Dimensions; Recommended Installation; Recommended Water Usage; Disposer Mounting Assemblies - InSinkErator Model SS-1000 Specifications

DISPOSER MOUNTING ASSEMBLIES (choose one)
Bowl Mounts
Type A Sink Bowl Assembly: Includes bowl, water
nozzle(s), bowl cover, splash baffle
Type B Sink Bowl Assembly: Includes bowl, water
nozzle(s), silver guard, splash baffle
Type C Sink Bowl Assembly: Includes bowl, water
nozzle(s), splash baffle
Sink Bowl Assembly Size
12" (304.8 mm) with one adjustable water nozzle
15" (381.0 mm) with one adjustable water nozzle
18" (457.2 mm) with two adjustable water nozzles

DIMENSIONS

IMPORTANT: Use dimension chart below for adaptor height in place
of InSinkErator bowl sink height when mounting directly to a sink.
Bowl
Flange O.D.
Work Table Hole
Sinks X
12" 13-1/2"
(304.8 mm) (342.9 mm)
15" 16-1/2"
(381 mm) (419.1 mm)
18" 19-1/2"
(457.2 mm) (495.3 mm)
Adaptors X
7-13/16"
No. 6
(198.4 mm)
9-1/8"
No. 7
(231.8 mm) (200.0 mm)
NOTE:
• Adaptors are available upon request for all competitor
sink bowls or cones.
• Please have sink bowl/cone type with the necessary
dimensions when ordering adaptors.
• Also available as a short body model. Reduces overall
height of disposer by 3" (76.2 mm).
RECOMMENDED INSTALLATION
Flange I.D.
Y Z
12-1/4" 12"
(311.2 mm) (304.8 mm) (165.1 mm)
15-1/4" 15"
(387.4 mm) (381.0 mm) (165.1 mm)
18-1/4" 18"
(463.6 mm) (457.2 mm) (165.1 mm)
Y Z
6-7/8" 6-5/8" 1-3/16"
(174.6 mm) (168.3 mm) (30.2 mm)
7-7/8" 7-5/8"
(193.7 mm) (52.4 mm)
Collar Mounts
#6 Collar Adaptor for welding into trough, provides
6-5/8" (168.3 mm) opening, includes splash baffle
#7 Collar Adaptor for welding into sink, provides
6-5/8" (168.3 mm) opening, includes splash baffle
and stopper
Height
InSinkErator
6-1/2"
BOWL SINK
6-1/2"
6-1/2"
Height
23-3/4"
31-1/8"
2-1/16"
(603.3 mm
790.6 mm)
EXTERNAL ELECTRICAL
CONNECTIONS
X
Y
Z
6-5/8"
(168.3 mm)
7-1/8"
(181.0 mm)
1/2-14 N.P.T.
WATER INLET
TO
TO
8-3/4"
(222.3 mm)
8-3/4"
(222.3 mm)
ADJUSTABLE
LEGS
RECOMMENDED WATER USAGE
Standard
8 GPM
SS-300
(30.3 LPM)
8 GPM
SS-500
(30.3 LPM)
10 GPM
SS-750
(37.9 LPM)
10 GPM
SS-1000
(37.9 LPM)
For additional information, see
Foodservice Product Information Binder.
6-1/2"
(165.1 mm)
13"
(330.2 mm)
3" (76.2 mm)
N.P.T.
WASTE
OUTLET
Optional
7 GPM
(26.5 LPM)
7 GPM
(26.5 LPM)
N/A
N/A
