Infrant Technologies ReadyNAS 1100 Getting Started Manual page 7

RAID Configuration (continue...)
3
Factory Default Step-by-step
1 Make sure the device is power off.
Insert a paper clip or push pin to trigger the "System Reset" switch.
2
3 Depress the "System Reset" switch for 30 seconds while powering on the unit.
4 As an indication, the 4 disk LEDs will light up for 2 sec. at the 5th and the 30th sec.
As soon as the LEDs light at the 30th second, release the switch.
5
4
Select RAID Level and Volume Type in RAIDar
After the factory default, the RAIDar will prompt
1
"Click Setup" in the Info column.
A ReadyNAS Volume Setup screen pops up
2
after clicking the "Setup" button.
Select Expandable Volume (X-RAID) or Flexible
3
Volume (RAID 0,1,5), and click "Create Volume now"
to start the volume creation and initialization process.
If you take no action within 10 minutes the system will default to RAID 5
with 5GB reserved space for snapshots.
OFF
ON
p6
