DV6T721D-AQ/D_SD6200
02.5.31 9:33 AM
Recording
To Record With VCR
DVD
MENU
TITLE/PBC
DISPLAY
OPEN/CLOSE
PR
SETUP
ENTER
PR
REPEAT
ZOOM
AUDIO
PREV
PLAY/PAUSE
PROGRAM
CLK/CNT
MARK
REC
SPEED/ANGLE
TV/VCR
TRACKING
30
˘
` 30
mac001
1
Press [ ] button to power on.
• Press [VCR] button of the remote control to change into VCR mode.
• Power on TV and select Ch 52 or reset channel, or press [TV/VCR] button to
select External Input mode.
2
Insert a recordable tape.
Always insert a tape with recording tab.
3
With [CHANNEL], [NUMBER] and [OUTPUT] buttons, select the desired
broadcasting channel or external input unit to record.
STANDBY/ON
VCR
VCR
OUTPUT
OUTPUT SELECT
CHANNEL
SUBTITLE
NEXT
PLAYBACK/
PAUSE
STOP
SEARCH
REC
REC SPEED
SYSTEM
NUMBER
600DPI 80LPI
4
Select the desired speed (SP or LP) with [SPEED]
button.
5
Press [REC] button.
Then, it starts recording.
6
If you want to pause recording, press [PAUSE]
button.
After pressing [PAUSE] button, if the pause status
continues for five minutes, the recording is released
automatically.
7
To exit recording, press [STOP] button.
