IP200 MiniDome In-Ceiling Mount
NDA-FMT200-DOME
en
Installation Manual

Advertising

   Summary of Contents for Bosch NDA-FMT200-DOME

  • Page 1

    IP200 MiniDome In-Ceiling Mount NDA-FMT200-DOME Installation Manual...

  • Page 3: Table Of Contents

    Table of Contents | en Table of Contents Safety Safety precautions Unpacking Parts List Installation Overview Installing a Recessed Mount Overview Installing the Recessed Mount Installing the Camera to the Recess Mount Connection Bosch Security Systems Installation Manual AM18-Q0626 | v1.0 | 2012.09...

  • Page 4: Safety, Safety Precautions

    This symbol indicates information or a company policy that relates directly or indirectly to the safety of personnel or protection of property. This manual is the intellectual property of Bosch Security Systems and is protected by copyright. All rights reserved. Contact: www.boschsecurity.com AM18-Q0626 | v1.0 | 2012.09...

  • Page 5: Unpacking, Parts List

    Verify that all the parts listed in the applicable Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service.

  • Page 6: Installation Overview

    Camera Ring A NDN-265-PIO Ring B NDC-225-P NDC-225-PI NDC-255-P NDC-265-P The installation should be made by qualified installation personnel and conform to the National Electrical Code and applicable local codes. AM18-Q0626 | v1.0 | 2012.09 Installation Manual Bosch Security Systems...

  • Page 7: Installing A Recessed Mount, Overview, Installing The Recessed Mount

    Installing the Recessed Mount To mount to a recess mount, do the following: Determine a secure location for the recessed mount. 194 (7.64) Figure 4.1 Recess Mount Dimensions Bosch Security Systems Installation Manual AM18-Q0626 | v1.0 | 2012.09...

  • Page 8

    41.7 mm (1.64 in.) maximum ceiling thickness and 9.7 mm (0.38 in.) minimum ceiling thickness). AM18-Q0626 | v1.0 | 2012.09 Installation Manual Bosch Security Systems...

  • Page 9

    Installing a Recessed Mount | en Figure 4.3 Attach Recess Mount to Ceiling Figure 4.4 Attach Recess Mount to Ceiling Tighten both clamps to the ceiling using supplied screws and a #2 Phillips screwdriver. Bosch Security Systems Installation Manual AM18-Q0626 | v1.0 | 2012.09...

  • Page 10

    Only tighten the clamp until it contacts the ceiling and you start to feel some resistance. If using a power screwdriver, set the torque level to the lowest setting. AM18-Q0626 | v1.0 | 2012.09 Installation Manual Bosch Security Systems...

  • Page 11: Installing The Camera To The Recess Mount

    Figure 4.6 Match Connectors Cable out Attach the camera to the recess mount by removing the upper housing/bubble from the camera (use the wrench supplied with the camera), and attaching the camera base Bosch Security Systems Installation Manual AM18-Q0626 | v1.0 | 2012.09...

  • Page 12

    Align the two mounting screws attached to the trim ring with the two mounting holes in the recess mount. AM18-Q0626 | v1.0 | 2012.09 Installation Manual Bosch Security Systems...

  • Page 13

    Installing a Recessed Mount | en Figure 4.8 Align Trim Ring Fit the plastic trim ring. Use the supplied T-10 Torx wrench to secure the trim ring’s two safety locking screws to the mounting bracket. Bosch Security Systems Installation Manual AM18-Q0626 | v1.0 | 2012.09...

  • Page 14: Connection

    To prevent humidity problems, the camera must be installed in dry conditions, and the cable leads should be sealed once connected. Please refer to the IP200 Minidome series User Manual for further instructions on camera connections and configuration. AM18-Q0626 | v1.0 | 2012.09 Installation Manual Bosch Security Systems...

  • Page 16

    Bosch Security Systems www.boschsecurity.com © Bosch Security Systems, 2012...
