Port Assignment Menu - Gateway MULTIMEDIA NOTEBOOK SYSMAN017AAUS User Manual

Option Function
Disable shuts off password protection select (can only be selected if password is currently
Enables turns on password protection
Change changes password

Port Assignment Menu

Option
Serial Port
IR Port
Parallel Port
Parallel IRQ
Parallel Port
General Audio
Audio Base Port
Audio and MIDI IRQ select; press Spacebar to toggle between: IRQ5; IRQ2; IRQ10; IRQ5 &IRQ2;
PC Speaker Audio
Audio DMAC
MPU-401 Base Port select; press Spacebar to toggle between: 300h; 320h; 330h; or DISABLED.
To Change
select; press Spacebar to toggle between:
COM1; COM2; COM3; COM4; or DISABLED.
select; press Spacebar to toggle between:
COM1; COM2; COM3; COM4; or DISABLED.
select; press Spacebar to toggle between: LPT1; LPT2; LPT3; or DISABLED.
select; press Spacebar to toggle between: IRQ5or IRQ7.
select; press Spacebar to toggle between: AT or BI-DIRECTIONAL.
select; press Spacebar to toggle between: ENABLED or DISABLED.
select; press Spacebar to toggle between: 220h; 230h; or 240h.
IRQ5 & IRQ11; IRQ10 & IRQ2; or IRQ10 & IRQ 11.
select; press Spacebar to toggle between: ENABLED or DISABLED.
select; press Spacebar to toggle between: DMA0 or DMA1.
To Change
enabled); press Enter; type old password; press Enter.
select (can only be selected if password is currently
disabled); press Enter; type new password, press En-
ter; type new password again; press Enter.
select (can only be selected if password is currently
enabled); press Enter; type old password, press Enter;
type new password, press Enter; type new password
again; press Enter.
This menu allows you to designate port assignments for
the system. Access this menu from the Main Setup Menu
(See page 25.)
The following chart details the process for setting the
Port Assignment Menu options. (After setting options,
the screen automatically returns to the Main Setup Menu.):
User's Guide 27
