TIMER (DELAYED SWITCH ON / OFF) FUNCTION

This function mode enables a delayed switch ON or delayed switch OFF of the air conditioner.
The time (hours) delay can be set, enabled and disabled. The timer is adjustable between 1-24
hours.
SETTING SWITCH OFF TIMER
With the air conditioner operating in any function mode, press the Timer Control button. Then set
the desired time delay OFF hours by pressing the + or - buttons. When the delay time set has
elapsed, the air conditioner switches off.
SETTING DELAYED SWITCH ON TIMER
With the air conditioner is off, press the Timer Control button. Then set the desired time delay ON
hours by pressing the + or - buttons. When the delay time set has elapsed, the air conditioner
switches on.
AUTO RESTART
In the event of a power outage, the air conditioner restarts at the previously set function mode and
settings when power is restored.
NOISE LEVEL
Portable air conditioners may make sounds that are not familiar to you. The sounds listed below
are normal. Noise reflecting off hard surfaces such as a floor or wall can make the sounds seem
louder than they actually are.

The compressor may make a pulsating or high-pitched sound.

Water running from the evaporator to the water tank may make a splashing sound.

Refrigerant flowing may make a gurgling sound.

Fan sound may come from front and back air vents.

WATER DRAINAGE

During the process of cooling, some water will be extracted from the air into the unit. Most of this
water is used to cool and exhausted to the outside. If the unit is operated in high humidity or low
temperature environment, water will collect in the reservoir inside the unit. If the reservoir is full, the
compressor will stop. To continue the cooling function, please drain the water.
1. Turn off the unit.
2. Position a flat container or dish under the drain plug.
3. Remove the drain plug and the condensed water will drain out automatically.
4. Once all the condensed water is drained, replace the drain plug into the drain firmly.
CONTINUOUS DRAIN
For continuous drainage, install standard water hose to the upper drain port and place the open
end of the hose to a drain area. The outer diameter of water hose adaptor that will fit the upper
drain is 1 inch.
