JLA D170 Parts Manual

Phase 7
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D170 Parts Manual
Phase 7
JLA Limited
Meadowcroft Lane, Halifax Road
Ripponden
West Yorkshire, England
HX6 4AJ
Telephone: 01422 822282 / Fax: 01422 824390
JLA Part No. 450597

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D170 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JLA D170

Summary of Contents for JLA D170

  • Page 1 D170 Parts Manual Phase 7 JLA Limited Meadowcroft Lane, Halifax Road Ripponden West Yorkshire, England HX6 4AJ Telephone: 01422 822282 / Fax: 01422 824390 JLA Part No. 450597...
  • Page 2 These instructions must be posted in a prominent location near the dryer. POUR VOTRE SÉCURITÉ Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil. IMPORTANT D170...

  • Page 3: Table Of Contents

    Table of Contents Control Door Assembly ... 4 Phase 7 Non-Coin Microprocessor Control Panel Assembly ... 5 Front Panel/Main Door Assemblies ... 6, 7 Main Door Switch Assembly ... 8 Tumbler Assembly ... 9 Phase 7 Rotational Sensor Assembly ... 10 Lint Door Assembly ...

  • Page 4: Control Door Assembly

    Control Door Assembly Illus. No. Part No. Qty. Description 883256 Phase 7 Control Door (gas) 883322 Phase 7 Control Door (steam) 150314 #10-32 x 1/2” TORX Screw 154011 #10-32 Multi-Thread U-Nut ——— Logo Specify color when ordering. ** Contact reseller for logo. JLA Limited 450597-2...

  • Page 5: Phase 7 Non-Coin Microprocessor Control Panel Assembly

    Phase 7 Non-Coin Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112577 Phase 7 Non-Coin Keypad (for models mfd. as of September 11, 2004) 112571 Phase 7 Non-Coin Keypad (for models mfd. prior to September 11, 2004) 850980 Phase 7 Microprocessor Controller (computer) Panel Only 822754 Phase 7 Non-Coin Reversing Microprocessor Controller (computer)

  • Page 6: Front Panel/Main Door Assemblies

    Front Panel/Main Door Assemblies JLA Limited 450597-2...

  • Page 7: Front Panel/Main Door Assemblies

    Illus. No. Part No. Qty. Description 881685 White Main Door Hinge 882296 Coral Wrinkle Blue Main Door Hinge 881740 1/4-20 x 5/8” White Carriage Bolt 881739 1/4-20 x 5/8” Coral Wrinkle Blue Carriage Bolt 151012 #10-32 White Acorn Nut 881688 White Main Door Handle 881737 Blue Main Door Handle...

  • Page 8: Main Door Switch Assembly

    Main Door Switch Assembly Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single-Pole Door Switch 150443 1/4-20 x 3/4” Stainless Steel Cap Screw 881687 White Main Door Switch Housing Only 881695 Blue Main Door Switch Housing Only...

  • Page 9: Tumbler Assembly

    Illus. No. Part No. Qty. Description 835402 Stainless Steel Tumbler Assembly Complete (for models mfd. as of November 10, 2003) (includes illus. nos. 1 through 3) 835375 Tumbler Assembly Complete (for models mfd. prior to November 10, 2003) (includes illus. nos. 1 through 3) 390329 Stainless Steel Perforated Tumbler Panel (for models mfd.

  • Page 10: Phase 7 Rotational Sensor Assembly

    Phase 7 Rotational Sensor Assembly Illus. No. Part No. Qty. Description 819064 Tumbler Shaft Support Assembly Complete (includes illus. nos. 1 through 8) 835339 Tumbler Shaft Support Bracket 102394 Tumbler Friction Pad 153005 3/8” Lock Washer 150619 3/8-16 x 1” Tap Bolt 153004 3/8”...

  • Page 11: Lint Door Assembly

    Illus. No. Part No. Qty. Description 882497 White Lint Door Assembly (includes illus. nos. 1, 2, and 4) 882498 Coral Wrinkle Blue Lint Door Assembly (includes illus. nos. 1, 2, and 4) 117607 1/4” x 3/8” Poron Foam (sold by the foot) 150309 #10-16 x 1/2”...

  • Page 12: Lint Drawer/Lint Drawer Switch Box Assemblies For Models Mfd. As Of February 1, 2003

    Lint Drawer/Lint Drawer Switch Box Assemblies For Models Mfd. as of February 1, 2003 Illus. No. Part No. Qty. Description 884069 White Lint Drawer/Screen Assembly 884068 Coral Wrinkle Blue Lint Drawer/Screen Assembly 122116 Lint Drawer Switch Only 122605 4-Pin Socket Connector 122701 Socket Terminal Only 122801...

  • Page 13: Lint Drawer/Lint Drawer Switch Box Assemblies For Models Mfd. Prior To February 1, 2003

    Illus. No. Part No. Qty. Description 882792 White Lint Drawer/Screen Assembly 882793 Coral Wrinkle Blue Lint Drawer/Screen Assembly 122116 Lint Drawer Switch Only 122605 4-Pin Socket Connector 122701 Socket Terminal Only 122801 Pin/Socket Extraction Tool...Not Illustrated 882507 Lint Drawer Switch Box Assembly Complete (includes illus.

  • Page 14: Fan (Squirrel Cage) Shaft Mount Assembly

    Fan (Squirrel Cage) Shaft Mount Assembly Illus. No. Part No. Qty. Description 100612 1-1/4” Bore x 15” Diameter x 6” Blower/Fan (squirrel cage) 821078 Fan Shaft Mount Assembly Complete (includes illus. nos. 1 through 16, 18, and 19) 821073 Fan Shaft Mount Only 117604 4’...

  • Page 15: Blower Motor Mount Assembly

    Illus. No. Part No. Qty. Description 181030* 7.5 hp 208-230/460v 3-Phase (3ø) 60 Hz Motor Only 181031* 7.5 hp 200-230/380-410v 3-Phase (3ø) 50 Hz Motor Only 181039 7.5 hp 575v 3-Phase (3ø) 60 Hz Motor Only 101148 SB x 4.0 Motor Pulley (60 Hz gas) 101147 SB x 4.8 Motor Pulley (50 Hz steam) 101195...

  • Page 16: Microprocessor Temperature Sensor Bracket Assembly

    Microprocessor Temperature Sensor Bracket Assembly Illus. No. Part No. Qty. Description 815931 Microprocessor Temperature Sensor Bracket Complete (includes illus. nos. 1 through 10) 820967 Microprocessor Temperature Sensor Bracket Only 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 153010 #6 Star Washer 130103 225°...

  • Page 17: Drive Shaft Assembly

    Illus. No. Part No. Qty. Description 882460 Tumbler Shaft Assembly (includes illus. nos. 1 and 4) 821465 11” Drive Wheel 101234 Drive with Hub Taper Bushing 880779 1-3/8” Pillow Block Bearing 152011 3/8-18 Hex Nut 153005 3/8” Lock Washer 153004 3/8”...

  • Page 18: Idler Shaft Assembly

    Idler Shaft Assembly Illus. No. Part No. Qty. Description 882460 Idler Shaft Assembly (includes illus. nos. 1 and 4) 821465 11” Drive Wheel 101234 1-3/8” Taper Lock Bushing 880779 1-3/8” Pillow Block Bearing 152011 3/8-18 Hex Nut 153005 3/8” Lock Washer 153004 3/8”...

  • Page 19: Speed Reducer Shaft Assembly

    Illus. No. Part No. Qty. Description 882505 Speed Reducing Shaft Assembly (includes illus. nos. 1, 3, 4, and 10) 101160 2B x 3.4 SH Sheave (for models mfd. as of March 6, 2000) 101187 2B x 4.0” Pulley (for models mfd. prior to March 6, 2000) 101150 1-3/8”...

  • Page 20: Totally Enclosed, Non-Venting Drive Motor Assembly

    Totally Enclosed, Non-Venting Drive Motor Assembly Illus. No. Part No. Qty. Description 835297 Motor Adjustment Plate 150501 5/16-18 x 3/4” Hex Head Machine Bolt 153002 5/16” Lock Washer 153001 5/16” Flat Washer 882078 3 hp 208-230/380/416/460v 3-Phase (3ø) 50/60 Hz Totally Enclosed, Non-Venting Motor 181019 3 hp 575v 3-Phase (3ø) 60 Hz Totally Enclosed, Non-Venting Motor...

  • Page 21: Ce Hot Surface Ignition Burner Assembly

    141240 4-Port Manifold 140839 #2 Burner Orifice (natural gas) 140820 #29 Burner Orifice (liquid propane gas) 883331 D170 Liquid Propane Conversion Kit 390169 4 Tube Burner Hot Surface Ignition Mount Manifold Rest 141136 Uginox Burner Tube 332121 Burner Tube Support...

  • Page 23: Direct Spark Ignition Burner Assembly

    Illus. No. Part No. Qty. Description 142929 1-1/2” x 1” Reducing Coupling 332117 Pipe Bracket 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 142583 1” x 40” Nipple 128919 High Voltage Ignition Cable with Cap 36” 142808 1” x 3” Nipple 142602 1”...

  • Page 24: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 105500 Sail Switch Actuator Rod 319202 Sail Switch Damper (flat) 154002 1/8” Push On Fastener 802800 Sail Switch Box with Cover and Bracket Only 802801 Sail Switch Box Assembly Complete for Microprocessor Controller (computer) Models Only (includes illus.

  • Page 25: Air Jet Assembly

    Illus. No. Part No. Qty. Description 332700 Air Jet Tube Only 143287 1/4” x 1/8” M.P.T. Male Run Tee 143259 1/4” x 1/8” F.P.T. Bulkhead Fitting 143100 36” 1/4” Aluminum Tube (sold by the inch) 821081 Air Jet Assembly (includes illus. nos. 1 through 9) 332531 Air Jet Mounting Plate Only 152002...

  • Page 26: Microprocessor Reversing Contactor Mounting Panel Assembly For 208-240V Transformers

    Microprocessor Reversing Contactor Mounting Panel Assembly For 208-240V Transformers JLA Limited 450597-2...

  • Page 27: Microprocessor Reversing Contactor Mounting Panel Assembly

    Microprocessor Reversing Contactor Mounting Panel Assembly Illus. No. Part No. Qty. Description 152002 1/4-20 Hex Nut 132465 3 hp Contactor – 24 VAC 151001 #8-32 Pal Nut 150009 #6-32 x 1-1/4” Phillips Round Head Machine Screw 120701 4-Position Power Distribution Block 132497 Reversing Contactor –...

  • Page 28: Microprocessor Reversing Contactor Mounting Panel Assembly For 380-416V Transformers

    Microprocessor Reversing Contactor Mounting Panel Assembly For 380-416V Transformers JLA Limited 450597-2...
  • Page 29 Microprocessor Reversing Contactor Mounting Panel Assembly Illus. No. Part No. Qty. Description 132467 9-13 amp Overload 132465 10 hp Contactor – 24 VAC 151001 #8-32 Pal Nut 150009 #6-32 x 1-1/2” Phillips Round Head Machine Screw 120701 4-Position Power Distribution Block 132497 “Kline”...

  • Page 30: Microprocessor Reversing Contactor Mounting Panel Assembly For 460-480V Transformers

    Microprocessor Reversing Contactor Mounting Panel Assembly For 460-480V Transformers JLA Limited 450597-2...
  • Page 31 Microprocessor Reversing Contactor Mounting Panel Assembly Illus. No. Part No. Qty. Description 132467 9-13 amp Overload 132465 10 hp Contactor – 24 VAC 151001 #8-32 Pal Nut 150009 #6-32 x 1-1/2” Phillips Round Head Machine Screw 120701 4-Position Terminal Block 132497 “Kline”...

  • Page 32: Steam Damper Assembly For Steam Models Only

    Steam Damper Assembly For Steam Models Only Illus. No. Part No. Qty. Description 165017 Steam Coil Only 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 820994 Steam Damper Assembly (includes illus.

  • Page 33: Pneumatic Valve Assembly For Gas Models Only

    Illus. No. Part No. Qty. Description 100520 1/8” N.P.T. Silencer (muffler) Only 150002 #6-32 x 1” Slotted Machine Screw 100498 3-Way Micro Valve Only – 24 VAC 821105 Pneumatic Valve Assembly Complete (includes illus. nos. 1 through 8) 143268 1/8” Street Elbow 100472 1/4”...

  • Page 34: Pneumatic Valve Assembly For Steam Models Only

    Pneumatic Valve Assembly For Steam Models Only Illus. No. Part No. Qty. Description 100496 1/8” Needle Valve 143238 1/8” Close Nipple 100498 3-Way Micro Valve Only – 24 VAC 821104 Pneumatic Valve Assembly Complete (includes illus. nos. 1 through 8) 143223 1/8”...

  • Page 35: Top Console Assembly

    Illus. No. Part No. Qty. Description 821085* Top Console Assembly Only (for gas models Only) 821086* Top Console Assembly Only (for steam models Only) 114508 “Phase 7 Non-Coin Program Location Summary” Label (for microprocessor models Only) ——— Dryer Data Label 153007 1/4”...

  • Page 36: S.a.f.e. Temperature Probe Assembly

    S.A.F.E. Temperature Probe Assembly Illus. No. Part No. Qty. Description 822752 Sensor Activated Fire Extinguishing System Temperature Probe Assembly (includes illus. nos. 1 through 5) 154007 Push On Fastener 390390 Sensor Bracket Only 150301 #8-18 Phillips Pan Head TEK Screw 122647 Connector Only...Not Illustrated (does not include pins)

  • Page 37: Solenoid Assembly For Models Mfd. As Of September 23, 2004

    Illus. No. Part No. Qty. Description 143581 3 GPM 3/8” F.P.T. Spray Nozzle 143303 3/8” N.P.T. Brass Locknut 136987 Pressure Switch 143251 3/8” M.P.T. Brass Plug 182579 3/8” Hex Nipple 143220 3/8” F.P.T. Brass Tee 143301 3/8” Brass 45° Elbow 311588 Sprinkler Head Mounting Plate 143208...

  • Page 38: S.a.f.e. Solenoid Assembly

    S.A.F.E. Solenoid Assembly Illus. No. Part No. Qty. Description 165114 Sensor Activated Fire Extinguishing System Solenoid Valve 24 VAC 50/60 Hz 143220 3/8” F.P.T. Brass Tee 143251 3/8” M.P.T. Brass Plug 143208 3/8” Comp x 3/8” M.P.T. Brass Connector 143108 20”...

  • Page 39: Back Guard Assemblies

    Illus. No. Part No. Qty. Description 821793 Square Duct to 20” Round Duct Transition Piece Assembly with Damper 821956 Square Duct to 20” Round Duct Transition Piece Assembly ——— Wiring Diagram for Machine (contact factory with model and serial numbers) 112046 “Computer Ground”...
  • Page 40 JLA Part No. 450597 2 - 04/25/05 - 0...
