4
Plug the speaker bar's power and audio plugs into the appropriate connectors underneath
the monitor.
Power
connector
5
Plug the speaker bar's pink and green 3.5 audio plugs into the appropriate speaker and
microphone connectors on the computer.
Important
For best audio performance use an HDMI connection. The digital audio is
conveyed along the same cable as the digital video, and no additional audio
connection is required. You may need to set your video source's audio mode to PCM
or ANALOG to hear the audio. See your source device's user guide for more
information.
For information on using the speaker bar, see
To remove the speaker bar:
1
Disconnect all audio and power cables from the speaker bar.
2
Press the two clips on the back of your monitor, then slide the speaker bar back.
Mounting clip
www.gateway.com
Audio jack
"Using the speaker bar" on page 14.
