DIMENSIONS INCHES (MM)
A Overall width of cooktop
B Overall depth of cooktop
C Height of chassis (below top of counter)
D Width of chassis
E
Depth of chassis
F
Overall height of product (including retracted dials/pan supports)
Product dimensions and specifications are listed as a guide only. For complete installation instructions and specifications, refer to the product Use & Care Guide/Installation Instructions available at www.fisherpaykel.com
COOKSURFACE DIMENSIONS
CG363MLDNGB1, CG363MLNGB1
B
D
A
CG363MLNGB1
33 11⁄ 1 6"
1.888.936.7872
E
CG363MLDNGB1
35 ½"
(900)
35 ½"
16 ⅛"
(410)
20 ⅞"
3 ½"
(89)
3 ½"
(856)
33 11⁄ 1 6"
15 ⅛"
(384)
18 ⅞"
3 ¾"
(96)
3 ¾"
F
(900)
(530)
(89)
(856)
(480)
(96)
