Summary of Contents for Gateway 22-inch Widescreen LCD Monitor
- Page 1 22-inch Widescreen LCD Monitor USERGUIDE ®...
-
Page 3: Table Of Contents
Contents Using Your Gateway Flat-Panel Monitor ......1 Connecting the monitor ........... . 2 Connecting video inputs . - Page 4 Contents...
-
Page 5: Using Your Gateway Flat-Panel Monitor
Using Your Gateway Flat-Panel Monitor • Connecting the monitor • Starting the monitor • Adjusting monitor settings • Changing Windows screen settings • Power management • Maintaining • Troubleshooting • Specifications... -
Page 6: Connecting The Monitor
Using Your Gateway Flat-Panel Monitor Connecting the monitor To set up the monitor, first unpack the box, unwrap the components, then make your cable connections. Connecting video inputs To connect video sources to your monitor: Position your computer and the monitor so you can reach the back of each. -
Page 7: Connecting A Security Cable
Kensington lock slot Setting up the optional speaker bar An optional speaker bar is available for mounting underneath your monitor. In the United States, you can order a speaker bar from www.gateway.com. To install the speaker bar: Turn off the monitor. - Page 8 Using Your Gateway Flat-Panel Monitor Slide the speaker bar onto the bottom of the monitor until it snaps into place. Make sure that it is secure by pulling it downward. Mounting slot Mounting clip Plug the speaker bar’s power plug into the power connector on the monitor.
-
Page 9: Starting The Monitor
Plug the speaker bar’s audio plug into the audio jack on your monitor. Important For best audio performance, if your video connection uses HDMI, the digital audio is also conveyed along the same cable, and no additional audio connection is required. -
Page 10: Adjusting Monitor Settings
Using Your Gateway Flat-Panel Monitor Adjusting monitor settings Use the monitor controls (located on the monitor itself) and computer controls (accessible through Windows) to adjust the display image. For more information about computer controls, see “Changing Windows screen settings” on page... -
Page 11: Using The Main Menu
Using the main menu To use the main menu: Touch Menu on the front of your monitor. The rest of the button icons light up and the shortcut menu opens. To use a button, lightly touch its icon. For adjusting a setting’s values, you can touch and hold touch buttons as you would conventional buttons. - Page 12 Using Your Gateway Flat-Panel Monitor OSD Menu Description PIP Settings menu PIP Display—Toggles the display of the PIP window. Source—Sets the source of the video used in the PIP window. Position—Sets the position of the PIP window on the main screen.
-
Page 13: Using Picture-In-Picture (Pip)
OSD Menu Description Geometry menu H Position—Moves the display image left and right. (VGA mode only) V Position—Moves the display image up and down. Clock—Minimizes any vertical bars or stripes visible on the screen background. The horizontal screen size will also change. -
Page 14: Changing Windows Screen Settings
Using Your Gateway Flat-Panel Monitor Changing Windows screen settings Adjusting the color depth and screen area are two of the most basic display settings you may need to change. You can also adjust settings such as the screen background and screen saver. -
Page 15: Eztune Software
With EzTune, you can: • Change the orientation of the image (landscape to portrait). (Requires the optional height-adjustable stand available in the United States at www.gateway.com.) • Change brightness, contrast, and color balance •... -
Page 16: Power Management
Using Your Gateway Flat-Panel Monitor Power management Energy declaration When connected to a computer that supports the VESA Display Power Management Signaling (DPMS) Protocol, the monitor can conserve significant energy by reducing power consumption during periods of non-use. When your computer goes into the energy saving mode, the monitor will then enter the Active Off mode (sleep). -
Page 17: No Picture
No picture • Touch Menu, then Input Select to make sure that you have selected the correct video source. • Make sure that the power cord is connected correctly to both the back of the monitor and the power outlet. For more information about connecting the power cord, see “Connecting... -
Page 18: Image Is Not Sized Or Centered Correctly
Make sure that your video card can display at 1680 × 1050 resolution. • This may be caused by older video drivers on your computer. See the Gateway support Web site (www.gateway.com) for updated video drivers for your computer. You can also go directly to your video card’s support Web site for the most up-to-date video drivers. -
Page 19: Gaming
You need to know whether you can connect the HDMI output of your external video device to the DVI port of the monitor. Important Although the HDMI interface supports audio, no audio is sent to the monitor. You must separately connect the audio output of your video device to an external audio amplifier. -
Page 20: Hdcp
Using Your Gateway Flat-Panel Monitor HDCP What is HDCP and how should you troubleshoot it? High-bandwidth Digital Content Protection (HDCP) is a specification developed by the Intel® Corporation to protect digital entertainment content that uses a digital visual interface (DVI). - Page 21 Notebook computers typically have an F key combination that lets you toggle between your notebook’s display and an externally attached display. On Gateway notebooks, this key combination is F +F4. The F4 key is located along the top row of...
-
Page 22: Specifications
Using Your Gateway Flat-Panel Monitor Specifications Specifications are subject to change without notice or obligation. Many products for Gateway and its subsidiaries are custom engineered by our suppliers to Gateway specifications and may vary from similarly marketed products. Panel size... -
Page 23: Video Modes
Altitude Operating: 12,000 feet (3,658 m) Storage: 40,000 feet (12,192 m) Security Kensington lock slot Video modes Resolution Horizontal frequency Vertical frequency Available in DVI mode (kHz) (Hz) 720 × 400 31.469 640 × 480 31.469 640 × 480 37.9... - Page 24 Using Your Gateway Flat-Panel Monitor...
-
Page 25: Safety, Regulatory, And Legal Information
Safety, Regulatory, and Legal Information • Important safety information • Environmental information • Regulatory compliance statements • Notices... -
Page 26: Important Safety Information
Your Gateway product is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed. -
Page 27: Recycling
When your electrical or electronic equipment is no longer useful to you, “take it back” to your local or regional waste collection administration for recycling. ■ In some cases, your “end of life” product may be “traded in” for credit towards the purchase of new Gateway equipment. Call Gateway to see if this program is available in your area. ■... - Page 28 FCC declaration of conformity Model: HD2200/E Caution Changes or modifications not expressly approved by Gateway could void the FCC compliance and negate your authority to operate the product. California Proposition 65 Warning This product contains chemicals known to the State of California to cause cancer, birth defects, and/or other reproductive harm.
-
Page 29: Trademark Acknowledgments
Due to continuing system improvements, Gateway is not responsible for inaccurate information which may appear in this manual. For the latest product updates, consult the Gateway Web site at www.gateway.com. In no event will Gateway be liable for direct, indirect, special, exemplary, incidental, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. - Page 30 Safety, Regulatory, and Legal Information...
- Page 32 MAN HD2200 USR GDE R0 8/07...
