Installation, Start-Up, and Operating Instructions
For Sizes 040-140, Series 140 (LIMITED)
DIMENSIONAL DRAWING........................................................2
SAFETY CONSIDERATIONS .....................................................3
Clearances to Combustibles......................................................3
INTRODUCTION ..........................................................................4
APPLICATIONS ......................................................................5-12
General ......................................................................................5
Upflow Applications..............................................................5-7
Downflow Applications.........................................................7-8
LOCATION ............................................................................12-13
General ....................................................................................12
Hazardous Locations...............................................................13
INSTALLATION....................................................................13-17
Leveling Legs (If Desired) .....................................................13
Installation In Horizontal Applications ..................................15
Filter Arrangement..................................................................16
Bottom Closure Panel.............................................................16
Gas Piping..........................................................................16-17
AIR DUCTS............................................................................17-18
General Requirements.............................................................17
Ductwork Acoustical Treatment.............................................18
Supply Air Connections..........................................................18
Return Air Connections ..........................................................18
ELECTRICAL CONNECTIONS...........................................18-19
115-v Wiring......................................................................18-19
24-v Wiring.............................................................................19
Accessories..............................................................................19
DIRECT VENTING ...............................................................19-29
Common Vent Systems................................................19-21
Combustion-Air and Vent Piping .....................................21-27
Kit Installation ...................................................................28
Multiventing and Vent Termination.......................................28
CONDENSATE DRAIN ........................................................30-32
General ....................................................................................30
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 101
Catalog No. 535-758
Tab 6a 8a
4-Way Multipoise Fixed-Capacity
Direct-Vent Condensing Gas Furnace
A93040
As an ENERGY STAR®
Partner, Carrier Corpora-
tion has determined that
Page
this product meets the EN-
ERGY STAR® guidelines
for energy efficiency.
AIRFLOW
Application ..............................................................................30
Condensate Drain Protection ..................................................32
SEQUENCE OF OPERATION..............................................32-34
Heating Mode..........................................................................32
Cooling Mode .........................................................................32
Continuous Blower Mode.......................................................33
Heat Pump Mode ....................................................................33
Component Test ......................................................................33
START-UP PROCEDURES ..................................................34-42
General ....................................................................................34
Prime Condensate Trap With Water ......................................34
Purge Gas Lines......................................................................34
Adjustments .......................................................................35-42
Set Gas Input Rate ............................................................35-41
Set Temperature Rise ........................................................41-42
Blower Off Delay (Heat Mode) .............................................42
Set Thermostat Heat Anticipator............................................42
CHECK SAFETY CONTROLS..................................................42
Check Primary Limit Control.................................................42
Check Pressure Switch ...........................................................42
CHECKLIST ................................................................................43
Printed in U.S.A.
Form 58MCA-7SI
ama
REGISTERED QUALITY SYSTEM
AIRFLOW
UPFLOW
HORIZONTAL
LEFT
DOWNFLOW
AIRFLOW
Fig. 1-Multipoise Orientations
Pg 1
58MCA
CERTIFIED
HORIZONTAL
RIGHT
AIRFLOW
A93041
1-00
Replaces: New
