Summary of Contents for Pro-Form 510 E Elliptical

Page 1 Model No. PFEL05811.5 Serial No. USER’’S MANUAL Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.proformservice.com/ registration. CUSTOMER CARE For service at any time, go to www.proformservice.com.
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. PROFORM is a registered trademark of ICON IP, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
Page 5 STANDARD SERVICE PLANS...
Page 6: Before You Begin
Thank you for selecting the revolutionary PROFORM ® manual. To help us assist you, note the product model 510 E elliptical. The 510 E elliptical provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.
Page 7: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.
Page 8: Assembly
ASSEMBLY •• To hire an authorized service technician to •• To identify small parts, see page 7. assemble this product, call 1-800-445-2480. •• In addition to the included tool(s), assembly •• Assembly requires two persons. requires the following tools: one Phillips screwdriver ••...
Page 9 2. With the help of a second person, place some of the packing materials (not shown) under the rear of the Frame (1). Have the second person hold the Frame to prevent it from tipping while you complete this step. Attach the Rear Stabilizer (2) to the Frame (1) with two M10 x 122mm Screws (104) and two M10 Split Washers (105).
Page 10 4. With the help of a second person, place some of the packing materials (not shown) under the front of the Frame (1). Have the second per- son hold the Frame to prevent it from tipping while you complete this step. Attach the Front Stabilizer (6) to the Frame (1) with two M10 x 122mm Screws (104) and two M10 Split Washers (105).
Page 11 6. Tip: Avoid pinching the Upper Wire (110). Avoid damaging the indicated plastic tabs. Set the Upright (4) on the Frame (1). Avoid pinching the Upper Wire (110) and avoid damaging Attach the Upright (4) with four M10 x 25mm the tabs Screws (92) and four M10 Split Washers (105).
Page 12 8. Identify the Right Upper Body Arm (61) and ori- ent it as shown. Slide the Right Upper Body Arm (61) onto the Right Upper Body Leg (60). Attach the Right Upper Body Arm (61) with two M8 x 38mm Bolts (96) and two M8 Locknuts (102).
Page 13 10. Tip: Avoid pinching the wires. Attach the Console (7) to the Upright (4) with four M4 x 16mm Screws (101). Avoid pinching the wires 11. Identify the Right Pedal Arm (58) and orient it as shown. Attach a Pedal (49) to the Right Pedal Arm (58) with four M6 x 12mm Screws (103).
Page 14 12. Orient the Right Pedal Arm (58) as shown. Apply grease to the axle on the Right Pedal Arm (58). Attach the Right Pedal Arm (58) to the Right Roller Arm (59) with an M8 x 13mm Screw (82), a Small Axle Cover (55), and an M8 Washer (97).
Page 15 14. Orient the Rear Upright Cover (81) as shown. Attach the Rear Upright Cover (81) to the Upright (4) with four M4 x 16mm Screws (101). Orient the Front Upright Cover (117) as shown. Attach the Front Upright Cover (117) around the Upright (4) by pressing the hooks on the Rear Upright Cover (81) onto the tabs on the Front Upright Cover.
Page 16 16. Identify the Right Upper Body Leg Inner Cover (83) and orient it as shown. Attach the Right Upper Body Leg Inner Cover (83) to the Right Upper Body Leg (60) with an M4 x 16mm Screw (101) and an M5 Washer (32).
Page 17 18. Orient the Rear Console Cover (80) as shown. Attach the Rear Console Cover (80) to the Upright (4) with two M4 x 16mm Screws (101). Orient the Front Console Cover (79) as shown. Attach the Front Console Cover (79) around the Upright (4) by pressing the hooks on the Rear Console Cover (80) onto the tabs on the Front Console Cover.
Page 18: How To Use The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER ADAPTER HOW TO LEVEL THE ELLIPTICAL IMPORTANT: If the elliptical has been exposed to If the elliptical rocks cold temperatures, allow it to warm to room tem- slightly on your perature before you plug in the power adapter.
Page 19 HOW TO EXERCISE ON THE ELLIPTICAL To mount the elliptical, hold the handlebars or the Upper upper body arms and step onto the pedal that is in the Body Arms lower position. Then, step onto the other pedal. Push the pedals until they begin to move with a continuous motion.
Page 20 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you use the manual mode of the console, you can change the resistance of the pedals with the touch of a button.
Page 21 HOW TO USE THE MANUAL MODE Distance (Dist.)——This display mode will show the distance that you have pedaled in miles or 1. Begin pedaling or press any button on the kilometers. console to turn on the console. Pulse——This display mode will show your heart rate When you turn on the console, the display will turn when you use the handgrip heart rate monitor (see on.
Page 22 Press the Home button to return to the default When your pulse is detected, a heart symbol in the menu (see HOW TO CHANGE CONSOLE calorie display will flash each time your heart beats, SETTINGS on page 25 to set the default menu). one or two dashes will appear, and then your heart If necessary, press the Home button again.
Page 23 HOW TO USE AN ONBOARD WORKOUT As you exercise, you will be prompted to keep your pedaling speed near the target speed for the 1. Begin pedaling or press any button on the current segment. When an upward-pointing arrow console to turn on the console. appears in the display, increase your pace.
Page 24 HOW TO USE AN IFIT WORKOUT When you select an iFIt workout, the display will show the duration of the workout and the approxi- Note: To use an iFIt workout, you must have an mate number of calories you will burn. The display optional iFIt module.
Page 25 HOW TO USE THE SOUND SYSTEM 5. Determine if an iFIt module is connected to the console. To play music or audio books through the console sound system while you exercise, plug your audio If an iFIt module is connected to the console, the cable into the jack on the console and into a jack on display will show the words WIFI MODULE or USB your MP3 player or CD player;...
Page 26: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 27: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING I nspect and tighten all parts of the elliptical regularly. Note: For clarity, the left shield is shown removed in the Replace any worn parts immediately. drawing below. To clean the elliptical, use a damp cloth and a small Next, locate the Reed Switch (38).
Page 28 HOW TO ADJUST THE DRIVE BELT See EXPLODED DRAWING C on page 35. Remove the M4 x 19mm Screws (5) and the M4 x 48mm Screw If the pedals slip while you are pedaling, even while (107) from the Left and Right Shields (73, 74). Then, the resistance is adjusted to the highest level, the drive remove the Right Shield.
Page 29: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat——To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 30 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 31: Part List
PART LIST Model No. PFEL05811.5 R1112B Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Pedal Arm Rear Cap Ramp Large Axle Cover Upright 16mm Wave Washer M4 x 19mm Screw Small Axle Cover Front Stabilizer Roller Arm Bushing Console Arm Bearing Left Handlebar...
Page 32 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw M4 x 19mm Self-tapping Screw M8 Locknut Drive Belt M6 x 12mm Screw M4 x 42mm Screw M10 x 122mm Screw M4 x 30mm Screw M10 Split Washer Disc Ring Cover Mount Front Upright Cover...
Page 33: Exploded Drawing
EXPLODED DRAWING A Model No. PFEL05811.5 R1112B...
Page 34 EXPLODED DRAWING B Model No. PFEL05811.5 R1112B...
Page 35 EXPLODED DRAWING C Model No. PFEL05811.5 R1112B...
Page 36: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
