- Page 1 2 Portable LCD displays 7” ACVDS736 with built-in DVD player ALD1915H User manual Gebruiksaanwijzing NL 22 Manuel de l’utilisateur FR 43 Manual de instrucciones ES 64 DE 85 EL 107 DA 129...
-
Page 2: Table Of Contents
Table of contents Safety ................3 Intended use ..............3 Labels in this manual ............3 General safety instructions ..........4 Preparations for use ........... 4 Unpacking ................4 Package contents ............5 Installation ..............5 Connecting the units ............5 Connecting to a power source .........6 Remote control..............6 Functions .............. -
Page 3: Safety
ACVDS736 Safety Intended use The LCD display with built-in DVD player plays film and photos from DVD, USB and memory card. The game pad can be connected to play video games. The appliance also plays music from CD. Read the manual carefully before first use. -
Page 4: General Safety Instructions
General safety instructions WARNING Do not put force on the appliance. The appliance can fall and can cause serious injury. CAUTION Do not spill any liquid on the appliance. WARNING Do not insert any objects in the ventilation holes. CAUTION Do not block the ventilation holes. -
Page 5: Package Contents
ACVDS736 Package contents The following items are included in the received package: LCD display with built-in DVD player (master unit) LCD display (slave unit) Unit connection cable Remote control Battery (CR2025) Carrying bag Operator manual If any item is missing, please contact your reseller. -
Page 6: Connecting To A Power Source
Connecting to a power source Connecting to a car battery For this connection the 12 V adaptor + cable has to be used. ● Connect the adaptor plug of the adaptor cable to the DC IN 9-12 V connection in the master unit. ●... -
Page 7: Functions
ACVDS736 Functions Master unit OPEN button DC OUT 9-12 V connection SD/MS/MMC card slot DC IN 9-12 V connection Master power switch 10 ENTER button Headphone jack 11 Arrow buttons AV OUT connection 12 SOURCE button COAXIAL output 13 LCD display... -
Page 8: Slave Unit
Slave unit 14 Arrow buttons 18 DC IN 9-12 V connection 15 MODE button 19 AV IN connection 16 LCD display 20 Headphone jack 17 Volume dial 21 Master power switch... -
Page 9: Remote Control
ACVDS736 Remote control 22 STEP button 23 SEARCH button 24 Digit buttons (0-10+) 25 SUBTITLE button 26 ANGLE button 27 TITLE button 28 Arrow buttons 29 ENTER button 30 SETUP button 31 REPEAT button 32 SLOW button 33 PROGRAM button... -
Page 10: Operation
Operation All functions of the unit are accessible using the remote control. All instructions refer to operation with the remote control, unless indicated otherwise. Master power switch The units are equipped with a master power switch (3 & 21) located at the side panel. -
Page 11: Dvd/Cd Functions
ACVDS736 DVD/CD functions ● Switch on the units. Select the DVD mode. ● To insert a disc: • Press the OPEN button (1) to open the disc compartment. • Insert the disc with the label upwards. • Close the disc compartment. - Page 12 ● To stop playback temporarily, press the STOP button (42) once. To stop playback permanently, press the STOP button (42) again. To resume playback, press the PLAY/PAUSE button (43). ● To playback in slow-motion, either forward or backward, press the SLOW button (32) repeatedly.
- Page 13 ACVDS736 Using the SEARCH function The SEARCH function can be used to select a specific starting point on a DVD or CD. ● Press the SEARCH button (23). ● Press the digit buttons (24) to select an entry. The possible entries for DVD are:...
-
Page 14: Dvd Setup Menu Operation
Using the JPEG playback function ● Insert a JPEG disc. A content menu will display on the TV screen. ● Press the up/down arrow buttons (28) to select a folder or a file. Press the ENTER button (29) to start the slide show. ●... - Page 15 ACVDS736 General setup page ● TV DISPLAY to set the aspect ratio. The following settings are available: 4:3 PANSCAN, 4:3 LETTERBOX, 16:9, WIDE SQUEEZE. ● ANGLE MARK to display the angle setting information. Switch this function ON or OFF. ● OSD LANGUAGE to change the language. The following settings are available: ENGLISH, FRENCH, GERMAN, DANISH, SPANISH, DUTCH, GREEK.
- Page 16 Video setup page ● SHARPNESS: to adjust the screen sharpness. ● BRIGHTNESS: to adjust the screen brightness. ● CONTRAST: to adjust the screen contrast. ● HUE: to adjust the screen tint. This option is available for NTSC playback only. ● SATURATION: to adjust the saturation. Preference setup page The general system functions can only be set with an empty DVD player.
-
Page 17: Slave Setup Menu Operation
ACVDS736 Slave setup menu operation ● Press the MODE button (41) to enter the slave setup menu. Picture ● BRIGHT to set the brightness of the picture. ● CONTRAST to set the contrast of the picture. ● COLOR to set the colour of the picture. -
Page 18: Troubleshooting
Troubleshooting Trouble Action No sound or incomplete Check if the random equipment are switched on and set audio correctly. Check cables for connection problems. Check if the correct source is selected. Check volume or mute setting. No power Check if the power cord has been properly connected to the power outlet. - Page 19 ACVDS736 Picture distorted or noisy Disc may be damaged or dirty, clean the disc or try another disc. Check TV system setting (PAL/NTSC). Clean the disc. Picture not full screen Select the screen format from the unit's setup menu. Select screen format in disc start menu.
-
Page 20: Technical Data
Technical data DVD player Parameter Value Voltage 9-12 V Input voltage 100 ~ 240 V / 50 ~ 60 Hz Power consumption < 15 W Max. power output 2 x 1 W USB connection USB 2.0 compatible Flash memory connection SD/MS/MMC Dimensions (W x H x D) 260 x 182 x 37.5 mm... -
Page 21: Disposal Of Used Electrical And Electronic Equipment
For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.akai.eu...
