FOODSERVICE DISPOSER
Installation Manual
WARNING indicates a hazardous situation which, if not avoided, could result in
WARNING
death or seious injury.
CAUTION indicates a hazardous situation which, if not avoided, could result in
CAUTION
minor or moderate injury.
NOTICE is used to address practices related to physical injury
Please be certain that the person who installs or uses this appliance carefully reads
and understands the Safety Instructions contained in this manual.
www.insinkerator.com/foodservice
Part No. 13954 Rev. C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for InSinkErator SS-100

Summary of Contents for InSinkErator SS-100

  • Page 1 NOTICE is used to address practices related to physical injury Please be certain that the person who installs or uses this appliance carefully reads and understands the Safety Instructions contained in this manual. www.insinkerator.com/foodservice Part No. 13954 Rev. C...

  • Page 3: Table Of Contents

    Risk of Fire, Electrical Shock, or Injury to Persons......5 Installing the Disposer Disposer Mounting ................. 6 Standard InSinkErator Mountings Sink Bowl Mounting Assemblies ............ 7 Special InSinkErator Mountings ..............7 Plumbing Connections Drain Line Connections ..............8 Water Supply Connections ............8 Routing Water Flow ................. 8 Standard Motor Connection Wiring Diagrams ..........

  • Page 4: Introduction

    Introduction Read all warnings before proceeding. INTRODUCTION TYPICAL INSTALLATION The InSinkErator Foodservice food waste disposer is A typical Foodservice disposer installation incorporates and cUL Listed when installed in conjunction with the following connections (see Figures 1 and/or 9): ® ®...

  • Page 5: Instructions Pertaining To Risk Of Fire, Electrical Shock, Or Injury To Persons

    INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS IMPORTANT SAFETY INSTRUCTIONS NOTICE PERSONAL INJURY/PROPERTY DAMAGE PROPERTY DAMAGE If the electrical installer is not experienced in • Disposers shipped from factory are not wired electrical installation, we recommend seeking for a specific voltage.

  • Page 6: Installing The Disposer

    Installing the Disposer WARNING NOTICE PROPERTY DAMAGE PERSONAL INJURY To avoid excess vibration, InSinkErator • For safe operation, install the disposer in recommends a minimum countertop thickness compliance with the minimum distance illustrated of 16 gage stainless steel. in Figure 2.

  • Page 7: Standard Insinkerator Mountings

    Figure 5. #7 or Sink Bowl Mounting Assembly Special InSinkErator Mountings When installing an InSinkErator Foodservice disposer to any other mounting configurations, a special mounting adaptor kit is required. The special mountings are described in the Mounting Adaptor Selection Guide (for more infor- mation, call 1-800-845-8345, or go to www.insinkerator.com).

  • Page 8: Plumbing Connections

    NOTE: A syphon breaker must be installed above the is not experienced in plumbing installation, sink flood plane per local plumbing codes. InSinkErator recommends that competent professional assistance is sought. Damage to the disposer or accessories as a result of...

  • Page 9: Standard Motor Connection Wiring Diagrams

    Standard Motor Connection Wiring Diagrams NOTE: The diagrams below show standard motor connection wiring for a manual switch operation. For alternate controls, please refer to the control panel installation manual. MOTOR LEAD WIRE# MOTOR LEAD WIRE# Figure 10. Incoming 115V Single Phase Line Power Figure 11.

  • Page 10: Electrical Connections

    • The magnetic and manual starters supplied by voltage instructions. InSinkErator do not require heaters to complete the circuit. InSinkErator disposers are equipped with • Ensure the disposer motor voltage and phase overload protectors.

  • Page 11: Operating Instructions

    Operating Instructions OPERATING THE DISPOSER 1. Make sure there are no foreign objects in the disposer grind chamber. Do not pre-load the disposer with food waste prior to starting. 2. Push the start button on the control switch. The disposer will run and water will flow into the disposer. 3.

  • Page 12: Troubleshooting

    Press red reset button to reset overload protector. Never strike reset button with objects. 5. If disposer remains inoperative after following these steps, contact nearest InSinkErator Factory Authorized Service Center (call 1-800-845-8345 to find Service Center nearest you). Disposer motor stops while •...
  • Page 13 Notes...

  • Page 16: Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. InSinkErator® may make improvements and changes in the specification at any time, in its sole discretion, without notice or obligation and further reserves the right to change or discontinue models.
