Model No. WATL16105.0
Serial No.
Serial Number Decal
QUESTIONS?
If you have questions, or if any
parts are missing or damaged,
PLEASE CONTACT OUR CUS-
TOMER SERVICE DEPARTMENT
DIRECTLY.
Call toll-free:
800-830-7240
E-mail:
service@goodfamily.cc
Goodfamily's Web site:
www.goodfamily.cc
ICON's Web site:
www.iconfitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Goodfamily is an authorized dealer of this treadmill in the ter-
ritory of mainland China. This treadmill is designed and man-
ufactured by ICON Health & Fitness, Inc.
Advertisement
Table of Contents
Related Manuals for Weslo Cadence A 40 Treadmill
Summary of Contents for Weslo Cadence A 40 Treadmill
- Page 1 Model No. WATL16105.0 Serial No. USER'S MANUAL Serial Number Decal QUESTIONS? If you have questions, or if any parts are missing or damaged, PLEASE CONTACT OUR CUS- TOMER SERVICE DEPARTMENT DIRECTLY. Call toll-free: 800-830-7240 E-mail: service@goodfamily.cc Goodfamily’s Web site: www.goodfamily.cc ICON’s Web site: www.iconfitness.com CAUTION...
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. . .Back Cover Note: A PART IDENTIFICATION CHART, an EXPLODED DRAWING, and a PART LIST are found at the end of this manual. WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 12. Failure to use a properly functioning surge that all users of this treadmill are adequately suppressor could result in damage to the con- informed of all warnings and precautions. - Page 4 22. Inspect and properly tighten all parts of the scribed in this manual. Never remove the treadmill regularly. motor hood unless instructed to do so by an authorized service representative. Servicing 23. Never drop or insert any object into any other than the procedures in this manual opening.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the WESLO ® A-40 treadmill. ing this manual, please see the front cover of this man- The A-40 treadmill combines advanced technology ual. To help us assist you, note the product model with innovative design to let you enjoy an excellent number and serial number before calling. -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not remove the long wire inside of the right handrail yet. In addition, do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. - Page 7 3. With the help of a second person, raise the Handrails (6, 7) so the Base (71) is flat on the floor. Attach the Wheels (15) to the outer sides of the Base (71) with two Wheel Bolts (14) and two Nuts (17). Do not overtighten the Nuts;...
- Page 8 6. Set the Console (1) on the Right Handrail (6) and the Left Handrail (not shown). Start four Console Screws (70) (only two are shown) into the Console. After you have started all four Console Screws, tighten them. Insert the excess Wire Harness (22) down into the Right Handrail (6).
-
Page 9: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT Your treadmill features a walking belt coated with high-performance lubricant. IMPORTANT: Never apply sili- cone spray or other substances to the walking belt or the walking platform. Such substances will deterio- rate the walking belt and cause excessive wear. HOW TO PLUG IN THE POWER CORD This product must be earthed. - Page 10 DIAGRAM OF THE CONSOLE Note: If there is a sheet of clear plastic Clip on the console, remove the plastic. Next, stand on the foot rails of the treadmill. Find the CAUTION: clip attached to the key (see the drawing above), and Before operating the slide the clip securely onto the waistband of your console, read the following precautions.
- Page 11 To stop the walking belt, press the Stop button. If When you are finished exercising, remove the the elapsed time is shown in the display (see step key from the console. 3), the time will begin to flash. Step onto the foot rails, press the Stop button, and Note: The first time the treadmill is used, observe remove the key from the console.
-
Page 12: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the metal frame firmly in the location shown by the arrow at the right. -
Page 13: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 14 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
-
Page 15: Conditioning Guidelines
CONDITIONING GUIDELINES is activity that requires large amounts of oxygen for prolonged periods of time. This increases the demand WARNING: Before beginning on the heart to pump blood to the muscles, and on the this or any exercise program, consult your lungs to oxygenate the blood. - Page 16 PART LIST—Model No. WATL16105.0 R0306A Key No. Qty. Description Key No. Qty. Description Console Reed Switch Clip Round Endcap Magnet Key/Clip Motor Belt Console Back Roller Adj. Bolt Electronics Screw Foot Rail Screw Right Handrail Front Roller/Pulley Left Handrail Right Foot Rail Hood Screw Frame Motor Tension Bolt...
- Page 17 Washer (29)–4 Star Washer (81)–4 2 3/4” Bolt (47)–4 Handrail Washer (11)–2 PART IDENTIFICATION CHART 4” Bolt (120)–2 Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Handrail Star Nut (17)–6 Handrail Washer (30)–2...
- Page 18 EXPLODED DRAWING—Model No. WATL16105.0 R0306A...
-
Page 19: Ordering Replacement Parts
When ordering parts, please be prepared to provide the following information: • the MODEL NUMBER of the product (WATL16105.0) • the NAME of the product (WESLO A-40 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
