- Page 1 (9”) met usb-poort & omdraaischerm ACVDS9DD User manual GB Gebruiksaanwijzing NL Manual de l’utilisateur FR...
-
Page 2: Table Of Contents
Table of contents Safety ................3 Intended use ..............3 Labels in this manual ............3 General safety instructions ..........4 Preparations for use ........... 4 Unpacking ................4 Package contents ............5 Installation ..............5 Connecting random equipment ........6 Connecting to a power source .........7 Cordless operation ............7 Remote control..............7 Functions .............. -
Page 3: Safety
Safety Intended use The DVD Player plays film and photos from DVD, USB and memory card. The appliance also plays music from CD. Read the manual carefully before first use. DVDs and DVD appliances are manufactured under the worldwide agreed DVD regional code system that the appliance will operate only with corresponding disc of the same regional code. -
Page 4: General Safety Instructions
General safety instructions WARNING Do not put force on the appliance. The appliance can fall and can cause serious injury. CAUTION Do not spill any liquid on the appliance. WARNING Do not insert any objects in the ventilation holes. CAUTION Do not block the ventilation holes. -
Page 5: Package Contents
We recommend that you retain the original carton and packing materials in case it ever becomes necessary to return your product for service. This is the only way to safely protect the product against damage in transit. If you do dispose of the carton and the packing materials, please remember to recycle with due care to the environment. -
Page 6: Connecting Random Equipment
This appliance is equipped with rubber feet to prevent it from moving. The feet are made from non-migrating material specially formulated to avoid leaving any marks or stains on furniture. However, certain types of furniture polishes, wood preservatives or cleaning sprays cause the rubber to soften and leave marks or a residue on the furniture, and potentially risk the surface to become damaged. -
Page 7: Connecting To A Power Source
Connecting to a power source Connecting to the mains For this connection the AC/DC adaptor + cable has to be used. ● Connect the adaptor plug on the adaptor cable to the DC IN 9-12 V connection. ● Connect the mains plug to a wall socket. Cordless operation The appliance can also be operated cordless. -
Page 8: Functions
Functions DVD player 12 13 14 15 16 17 18 MENU button 10 Cover release switch SOURCE button 11 Disc compartment VOL- button 12 SD/MS/MMC card slot VOL+ button 13 USB slot ENTER button 14 Headphone jack Arrow buttons 15 AV OUT connection STOP button 16 COAXIAL connection SETUP button... -
Page 9: Remote Control
Remote control STEP MUTE SOURCE DISPLAY MENU SUBTITLE AUDIO /PBC TITLE ENTER MODE VOL- VOL+ SETUP SETUP REPEAT SLOW ZOOM 19 STEP button 33 FWD button 20 SEARCH button 34 PREV button 21 Digit buttons (0-10+) 35 NEXT button 22 SUBTITLE button 36 VOL- button 23 ANGLE button 37 VOL+ button... -
Page 10: Operation
The arrow buttons are buttons for navigation in the DVD menu. Operation All functions of the appliance are accessible using the remote control. All instructions refer to operation with the remote control, unless indicated otherwise. Quick start General functions ● To switch on the appliance, slide the ON/OFF switch (17) to the ON position. -
Page 11: Dvd/Cd Functions
USB functions (no disc in player) ● Switch on the appliance. ● Insert the USB device in the slot (13). The device can only be connected one way. ● Select the USB mode. ● To start playback, press the PLAY/PAUSE button (40) once. ●... -
Page 12: Using The Program Function
● To view a specific title of a DVD, press the TITLE button (24). Use the arrow buttons to select the title. ● To select the audio language of a DVD, press the AUDIO button (41) repeatedly until the desired language is set. ●... -
Page 13: Dvd Setup Menu Operation
Using the MP3/MPEG4 playback function ● Insert an MP3/MPEG4 disc. A content menu will display on the TV screen. ● Press the up/down arrow buttons (25) to select a folder or a file. ● Press the ENTER button (26) to enter the selected folder or file. ●... -
Page 14: Audio Setup Page
● Press the ENTER button (26) to store the setting. ● Press the SETUP button (27) to exit. General setup page ● TV DISPLAY to set the aspect ratio. The following settings are available: 16:9 (wide), 4:3 (letter box), 4:3 (pan scan). ●... -
Page 15: Cleaning And Maintenance
● AUDIO to set the audio language. ● SUBTITLE to set the subtitle language. ● DISC MENU to set the language for the disc menu. ● DEFAULT: Restore all default settings of the unit. Rating setup page ● PARENTAL: Set a rating for movies played by the appliance. The password to reset the rating is 1369. -
Page 16: Troubleshooting
Troubleshooting Trouble Action No sound or incomplete audio Check if the random equipment are switched on and set correctly. Check cables for connection problems. Check if the correct source is selected. Check volume or mute setting. No power Check if the power cord has been properly connected to the power outlet. -
Page 17: Usb Playback
No scan or skip possible Some discs are programmed to refuse user action at certain sections. This is no malfunction. Single chapter or track discs do not allow skip function. Picture distorted or noisy Disc may be damaged or dirty, clean the disc or try another disc. -
Page 18: Technical Data
Technical data DVD player Parameter Value Voltage 12 V Input voltage 100 ~ 240 V / 50 ~ 60 Hz Power consumption < 10 W Max. power output 2 x 1 W (RMS) USB connection USB 2.0 compatible Flash memory connection SD/MMC/MS Dimensions (W x H x D) 190 x 39 x 250 mm... -
Page 19: Disposal Of Used Electrical And Electronic Equipment
For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product. For more information and warranty conditions, please visit: www.akai.eu... - Page 20 Voor meer For more Pour plus informatie: information: d’information: www.akai.eu...
