Summary of Contents for Sennheiser EZX 60
-
Page 1: Bluetooth Headset
Bluetooth Headset ® EZX 60 Instruction manual... - Page 2 Quickguide EZX 60 Charging Power on/off Pairing Adjusting the volume 20 cm Vol + Pairing Vol – EZX 60 Phone Keyword Accepting and ending calls 0000...
-
Page 3: Table Of Contents
Operating elements ..................... 6 Overview of pictograms ..................7 Overview of buttons .................... 8 LED indications ..................... 9 Putting the EZX 60 into operation ..............10 Charging the headset battery ................. 10 Switching the headset on ..................11 Establishing Bluetooth connections ............... 11 Switching the headset off .................. -
Page 4: Important Safety Information
Before operation • Use the EZX 60 in dry places only and keep liquids and small electrically conductive parts away from the EZX 60 and its connecting sockets. • Do not expose the EZX 60 to extreme temperatures. Normal operating temperatures are 10°C (50°F) to 40°C (104°F). - Page 5 Keep the headset at least 1.2” (3 cm) from cardiac pace- makers or implanted defibrillators. Safety instructions for Lithium-Polymer rechargeable batteries The EZX 60 has a built-in Lithium-Polymer rechargeable battery. If abused or misused, rechargeable batteries may leak. In extreme cases, rechargeable batteries may even present •...
-
Page 6: Delivery Includes
Delivery includes Delivery includes 1 EZX 60 Bluetooth headset with built-in rechargeable Lithium-Polymer battery 1 earhook, flexible 1 EZX 60 power supply (EU/UK/US/AU version) 1 quick guide 1 safety guide... -
Page 7: Features Of The Ezx 60
Features of the EZX 60 Features of the EZX 60 • Flexible and removable earhook for easy wear • Can be worn on either left or right ear • Bluetooth 2.1 + EDR: compatible with all Bluetooth 1.1, 1.2, 2.0 and 2.1 devices that support the “hands free profile”... -
Page 8: Operating Elements
Operating elements Operating elements Multi-function button Socket for power supply » Earhook (flexible) Earpiece Microphone Volume down button Volume up button EZX 60 power supply (EU/UK/US/AU version) Charging plug... -
Page 9: Overview Of Pictograms
Overview of pictograms Overview of pictograms Meaning of the pictograms for pressing a button Pictogram Meaning Briefly press this button. Double-press this button. Keep this button pressed. Keep this button pressed for 5 seconds. Meaning of the pictograms for the flashing of the LED Pictogram Meaning This pictogram symbolizes a flashing. -
Page 10: Overview Of Buttons
Overview of buttons Overview of buttons Button To be pressed To ... Page accept an incoming call end a call voice dial* reject an incoming call transfer a call between headset and mobile phone* redial* mute/unmute the microphone switch the headset on or off 11/12 enter pairing mode increase the ring tone... -
Page 11: Led Indications
LED indications LED indications Meaning during operation LED flashing Meaning during operation rapidly Pairing mode once every 5 seconds Searching mode once every 5 seconds Standby mode 3 times every 4 seconds Call establishment twice every 4 seconds Active call mode For a more detailed description of the LED indications, see “Switching the headset on”... -
Page 12: Putting The Ezx 60 Into Operation
Putting the EZX 60 into operation Putting the EZX 60 into operation Charging the headset battery If you charge the battery for the first time, allow charging for at least 2.5 hours without interruption. Later, 2 hours will suffice to fully charge the battery. -
Page 13: Switching The Headset On
The headset is paired to a Bluetooth device and there is currently an active call. Establishing Bluetooth connections If the EZX 60 is not yet paired to any device, see “Pairing the headset“ on page 12. WARNING Danger of malfunction! The transmitted radio waves can impair the operation of sensitive and unprotected devices. -
Page 14: Switching The Headset Off
Putting the EZX 60 into operation If a certain Bluetooth connection cannot be established, because the corresponding Bluetooth device is switched off or out of range, you can manually re-establish the connection as follows: Switch off the Bluetooth visibility of all Bluetooth devices in the vicinity, except for the Bluetooth device you want to connect to. - Page 15 Once the headset is detected by the mobile phone, select “Sennheiser EZX 60” and connect. EZX 60 When the Bluetooth connection is successfully established, the headset is identified as “Sennheiser EZX 60” on the mobile phone Keyword display. 0000 When the mobile phone prompts a keyword, enter 4 zeros (”0000”).
-
Page 16: Using The Ezx 60
Using the EZX 60 Using the EZX 60 Wearing the headset WARNING Danger of accidents! The headset can draw off your attention and cause accidents. Do not wear the headset in an environment that requires your special attention (e.g. in traffic or when performing skilled jobs)! Switch the headset on (see page 11). -
Page 17: Calling
Using the EZX 60 Calling Provided the headset is switched on, paired and within the transmission range of a mobile phone (see page 12), you can accept and make calls with the EZX 60. Accepting a mobile phone call When you receive a call via your mobile phone and the headset is already... - Page 18 Using the EZX 60 Voice dialling* The voice dialling function must be supported by your mobile phone or Bluetooth device, supporting “hands free profile” (HFP) respectively, and be activated. Press the multi-function button Two ascending beeps are heard in the headset.
-
Page 19: Muting/Unmuting The Headset's Microphone
Using the EZX 60 Transferring an active call Double-press the multi-function button from the headset A low confirmation beep is heard in the headset. The call audio is trans- to the mobile phone* ferred to the mobile phone. The headset returns to standby mode. -
Page 20: Changing The Speaker Volume
Hearing damage due to high volumes! Listening at high volume levels for long periods can lead to permanent hearing defects. Please protect your hearing. Sennheiser headsets also sound exceptionally good at low volumes. Set the volume to a medium level. -
Page 21: If You Are Out Of The Transmission Range
Using the EZX 60 If you are out of the transmission range Calling is only possible in the Bluetooth transmission range of the mobile phone or Bluetooth device, respectively. The transmission range largely depends on environmental conditions such as wall thickness, wall compo- sition etc. -
Page 22: Cleaning And Maintaining The Ezx 60
Cleaning and maintaining the EZX 60 Cleaning and maintaining the EZX 60 CAUTION Liquids can damage the electronics of the device! Liquids entering the housing of the device can cause a short circuit and damage the electronics. Keep all liquids far away from the device. -
Page 23: Accessories
Accessories Accessories The following EZX 60 accessories are available from your specialist dealer: Cat. No. Accessory/spare part 504115 EZX 60 power supply, EU version 504116 EZX 60 power supply, UK version 504117 EZX 60 power supply, US version 504170 EZX 60 power supply, AU version... -
Page 24: Specifications
Operating relative humidity 20 to 85%, non-condensing −20°C (−4°F) to +60°C (140°F) Storage temperature range Storage relative humidity 10 to 95%, non-condensing EZX 60 power supply unit Nominal input voltage 100 to 240 V~ Nominal input current max. 0.2 A Mains frequency... -
Page 25: Manufacturer Declarations
Manufacturer declarations Manufacturer declarations Warranty regulations Sennheiser Communications A/S gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner. In compliance with the following requirements •... - Page 26 This Class B digital apparatus complies with Canadian ICES-003. Rechargeable batteries The supplied rechargeable batteries can be recycled. Please return them to your specialist dealer or to your Sennheiser partner. WEEE Declaration Your Sennheiser Communications product was developed and manu- factured with high quality materials and components which can be recycled and/or reused.
- Page 27 Sennheiser Communications A/S Publ. 12/09 Langager 6, 2680 Solrød Strand, Denmark www.sennheisercommunications.com...
