CopyCentre 232 shown with
Duplex Automatic Document
Feeder, High Capacity Feeder
and Offset Catch Tray
CopyCentre/WorkCentre/WorkCentre Pro 232/238
OUTPUT SPEED – printing and copying
FIRST-IMAGE-OUT TIME (FCOT) – letter size, from platen to offset catch tray
COPYING
Document Scanner
Single Pass – Platen (available with CopyCentre and WorkCentre 232/238) or Duplex Automatic Document
Handler (DADH) option. Scans sizes up to 11 x 17 in. (A3/297 x 420 mm) SEF
Sides (input:output)
1:1, 1:2, 2:2 and 2:1
Quantity
1 to 9,999
Resolution
600 x 600 x 8 bit dpi input / 4800 x 600 dpi interpolated output
Concurrency*
Unlimited program-ahead consistent with configuration (Copy, Print, Fax and Scan)
Copy Pre-Collation
128 MB — CopyCentre / WorkCentre (expandable to 512 MB)
Memory (EPC)
384 MB — WorkCentre Pro (expandable to 512 MB)
WorkCentre 238 shown with
Duplex Automatic Document Feeder,
High Capacity Feeder and
Basic Office Finisher
Up to 32 and 38 ipm (images per minute)
8.5 x 11 in. (A4/210 x 297 mm)
Up to 25 ipm
8.5 x 14 in. (216 x 356 mm)
Up to 22 ipm
11 x 17 in. (A3/297 x 420 mm)
As fast as 4.5 seconds
CopyCentre
®
WorkCentre
232/238/245/255
WorkCentre 245 shown with
Duplex Automatic Document Feeder,
High Capacity Feeder and
Office Finisher
CopyCentre/WorkCentre/WorkCentre Pro 245/255
Up to 45 and 55 ipm (images per minute)
8.5 x 11 in. (A4/210 x 297 mm)
8.5 x 14 in. (216 x 356 mm)
11 x 17 in. (A3/297 x 420 mm)
As fast as 3.3 seconds
Copy Specifications
Copy Specifications
®
WorkCentre
232/238/245/255
232/238/245/255
Detailed Specifications
WorkCentre Pro 255 shown with
Duplex Automatic Document Feeder,
High Capacity Feeder, Professional
Finisher and Convenience Stapler/Shelf
Up to 36 ipm
Up to 31 ipm
* A minimum of 256 MB EPC memory required
®
Pro
Continued
1
Advertisement
Related Manuals for Xerox CopyCentre 232
Summary of Contents for Xerox CopyCentre 232
- Page 1 ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Detailed Specifications CopyCentre 232 shown with WorkCentre 238 shown with WorkCentre 245 shown with WorkCentre Pro 255 shown with Duplex Automatic Document Duplex Automatic Document Feeder, Duplex Automatic Document Feeder, Duplex Automatic Document Feeder,...
- Page 2 Interface to third-party access control devices, coin machines, card readers Foreign Device Interface (FDI) (Optional) Supports a variety of vending stations available through the Xerox Custom Application Service PC interface for upload/download of internal auditron data and Xerox Copier Assistant USB Port...
- Page 3 COPYING (Continued) Accessibility Option Xerox Copier Assistant (XCA) Software provides a PC-based alternative to the user interface touchscreen. Used in conjunction with a customer-supplied PC attached via the USB port, this software provides text-to-speech, screen magnification and easy PC keyboard access to basic and advanced copy features.
- Page 4 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Copy Specifications PAPER HANDLING – Bypass Tray Capacity* 100 sheets Sizes User Adjustable from 4.13 x 5.83 in. (105 x 148 mm) to 11 x 17 in. (A3/297 x 420 mm) Weights 16 lb to 57 lb bond/80 lb cover (60 to 216 gsm) Types...
- Page 5 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Copy Specifications OUTPUT OPTION – Office Finisher option Capacity* Top Tray — 250 sheets Stacking Tray — 2,000 sheets 4.25 x 5.5 in. (A6/105 x 148 mm) to 11 x 17 in. (A3/297 x 420 mm) Sizes 16 lb to 57 lb bond/80 lb cover (60 to 216 gsm) Weights...
- Page 6 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Print Specifications NETWORK PRINTING – SMart Controller (Simultaneous rip, receive, program ahead, queue processing, and transmit) 1.4 GHz AMD Athlon dedicated Processor WorkCentre 128 MB (expandable to 256 MB) Memory (ESS) WorkCentre Pro 256 MB System Disk 80 GB Hard Drive shared...
- Page 7 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Print Specifications NETWORK PRINTING – Print Driver Options (Continued) Special Pages Exception Page programming (covers, inserts/tabs, exception pages) Image Options Light/Dark Toner saver Resolution options (600 x 600 and 1200 x 1200 dpi) Reduction/Enlargement Margins (edge to edge printing) Invert Image (negative/mirror)
- Page 8 Font Management Utility for downloading additional fonts (available for Windows and Mac) Print Drivers Environment PCL6/5e PostScript 3 Windows 98/Me, NT 4.0, 2000/XP, Xerox custom graphical user interface Xerox custom graphical user interface Windows Server 2003, Windows Bi-directional features Bi-directional features Walk-up (PS), Microsoft Certified •...
-
Page 9: Device Management
Xerox Barcode Pro PS Enables intelligent PostScript printing on Xerox multifunction systems by storing Xerox software, as well as, the barcode fonts on the printer hard disk. Enables the printing of barcodes from any application (SAP R/3 client or mainframe) that (optional) supports PostScript printing. - Page 10 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Print Specifications CENTREWARE INTERNET SERVICES – Integrated device Web page Device Status Web server embedded on SMart Controller • Tray status/contents • Consumables status • Alerts Job-Print Queue Viewing Complete job print queue management –delete Job Submission Print ready files PS, PCL (TIFF, PDF with WorkCentre Pro only) Output feature selection (2-sided, staple, fold, hole punch, paper select)
- Page 11 • Scan to file • Scan to network server / directory • Scan to Mailbox* • Scan to Windows XP client via Windows Image Acquisition (WIA) or TWAIN driver downloadable from www.xerox.com Network Protocol Novell (NCP via IPX/SPX) Microsoft SMB via TCP/IP...
- Page 12 ScanSoft OmniPage Pro 15 Office (for desktop/client installation) Professional OCR software for digital archiving and document conversion Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox WorkCentre Pro to individual desktops. Also includes an email inbox polling capability...
- Page 13 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Fax Specifications FAX OPTIONS –Walk-up option (One or Two Lines options) Compatibility ITU (CCITT) Group 3 32MB (One Line) Memory 256MB (Two Line) Speed/Modem(s) 1 or 2 V.34 modems: 33,600bps. Less than 4 seconds per page transmission time, ISDN via third party adapter Compression/Speed MH/MR/MMR/G3/Super G3 Fax Send Features...
- Page 14 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Fax Specifications FAX OPTIONS - LAN Fax with Walkup Fax (Optional with WorkCentre and WorkCentre Pro) Driver based LAN fax for Windows and Macintosh users (PCL and PS drivers) Recipient options (add recipient or add from phone book) User personal phone book –...
- Page 15 One – or two-sided printing Fax Print Features Quantity Staple on/off Collate on/off Secure print on/off Finisher output tray selection (top tray or main tray) Multiple vendors, certified by the Xerox Business Alliance Partner Program. For details visit www.xerox.com Supported Network Fax Vendors Continued...
- Page 16 Various options available through Xerox Business Alliance Partner solutions. For details visit www.xerox.com Security enhancements with the addition of HTTPS protocol support...
-
Page 17: Xerox Extensible Interface Platform
Xerox EIP is a development platform that allows customers, Xerox Business Partners and System Integrators to build unique applications that are presented at the WCP 200 series user interface. Xerox EIP is an open standard platform that utilizes industry standard development tools enabling applications that are easily developed and customized to meet the needs of any business environment or personalized for each user. -
Page 18: Basic Configurations
Image Overwrite Security (standard feature in North America) USB 2.0 / (IEEE1284) Parallel Port Kit FreeFlow Scan to PC Desktop SE and Professional Internet Fax Enablement for Fax/Scan/Accounting Xerox Business Alliance Partner solutions Common Criteria Certified Software Level Common Criteria Kit (US only) Continued... - Page 19 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Machine Specifications ELECTRICAL REQUIREMENTS 110-140 Volt Nominal, 60 Hz, 15A (North America) 220-240 Volt Nominal, 50 Hz, 10A (Europe) Note: Convenience Stapler requires separate 110V 15A circuit POWER CONSUMPTION 232/238 CopyCentre 232/238 WorkCentre/WorkCentre Pro 245/255 CopyCentre 245/255 WorkCentre/WorkCentre Pro...
- Page 20 CopyCentre ® WorkCentre ® WorkCentre ® 232/238/245/255 232/238/245/255 232/238/245/255 Machine Specifications SPACE REQUIREMENTS (Fixed) Width Depth Height CopyCentre 104 in. /2,650mm Configuration With OCT 116 in. / 2,955 mm 78 in. / 1,981 mm WorkCentre/ WorkCentre Pro 107 in. /2,710mm CopyCentre 104 in.
-
Page 21: Machine Specifications
Pro and Copier Assistant are trademarks of Xerox Corporation in the United States and/or other countries. PostScript is a registered trademark of Adobe Systems Incorporated in the United States and/or other countries. Other marks are trademarks or registered trademarks of the companies with which they are associated. In support of Xerox’s environmental leadership goals, these models may contain some recycled components that are reconditioned.
