockwise “Off” position, the circuitry is bypassed and no compression is applied (the knob clicks when set to the “Off”...
-
Page 11: Model 3500 Rear Panel
Guided Tour - Model 3500 Rear Panel SPEAKER EFFECT DIRECT OUT Hartke Systems OUTPUTS POST NORMAL SEND Distributed Exclusively by GND LIFT Samson Technologies Corp. Hicksville, New York 11802 MODEL 3500 ~ AC INPUT 115V/230V 50/60Hz 350 WATTS FUSE 8 = 240 WATTS... - Page 12 Guided Tour - Model 3500 Rear Panel 5. Effect Send jack - Use this 1/4” unbalanced jack to send low impedance (600 ohm) signal from the Model 3500 to a professional outboard effects proces- sor such as a reverb, echo, chorus, flanger, or harmonizer device.* Output level is approximately 0 dB to +4 dB and is post-EQ and post-compression but unaffected by the setting of the Master Volume control.
-
Page 13: Setting Up And Using The Model 2000/3500
4 ohms (that is, 4 ohms or greater) can be used. In order to ensure correct phase correlation, the tip of the Model 2000/3500 speaker jack should be con- nected to the “+” (hot) input of your loudspeaker, and the sleeve of the Model 2000/3500 speaker jack should be connected to the “-”... - Page 14 LOW PASS HIGH PASS idea to write it down for future use. 9. Next, experiment with the Model 2000/3500 graphic equalizer. Begin by set- GRAPHIC EQUALIZER ting each of the ten sliders to their flat “0” center detented position. Then press...
-
Page 15: About Equalization
EQ controls allow you to alter a sound by boosting or attenuating specific frequency areas—they operate much like the bass and treble controls on your hi-fi amp, but with much greater precision. The Model 2000/3500 pro- vides you with two different means for equalizing your bass sound: •... - Page 16 5KHz 8KHz Finally, as you experiment with the EQ controls of the Model 2000/3500, don’t forget that your bass also provides EQ controls in the form of its tonal settings— this can be particularly effective in instruments that have active circuitry. Also, try various EQ settings with different Pre-Amp blends and with and without Compression.
-
Page 17: About Compression
(transient) high output levels, as might be caused by finger-popping or other performance techniques. Whether or not you need to use compression with your Model 2000/3500 will be a matter of personal taste and playing style—experiment and see if you like the effect. -
Page 18: Appendix A: Impedance Vs. Expected Power
(NOTE: Measurements taken at 1 kHz, Solid State in, and at 3 kHz, Tube in, with 20 Hz - 30 kHz bandpass filter, to give less than 1% THD) Model Speaker Impedance Expected Power 2000 4 ohms 200 W 2000 8 ohms... -
Page 19: Appendix B: Block Diagram
COMPRESS 2 BAND VR SOLID CONTOUR STATE MIXER 10 BAND EQ 10 BAND OUT 10 BAND IN MASTER SECTION PROTECTION Model 2000 SEND 50 mV, IN COMPRESSOR 0 dB TO +4dB IN/OUT SWITCH FIXED EQ RETURN VR TUBE DETECTOR COMPRESS... -
Page 20: Changing The Model 2000/3500 Voltage
(actually 220 - 240 volts). The position of the two fuses in the sled as well as the fuse ratings must be maintained for adequate protection. Fuse ratings for the Model 2000 are: 5 amp for 115 VAC and 2.5 amp for 230... -
Page 21: Specifications
Passive Input 100 k Ohms 20 mv. Active Input 100 k Ohms 60 mv. 2. Rated Output Power Model 2000 200 watts @ 4 ohms 120 watts @ 8 ohms Model 3500 350 watts @ 4 ohms 240 watts @ 8 ohms 3.
