Cisco TelePresence PrecisionHD 1080p12x Installing

Installing Cisco TelePresence PrecisionHD Camera - 1080p12x
1
This box contains: We recommend that you mount
the lens hood to prevent stray light
•
PrecisionHD 1080p 12X camera
from disturbing your video experience.
•
Lens hood
•
Power supply 12 V
dc
•
Mains power cable
•
HDMI cable (5 m / 16 ft)
•
VISCA camera control cable
(5 m / 16 ft), RJ45 to DB9
•
Daisy chaining cable, RJ11 to RJ45
EMC Class A declaration
声 明
此为A级产品，在生活环境中，该产品可能会造成无线电干扰。在这种
情况下，可能需要用户对其干扰采取切实可行的措施。
WARNING: This is a class A product. In a domestic environment this product may cause radio
WARNING: This is a class A product. In a domestic environment
interference in which case the user may be required to take adequate measures.
this product may cause radio interference in which case the user
may be required to take adequate measures.
The rear panel sockets
Extra Camera out and
for Daisy chaining
Power supply
Camera control
78-19791-02 PrecisionHD Camera - 1080p12x Installation Sheet | February 2013 | © 2010-2013 Cisco Systems, Inc. All rights reserved.
2
Turn the camera upside down to
check the video output format
setting. Alter the setting if needed.
Lens hood
Camera shown
with lens hood mounted.
DIP switch table for video formats
1 2 3
0 0 0
0 0 0
0 0 0
0 0 0
0 0 1
0 0 1
0 0 1
0 0 1
0 1 0
HDMI and HD-SDI can be
0 1 0
used simultaneously.
The table shows the different settings available for
the HDMI and the HD-SDI outputs.
HD-SDI out
Auto: Camera negotiates format over HDMI. HD-SDI
tracks HDMI and defaults to 1080p30 in absence of
HDMI sync.
Not used
Software: For more information about the
Software control setting, consult the VISCA™
HDMI Video out
commands in the PrecisionHD camera user guide.
3
Connect the camera to your codec. If you connect to a C-series codec, the power will be supplied
from the codec and the camera power supply will not be needed.
1
0
VISCA™ commands
DIP switch
The VISCA™ commands for controlling
the camera are described in the
PrecisionHD camera user guide.
VISCA™ is a trademark of Sony Corporation.
4 5 HDMI HD-SDI
0 0 Auto
0 1 1080p25 1080p25
1 0 1080p30 1080p30
Power supply connection
1 1 1080p50 720p50
is NOT needed when the
0 0 1080p60 720p60
camera is used with a
0 1 720p25 720p25
C-series codec.
1 0 720p30 720p30
1 1 720p50 720p50
0 0 720p60 720p60
Codec C40 is used for illustration only. The connectors may be placed differently on other codecs.
0 1 Software control
Page 1
HD-SDI socket
HDMI and HD-SDI
can be used simultaneously.
Camera control. RJ45 to RS 232.
VISCA™ protocol is supported.
Connect HDMI Video out on the camera to HDMI Main camera in on the codec.
