Infrant Technologies ReadyNAS 1100 Getting Started Manual page 9

C
Backup Button and Front USB Port
1
The Backup Button is associated with the Front USB Port.
ReadyNAS
Backup Button
2
By default, the Backup Button copies the data on [backup] share of the ReadyNAS to the USB disk directly connected to this Front USB Port.
You can easily program the Backup Button in the FrontView Backup menu to backup one or more pre-defined backup jobs.
Backup
Backup Button Front USB Port
D
Access the System Module
3
1
2
1 Power off the unit , unscrew;
Backup USB Act
Front USB Port
USB
Act
1 2 3 4
2 Lift up the latch, and 3 Pull to slide the System Module out.
USB Hard Drive
3
1
2
ReadyNAS 1100 with the System Module sliding out
p8
