Location of Controls

21
20
19
18
17
16
1. LCD Panel
2. Speaker
3. Remote Sensor
4. Setup Button
5. Skip Buttons
,
( )
6. Play / Pause Button
7. Stop Button
8. Direction Buttons
( )
, , ,
9. Enter/Menu Button
10.
Disc Cover
11. Open Button
12. Power Switch
13.
Volume Control
3
11 10
14.
15.
16.
17.
18.
19. A/V Input Jack
20. USB Jack
21. SD Card
GB-6
1
2
4
5
6
7
8
9
Headphones Output Jack
DC IN :12V
S-Video Output
Line In/Out Switch Selector
N o t e : W h e n u s i n g t h e L I N E I N
setting of the selector switch,
the LCD screen will be blank if
there is no video input present
at the A/V Input Jack(16)
A/V Output Jack
15
14
13
12
