REPAIR
PARTS
LIST
253.28459806
For Parts or Service:
Call
P08F0134.eps P08D0615.eps P08C1200.eps P08S0422.eps
1-800-4-MY-HOME
(1-800-469-4663)
Or Visit
www.sears.com
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A
UPRIGHT FREEZER
In all orders or correspondence, avoid delays and misunderstandings
by always giving the complete model number shown on the left side of
the access panel.
All repair parts listed are available for immediate purchase or special
order when you visit your nearest Sears Parts & Repair Center, or the
Service Department at most Sears stores. To order parts by phone, call
the toll-free number listed to the left or visit sears.com.
When requesting service or ordering parts, always provide the following
information:
®
• Product Type
• Model Number
Publication number 5995549218
• Part Number
• Part Description

Advertisement

Table of Contents
loading

  Related Manuals for Electrolux 253.28459806

  Summary of Contents for Electrolux 253.28459806

  • Page 1 REPAIR PARTS LIST 253.28459806 UPRIGHT FREEZER In all orders or correspondence, avoid delays and misunderstandings by always giving the complete model number shown on the left side of the access panel. All repair parts listed are available for immediate purchase or special order when you visit your nearest Sears Parts &...
  • Page 2 253.28459806 DOOR CAUTION: Use the Kenmore part number to order part, not the illustration number. P08D0615 08/09...
  • Page 3 253.28459806 DOOR CAUTION: Use the Kenmore part number to order part, not the illustration number. POS. NO PART NO. DESCRIPTION 216522307 Gasket-door, black 297213400 Lock Assy 297213300 Clip, spring 297147700 Key, lock 216527615 Panel-inner door, frzr 297316307 Panel-outer door, black...
  • Page 4 253.28459806 CABINET CAUTION: Use the Kenmore part number to order part, not the illustration number. 137B P08C1200 08/09...
  • Page 5 253.28459806 CABINET CAUTION: Use the Kenmore part number to order part, not the illustration number. POS. NO PART NO. DESCRIPTION 216503100 Screen-drain 216325600 Fan Blade 297200300 Breaker Kit w/corners, no lock slot 297200500 Breaker Kit w/corners, incl lock catch 297200200 Breaker Kit w/corners, 28", top and bottom...
  • Page 6 253.28459806 SYSTEM CAUTION: Use the Kenmore part number to order part, not the illustration number. 08/09...
  • Page 7 253.28459806 SYSTEM CAUTION: Use the Kenmore part number to order part, not the illustration number. POS. NO PART NO. DESCRIPTION 5300123788 Condenser 5308000110 Strap-evap/heater, aluminum, (2) 216987500 Drier-filter 297237601 Harness-main 240555002 Screw-#8-32 X 3/8 297216201 Heater-defrost 15 # 216997200 Evaporator...
  • Page 8 Get it fixed, at your home or ours! Your Home For expert troubleshooting and home solutions advice: www.managemyhome.com For repair – in your home – of all major brand appliances, lawn and garden equipment, or heating and cooling systems, no matter who made it, no matter who sold it! For the replacement parts, accessories and owner’s manuals that you need to do-it-yourself.
