GE MONOGRAM ZET857BBBB Specifications

Monogram. ™
ZET857BBBB - GE Monogram
Dimensions and Specifications (in inches)
23-1/2"
30"
28" min.
28-3/8 max.
47-5/8"
12"
24"
Must Support 300 lbs.
Specification Created 8/99
™ 30" Double Convection Wall Oven
Locate junction box above
or below cutout or through cabinet sides.
21-1/4"
22"
29-1/4"
2"x 4" or
Equivalent Runners
25"
30"
Cutout Dimensions:
Height 47-5/8" min.
Width 28" min.
Depth 23-1/2" min.
Cabinet depth required from front frame to inside rear
cabinet wall.
*Most 30" wall cabinets can be used with
this unit.
The opening between the inside walls must
be at least 28" wide.
48"
Allow minimum of 17-3/4" for clearance to adjacent
corners, drawers, walls, etc., when door
is opened.
Allow 3/4" for overlap of oven over side edges
of cutout.
Allow 1" for overlap and clearance of oven over top
of cutout and allow 1/4" at bottom for clearance.
Installation Information:
Before installing, consult installation instructions,
packed with the product, for current dimensional data
and for alternate installation options.
Monogram Built-In Convection Double Ovens require
a separate, properly grounded 3-wire 208/120 or
240/120 volt, 60Hz power supply, protected by a time
delay fuse or circuit breaker. Ovens are supplied with
a flexible power cable.
Convection double ovens are rated at 6.5 KW at 240
volts and 5.6 KW at 208 volts.
For answers to your Monogram,
GE Profile Performance Series,
GE Profile
GE Answer Center
47-3/4" max.
28-3/8" max.
®
™
™ or GE appliance questions, call
® service, 800.626.2000.
Listed by
Underwriters
Laboratories
R
