JP969BH/CH/SH/WH – GE Profile
Cabinet Installation Dimensions (in inches)
13" MAX.
depth
30" MIN. to
unprotected
18" MIN.
1-1/2" MIN.
cabinet
to cabinet
clearance to
1-3/4" to
from cut-out
rear wall
1-3/4" MIN.
clearance to
side wall
from cut-out
Electrical junction
Cut should not interfere
box 16" MIN.
with cabinet structure
below countertop
at front
Specification Created 1/03
36" Built-In CleanDesign Cooktop
36"**
Cooktop
33-7/8"
side wall
2-1/2"
Required
**Depth of unit at conduit connection location (rear) is 6-1/4".
**Width and Depth of stainless model is 36-1/8" and 21".
KW Rating
240V
8.6
20-3/8"**
208V
6.5
3-1/4"*
Breaker Size
240V
36 Amps
208V
31 Amps
19-1/8"
Note: Check local codes for required breaker size.
Built-In CleanDesign Cooktops
Requires a 5" free area between the bottom of the cooktop to any combustible material, i.e.,
shelving. Free area not required when installing wall oven underneath cooktop. Refer to installation
instructions. Requires an 18" minimum from cooktop to adjacent overhead cabinets. Units
are furnished with a 48" flexible armored cable.
36" Ribbon cooktops are approved for use over GE 30" Single Wall Ovens and warming drawers.
Refer to cooktop and wall oven installation instructions packed with product for current
dimensional data.
Notes: If installing with a GE Profile Telescopic Downdraft System, consult both cooktop
and downdraft installation instructions packed with product before installing. Cooktop
gas/electric supply may need to be re-routed to install downdraft.
The countertop must be at least 26" deep with a flat surface area of 23-1/2" or more, front to
back. In addition, other clearances to the front edge of the countertop must be considered.
Note: Consult cabinet and countertop manufacturer's specs for flush mount installation
prior to install.
Flush Mount Installation Kit
Accommodates both 30" and 36" installations. Not for use with stainless steel models.
JXFLMBB (Black—use with black glass cooktops with a white, bisque or black pattern)
Installation Information:
Before installing, consult installation instructions packed with product for current
dimensional data.
Listed by
Underwriters
Laboratories
R
For answers to your Monogram,
GE Profile
®
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center
service, 800.626.2000.
®
or
