HP Z600 Specification

Hp z600 workstation
Hide thumbs Also See for Z600:
Table of Contents

Advertisement

Quick Links

See also: Maintenance and Service Manual , Function Manual
QuickSpecs

Overview

1. Power Button
2. 2 External 5.25" Bays
3. Front I/O: 3 USB 2.0, 1 IEEE 1394a, Headphone, Microphone
DA - 13277 North America — Version 51 — November 21, 2013
HP Z600 Workstation
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP Z600

Summary of Contents for HP Z600

  • Page 1 QuickSpecs HP Z600 Workstation Overview 1. Power Button 2. 2 External 5.25" Bays 3. Front I/O: 3 USB 2.0, 1 IEEE 1394a, Headphone, Microphone DA - 13277 North America — Version 51 — November 21, 2013 Page 1...
  • Page 2 Genuine Windows 7® Professional 32-bit* HP Linux Installer Kit for Linux [includes drivers for 32-bit & 64-bit OS versions of Red Hat Enterprise Linux(RHEL) 4 Workstation, Red Hat Enterprise Linux (RHEL) 5 Workstation, Red Hat Enterprise Linux (RHEL) 6 Workstation, 64-bit SUSE Linux Enterprise Desktop (SLED) 11] Red Hat Enterprise Linux Desktop (Preinstall NOT available;...
  • Page 3 QuickSpecs HP Z600 Workstation Overview Solaris 10, 11 Ubuntu 10.10, 11.04 Notes: For detailed OS/hardware support information for Linux, see: http://www.hp.com/support/linux_hardware_matrix *Systems may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See http://www.microsoft.com/windows/windows-7/...
  • Page 4 3 USB 2.0 headers [3 USB 2.0 ports available by one 2x5 header and one 1x5 header: supports either up to two HP Internal USB Port Kits, AMO- EM165AA (one port on each Kit), or one Internal Port kit and one USB Media Card Reader.]...
  • Page 5 QuickSpecs HP Z600 Workstation Overview Maximum Altitude (non- Operating: 3,000 m; 10,000 feet pressurized) Non-operating 9,100 m; 30,000 feet Power Supply 650W 85% (80PLUS) Efficient wide-ranging, active Power Factor Correction, with tool-free & cable-free connection The Power Supply Efficiency Report for this product may be found at this link: http://www.80plus.org/manu/psu/psu_reports/SO-034_DELTA_DPS-25AB%20A_650W_...

  • Page 6: Supported Components

    Support for Xeon 5600 Series processors requires the C2 revision of the Intel 5520 chipset. Two methods are available to determine if a specific Z600 system has the C2 revision of the chipset. 1. Use the BIOS setup menu to access the "Boot Block Date" from the "System Information Menu". All B3-based systems will have a "1/30/09"...
  • Page 7 Option Kit Part Support Configured Number Notes HP SAS (Serial Attached SCSI) Hard Drives for HP Workstations 300GB SAS 15K rpm 6Gb/s 3.5" HDD LU967AA 450GB SAS 15K rpm 6Gb/s 3.5" HDD LU968AA 600GB SAS 15K rpm 6Gb/s 3.5" HDD...
  • Page 8 QuickSpecs HP Z600 Workstation Supported Components HP 160GB SATA SSD LZ704AA HP 256GB SATA SSD A3D26AA HP 300GB SATA SSD LZ069AA For hard drives, 1 GB = 1 billion bytes; TB = 1 trillion bytes. Actual formatted capacity is less.
  • Page 9 QuickSpecs HP Z600 Workstation Supported Components Graphics Option Supported Factory Option Kit Part Multi Configured Number Support Notes Mixed Professional 2D NVIDIA Quadro NVS 295 256MB PCIe FY943AA 2nd card must Graphics Card be NVS 450 or NVS 295 NVIDIA Quadro NVS 450 512 MB PCIe...
  • Page 10 QuickSpecs HP Z600 Workstation Supported Components 8GB (2x2GB + 1x4GB) DDR3-1333 ECC Unbuffered RAM 1- 12GB (3x4GB) DDR3-1333 ECC Unbuffered RAM 1-CPU 4GB (2x2GB) DDR3-1333 ECC Unbuffered RAM 2-CPU Both processor sockets must be populated. 8GB (4x2GB) DDR3-1333 ECC Unbuffered RAM 2-CPU...
  • Page 11 Support for Registered DIMMs on the Z600 requires a systemboard with the C2 revision of the Intel 5520 chipset. Two methods are available to determine if a specific Z600 system has the C2 revision of the chipset.
  • Page 12 Option Kit Factory Part Support Configured Option Kit Number Notes HP USB 3.0 2x2 Port SuperSpeed PCIe x1 Card QT587AA HP SuperSpeed USB 3.0 PCIe x1 Card BM867AA HP FireWire/IEEE 1394a PCI Card PA997A HP IEEE 1394b FireWire PCIe Card NK653AA DA - 13277 North America —...
  • Page 13 Number Support Notes Integrated Broadcom 5764 PCIe LOM Controller Broadcom NetXtreme Gigabit Ethernet Plus NIC (PCIe) FS215AA HP NC360T PCI Express Dual Port Gigabit NIC KU004AA Intel Gigabit CT Desktop NIC FH969AA The Broadcom NetXtreme Plus card may be used, along with the integrated 5764 LOM, for teaming, redundancy, or additional network bandwidth.
  • Page 14 PA716A Provides 1st Serial Port for the Z600. HP Internal USB Port Kit EM165AA HP Workstation to LTO SAS Int. Cable EH925A HP Optical Bay HDD Mounting Bracket NQ099AA For 3.5" HDDs HP ENERGY STAR 5.0 Enabled Configuration Software Option Kit...
  • Page 15 QuickSpecs HP Z600 Workstation Supported Components system memory. HP Remote Graphics Software (RGS) V5 Will be preloaded starting 12/1/11. Supports both 32 and 64 bit versions of Windows 7 Professional and Enterprise, Windows XP Professional and Enterprise, Windows Vista Business,...

  • Page 16: System Board

    QuickSpecs HP Z600 Workstation System Technical Specifications System Board System Board Form Factor 36 x 28 cm 14.2 x 11 inches Processor Socket Dual LGA 1366 CPU Bus Speed QPI: Up to 6.4GT/second, depending on processor Chipset Intel® 5520 Super I/O Controller...
  • Page 17 QuickSpecs HP Z600 Workstation System Technical Specifications Memory Configuration Not all memory configurations possible are represented above. Only ECC DIMMs are supported. (Supported) Do not install memory modules into memory slots if corresponding processor is not installed. Dual processor configurations with memory modules installed for only one processor is not supported.
  • Page 18 Internal 3 [3 USB 2.0 ports available by one 2x5 header and one 1x5 header: supports either up to two HP Internal USB Port Kits, AMO- EM165AA (one port on each Kit), or one Internal Port kit and one USB Media Card Reader.]...
  • Page 19 QuickSpecs HP Z600 Workstation System Technical Specifications Chassis Fan Header 2 Rear System Chassis Fan Header 1 Front Chassis Fan Header Front PCI Fan Header Front Control Panel/Speaker Header CMOS Battery Holder – Lithium Integrated Trusted TPM 1.2, Infineon Platform Module...
  • Page 20 Clear CMOS Button Chassis Speaker Header Yes (Integrated in Front Control Panel Cable) ENERGY STAR® qualified (Config Dependent) Z600 Required Power Supply Info Power Supply 650 watt custom power supply – (Wide Ranging Active PFC) Operating Voltage Range 90 - 269 VAC Rated Voltage Range 100 –...
  • Page 21 QuickSpecs HP Z600 Workstation System Technical Specifications Power Consumption in sleep mode (as defined by <9W ENERGY STAR) - Suspend to RAM (S3) (Instantly Available PC) measured at 115V. Built-in Selft Test LED Surge Tolerant Full Ranging Power Supply (withstands power surges up to 2000V DA - 13277 North America —...
  • Page 22 QuickSpecs HP Z600 Workstation System Technical Specifications DA - 13277 North America — Version 51 — November 21, 2013 Page 22...
  • Page 23 QuickSpecs HP Z600 Workstation System Technical Specifications Declared Noise Emissions (Entry-level and High-end configurations) System Configuration Processor Info Dual Intel® Xeon® X5570 2.93Ghz processors (Entry level) Memory Info 4 x 1GB 1333Mhz Graphics Info NVIDIA Quadro NVS 295 Disks/Optical/Floppy 250GB 7200 rpm SATA / 1 DVD-ROM/ 1 Floppy DA - 13277 North America —...
  • Page 24 QuickSpecs HP Z600 Workstation System Technical Specifications Declared Noise Emissions Sound Power (LWAd, bels) Deskside Sound Pressure (in accordance with ISO (LpAm, decibels) 7779 and ISO 9296) Idle Hard drive Operating (random reads) Floppy Drive Operating (continuous copy) DVD-ROM Operating...
  • Page 25 Configuration Record SW Yes Over-Temp Warning on Screen Restore CD/DVD Set Restores the computer to its original factory shipping image - Can be obtained via HP Support Dual Function Front Also acts as a reset switch when held for 4 seconds Power Switch...
  • Page 26 View the hardware configuration of the system Key features and benefits HP Vision Diagnostics simplifies the process of effectively identifying, diagnosing, and isolating the hardware issues. In addition to robust management tools, service tools can be invaluable in quickly resolving system problems. To streamline the service process and resolve problems quickly, it is necessary to have the right information available at the time that a service call is placed.
  • Page 27 QuickSpecs HP Z600 Workstation System Technical Specifications Sending configuration information to another location for more in-depth analysis Access Panel Key Lock Yes, prevents removal of the access panel and all internal components including optical and floppy drives ACPI-Ready Hardware Advanced Configuration and Power Management Interface (ACPI).
  • Page 28 QuickSpecs HP Z600 Workstation System Technical Specifications Boot Control Disables the ability to boot from removable media on supported devices Memory Change Alert Alerts management console if memory is removed or changed Thermal Alert Monitors the temperature state within the chassis. Three modes: NORMAL - normal temperature ranges.
  • Page 29 QuickSpecs HP Z600 Workstation System Technical Specifications Industry Standard Revision Supported by the BIOS ACPI Advanced Configuration and Power Management Interface, Version 2.0 Alert Standard Format Specification, Version 2.0 ATA (IDE) AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b CD Boot "El Torito"...
  • Page 30 To recycle your product, please go to: http://www.hp.com/recycle or contact your nearest HP sales office. and Recycling Products returned to HP will be recycled, recovered or disposed of in a responsible manner. Hewlett-Packard For more information about HP's commitment to the environment: Corporate Environmental Global Citizenship Report: http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html...
  • Page 31 NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply. NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
  • Page 32 HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is available at: http://www.hp.com/hps/carepack.
  • Page 33 © 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
  • Page 34 Offerings are built on the foundation of a carefully chosen set of hardware and software designed and tested to work with all HP Z Workstation platforms through their end of life. These components and their corresponding HP Workstation platform compatibility are outlined in this section.
  • Page 35 QuickSpecs HP Z600 Workstation Stable & Consistent Offerings Operating Systems Product # Offering VM436AV Genuine Windows® 7 Professional 64-bit DA - 13277 North America — Version 51 — November 21, 2013 Page 35...
  • Page 36 QuickSpecs HP Z600 Workstation Technical Specifications - Processors Processors Intel® Xeon® Processor X5675 6C 3.06 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 LB215AA 1333MHz, HT, Turbo Intel® Xeon® Processor X5672 4C 3.20 GHz, 95W, 12M cache, 6.40GT/s QPI, DDR3 LB214AA 1333MHz, HT, Turbo Intel®...

  • Page 37: Turbo Boost Technology

    QuickSpecs HP Z600 Workstation Technical Specifications - Processors Scalable shared memory of Intel® QuickPath technology features memory distributed to each processor with integrated memory controllers and high-speed point-to-point interconnects to unleash the performance of future versions of next-generation Intel® multi-core processors.
  • Page 38 QuickSpecs HP Z600 Workstation Technical Specifications - Monitors / Displays HP LP2065 20-inch LCD QuickSpecs URL http://h18000.www1.hp.com/products/quickspecs/12377_div/12377_div.html Monitor Part Number Workstation Volume Channel EF227A4 Workstation Value Channel EF227A5 HP LP2475w 24-inch QuickSpecs URL http://h18000.www1.hp.com/products/quickspecs/13134_div/13134_div.html Widescreen LCD Monitor Part Number KD911A8...
  • Page 39 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drives HP SAS (Serial Attached 600GB SAS 15K rpm 6Gb/s Capacity 600GB SCSI) Hard Drives for HP 3.5" HDD Height 1 in; 2.54 cm Workstations Width Media Diameter 3.5 in; 8.9 cm Physical Size 4 in;...
  • Page 40 Full Stroke 6.6 ms settling) Rotational Speed 15,000 rpm Operating Temperature 50° to 95° F (10° to 35° C) HP 300GB SAS 10K SFF Capacity 300GB Height 0.6 in; 1.53 cm Width Media Diameter 2.5 in; 6.36 cm Physical Size 2.75 in;...
  • Page 41 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drives Height 0.6 in; 1.53 cm Width Media Diameter 2.5 in; 6.36 cm Physical Size 2.75 in; 6.99 cm Interface SAS 6Gb/s Synchronous Transfer Up to 600MB/s Rate (Maximum) Buffer 64MB Cache...
  • Page 42 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drives Buffer 16 MB Seek Time (typical reads, Single Track 0.7 ms (maximum) includes controller Average 4.4 ms overhead, including Full Stroke 9.5 ms settling) Rotational Speed 10,000 rpm Logical Blocks 586,072,368 Operating Temperature 41°...
  • Page 43 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drives 1.5TB SATA 7200 rpm Capacity 1.5TB 3Gb/s 3.5" HDD Height 1 in; 2.54 cm Width Media Diameter 3.5 in; 8.9 cm Physical Size 4.0 in; 10.17 cm Interface Serial ATA (3.0 Gb/s), Native Command Queuing...
  • Page 44 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drives Synchronous Transfer 300 MB/s Rate (Maximum) Buffer 16 MB Seek Time (typical reads, Single Track 2 ms includes controller Average 11 ms overhead, including Full Stroke 21 ms settling) Rotational Speed...
  • Page 45 21 ms settling) Rotational Speed 7,200 rpm Logical Blocks 312,581,808 Operating Temperature 41° to 131° F (5° to 55° C) HP Solid State Drives for HP 160GB SATA SSD Capacity 160GB Workstations Width Media Diameter NaN in; NaN cm Physical Size 2.5 in;...
  • Page 46 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drive Controllers LSI 3041E 4-Port SAS 3.0 PCI Bus PCI-Express x4 lanes Gb/s RAID Card PCI Modes Bus Master DMA RAID Levels RAID 0, 1, 1E and 10E PCI Data Burst Transfer...
  • Page 47 QuickSpecs HP Z600 Workstation Technical Specifications - Hard Drive Controllers Certification Level PCI-Express 2.0 IO Bus 1x4 6Gb/s SAS ports SAS Processor LSISAS2004 Internal Connectors Four x1 SATA External Connectors None Maximum Number of SCSI Devices LED Indicators Internal Activity/Fault per x4 port - Heartbeat LSI MegaRAID®...
  • Page 48 Internal Connectors Two SAS SFF8087 x4 External Connectors None Maximum Number of SCSI NOTE: HP Workstations do not support this many internal drives. Devices LED Indicators Connector LEDs indicate whether the internal connector is active for ports 0-3 and 4-7 DA - 13277 North America —...
  • Page 49 * WS4 not supported on Z200 & Z200 SFF Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation (64-bit and 32-bit) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 50 Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 51 Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 52 Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 53 Red Hat Enterprise Linux(RHEL) WS4 (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) 5 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 54 Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 55 Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or the latest HP qualified drivers are available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Power Consumption <75W...
  • Page 56 Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 57 Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 58 Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html...
  • Page 59 Genuine Windows Vista Business (64-bit and 32-bit) Drivers Microsoft Windows XP Professional (64-bit and 32-bit) Red Hat Enterprise Linux(RHEL) SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Power Consumption < 75W...
  • Page 60 Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 61 Red Hat Enterprise Linux (RHEL) 5 Desktop/Workstation (64-bit and 32-bit) Red Hat Enterprise Linux (RHEL) 6 Desktop/Workstation SUSE Linux Enterprise Desktop 11 (64-bit and 32-bit) HP qualified drivers may be preloaded or available from the HP support Web site: http://welcome.hp.com/country/us/en/support.html Novell SUSE Linux Enterprise drivers may also be obtained from: ftp://download.nvidia.com/novell...
  • Page 62 QuickSpecs HP Z600 Workstation Technical Specifications - Graphics Note AMD Eyefinity technology can support multiple displays using a single enabled AMD FirePro™ professional graphics card; the number of supported displays varies by card model. Microsoft® Windows® 7, Windows Vista®, or Linux® is required in order to support more than 2 displays.
  • Page 63 QuickSpecs HP Z600 Workstation Technical Specifications - Multimedia and Audio Devices SoundBlaster (Creative 24-bit Analog-to-Digital 96kHz sample rate Labs) X-Fi Titanium PCIe conversion of analog Audio Card inputs 24-bit Digital-to-Analog 96kHz to analog 7:1 speaker output conversion of digital sources 24-bit Digital-to-Analog 8, 11.025, 16, 22.05, 24, 32, 44.1, 48 and 96kHz...
  • Page 64 QuickSpecs HP Z600 Workstation Technical Specifications - Optical and Removable Storage HP DVD-ROM Drive Description 5.25-inch, half-height, tray-load Mounting Orientation Either horizontal or vertical Interface Type SATA/ATAPI Dimensions (WxHxD) 15.0 x 4.4 x 20.3 cm (5.9 x 1.7 x 8.0 in)
  • Page 65 No driver is required for this device. Native support is provided by the operating system. Kit Contents HP SATA SuperMulti DVD Writer Drive, Roxio Easy Media Creator software, Intervideo WinDVD Software, installation guide, and DVD+R media. DA - 13277 North America — Version 51 — November 21, 2013...
  • Page 66 QuickSpecs HP Z600 Workstation Technical Specifications - Optical and Removable Storage HP Slot Load DVD+/-RW Description Slim-Line, Slot-load Drive Mounting Orientation Either horizontal or vertical Interface Type SATA Dimensions (WxHxD) 12.7 x 1.2 x 12.9 cm (5 x 0.5 x 5 in)
  • Page 67 QuickSpecs HP Z600 Workstation Technical Specifications - Optical and Removable Storage Disc Formats BD-ROM BD-R BD-RE DVD-RAM DVD+R DVD+RW DVD+R DL DVD-R DL DVD-R DVD-RW CD-R CD-RW Disc Capacity DVD-ROM 8.5 GB DL or 4.7 GB standard Blu-ray 50 GB DL or 25 GB standard Full Stroke DVD <...
  • Page 68 * No driver is required for this device. Native support is provided by the operating system. ** RHEL WS4 not supported on Z200/Z200SFF Kit Contents HP Blue Laser RW Drive, Roxio Easy Media Creator software, Intervideo WinDVD Software, installation guide. Disclaimer...
  • Page 69 QuickSpecs HP Z600 Workstation Technical Specifications - Optical and Removable Storage HP 22-in-1 Media Card Description The Media Card Reader device uses the same physical form factor and mounting as a Floppy Disk Drive. The device connects to a 2x5 two-channel Reader USB header on the motherboard of the system.
  • Page 70 0.21 lb (95.0 g) Warranty The HP USB 3.0 2x2 Port Super Speed PCIe x1 Card has either a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed. Technical support is available seven days a week, 24 hours a day, by phone, as well as online support forums.
  • Page 71 The HP Super Speed USB 3.0 PCIe x1 Card has either a one-year limited warranty or the remainder of the warranty of the HP product in which it is installed. Technical support is available seven days a week, 24 hours a day, by phone, as well as online support forums.
  • Page 72 QuickSpecs HP Z600 Workstation Technical Specifications - Controller Cards http://www.windowsvista.com/upgradeadvisor. For Windows Vista system requirements, visit: http://www.windowsvista.com/systemrequirements. HP IEEE 1394b FireWire Data Transfer Rate Supports up to 800 Mbps PCIe Card Devices Supported IEEE-1394 compliant devices Bus Type PCIe card full height PCIe slots...
  • Page 73 QuickSpecs HP Z600 Workstation Technical Specifications - Networking and Communications Integrated Broadcom Connector RJ45 5764 PCIe LOM Controller Data Rates Supported 10/100/1000BT Bus Architecture PCIe X1 Alerting ASF 2.0 Broadcom (5761) Connector RJ-45 NetXtreme Gigabit Controller Broadcom 5761 PCI-Express LAN Controller...
  • Page 74 Novell SLED 10 & SLED 11 Management Capabilities WOL , PXE 2.1 Kit Contents HP NC360T PCI Express Dual Port Gigabit NIC, low profile bracket, CD containing Intel PROset II NIC drivers, quick install guide, product warranty statement DA - 13277 North America — Version 51 — November 21, 2013...
  • Page 75 HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
