JLA D75 Parts Manual

American dryer corporation dryer parts manual
Hide thumbs Also See for D75:
Table of Contents

Advertisement

Quick Links

D75 Parts Manual
JLA Limited
Meadowcroft Lane, Halifax Road
Ripponden
West Yorkshire, England
HX6 4AJ
Telephone: 01422 822282 / Fax: 01422 824390
Part No. 450592-3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D75 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JLA D75

Summary of Contents for JLA D75

  • Page 1 D75 Parts Manual JLA Limited Meadowcroft Lane, Halifax Road Ripponden West Yorkshire, England HX6 4AJ Telephone: 01422 822282 / Fax: 01422 824390 Part No. 450592-3...
  • Page 2 Retain This Manual In A Safe Place For Future Reference JLA products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation. ONLY qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with the dryer.

  • Page 3: Table Of Contents

    Table of Contents Control Door Assembly for Models Mfd. as of July 10, 2002 ... 4 Control Door Assembly for Models Mfd. prior to July 10, 2002 ... 5 Phase 7 OPL Microprocessor Control Panel Assembly ... 6 Phase 7 OPL Microprocessor Control Box Assembly ... 7 Front Panel Assembly ...

  • Page 4: Control Door Assembly For Models Mfd. As Of July 10, 2002

    Control Door Assembly For Models Mfd. as of July 10, 2002 Illus. No. Part No. Qty. Description 883576 White OPL Control Door (includes illus. nos. 1 and 3) 150321 #10-32 x 1/2” Phillips Machine Screw 117604 Neoprene Sponge Tape (sold by the foot) 150317 #10-16 x 3/4”...

  • Page 5: Control Door Assembly For Models Mfd. Prior To July 10, 2002

    Illus. No. Part No. Qty. Description 883304 White Control Door Assembly (includes illus. nos. 1 and 3) 150314 #10-32 x 1/2” TORX PLUS 117604 Noise Suppressor Tape (sold by the foot) ––––––* Logo 154011 #10-32 Multi-Thread U-Nut * Contact reseller for logo. 450592 - 3 ®...

  • Page 6: Phase 7 Opl Microprocessor Control Panel Assembly

    Phase 7 OPL Microprocessor Control Panel Assembly Illus. No. Part No. Qty. Description 112571 Phase 7 OPL Keyboard 850984 Phase 7 Microprocessor Controller (computer) Panel ONLY 887005 Phase 7 OPL Microprocessor Controller (computer) (for models mfd. as of December 3, 2003) 887002 Phase 7 OPL Microprocessor Controller (computer) (for models mfd.

  • Page 7: Phase 7 Opl Microprocessor Control Box Assembly

    Phase 7 OPL Microprocessor Control Box Assembly Illus. No. Part No. Qty. Description 122681 10-Pin Connector 122676 8-Pin Connector 122646 2-Pin Connector 122683 6-Pin Terminal 122640 9-Pin Terminal 122706 #20-16 U.M.N.L. Socket 122669 Female Crimp Terminal * As needed. 450592 - 3 Telephone: 01422 822282 / Fax: 01422 824390...

  • Page 8: Front Panel Assembly

    Front Panel Assembly Illus. No. Part No. Qty. Description 801604 Front Panel Assembly (for models mfd. as of September 11, 2006) (includes illus. nos. 1, 7, and 8) 802267 Front Panel Assembly (for models mfd. prior to September 11, 2006) (includes illus.

  • Page 9: 37-1/4" Main Door Assembly For Models Mfd. As Of September 11, 2006

    Illus. No. Part No. Qty. Description 835128 Main Door Hinge 314729 Main Door Handle 102357 Door Gasket 170731 Black Gasket Adhesive (10.3 oz. cartridge) 102221 Door Glass 170731 Black Glass Adhesive (10.3 oz. cartridge) 152014 1/4-20 Free Spin Wash Nut 150683 1/4-20 x 5/8”...

  • Page 10: 25-1/2" Main Door Assembly For Models Mfd. Prior To September 11, 2006

    25-1/2” Main Door Assembly For Models Mfd. prior to September 11, 2006 Illus. No. Part No. Qty. Description 881150 Black Main Door Assembly Complete (includes illus. nos. 1, 2, and 8 through 15) 102354 Door Gasket 170731 Black Gasket Adhesive (10.3 oz. cartridge) 881152 Black Top Hinge Block Assembly (includes illus.

  • Page 11: Main Door Switch Assembly For Models Mfd. As Of September 11, 2006

    Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Single-Pole Door Switch 150445 1/4-20 x 3/4” Cap Screw 882866 Black Main Door Switch Housing 883338 Black Main Door Switch with Housing Assembly (includes illus.

  • Page 12: Main Door Switch Assembly For Models Mfd. Prior To September 11, 2006

    Main Door Switch Assembly For Models Mfd. prior to September 11, 2006 Illus. No. Part No. Qty. Description 150006 #6-32 x 7/8” Phillips Pan Head Machine Screw 152013 #6-32 Hex Nut 153010 #6 Star Washer 137005 Door Switch 122636 Flag Terminal 881211 Black Main Door Switch Housing ONLY 881153...

  • Page 13: Tumbler / Support Assemblies

    Illus. No. Part No. Qty. Description 801076 Tumbler ONLY without Felt Collar (for models mfd. as of September 11, 2006) 800985 Tumbler ONLY without Felt Collar (for models mfd. prior to September 11, 2006) 887184 Tumbler and Support Assembly Complete (for models mfd.

  • Page 14: Lint Drawer / Lint Drawer Switch Assembly

    Lint Drawer / Lint Drawer Switch Assembly Illus. No. Part No. Qty. Description 884055 White Lint Drawer Assembly (includes illus. nos. 1, 2 and 3) 117605 Neoprene Sponge Tape (sold by the foot) 108222 Lint Screen Assembly 122605 4-Pin Connector (female) 122116 Lint Drawer Switch 833123...

  • Page 15: Idler Bearing Assembly

    Illus. No. Part No. Qty. Description 100108 5L-680 V-Belt (tumbler to idler) 101140 14” x 3” Compound Pulley 100194 4L-720 V-Belt (idler to motor) for Non-Reversing Models ONLY 100109 4L-650 V-Belt (idler to motor) for Reversing Models ONLY 154301 5/16-18 x 1” Allen Setscrew 100705 3/16”...

  • Page 16: Tumbler Bearing Assembly

    Tumbler Bearing Assembly JLA Limited 450592 - 3...
  • Page 17 Illus. No. Part No. Qty. Description 880220 1-3/4” Flange Bearing 153025 9/16” Lock Washer 152050 9/16-12 Hex Nut 883387 Pillow Block Bearing Assembly Complete (includes illus. nos. 4 through 18, 23 and 24) 882543 Pillow Block Bearing Platform ONLY 880779 1-3/8”...

  • Page 18: Non-Reversing Motor Mount Assembly

    Non-Reversing Motor Mount Assembly JLA Limited 450592 - 3...
  • Page 19 Illus. No. Part No. Qty. Description 100194 4L-720 V-Belt (idler to motor) 100701 3/16” x 3/16” x 1” Key 101139 5/8” x 2-3/4” Motor Pulley 150501 5/16-18 x 3/4” Tap Bolt 153002 5/16” Lock Washer 153001 5/16” Flat Washer 181050 1 hp 240v 1ø...

  • Page 20: Reversing T.e.f.c. Motor Mount Assembly

    Reversing T.E.F.C. Motor Mount Assembly JLA Limited 450592 - 3...
  • Page 21 Illus. No. Part No. Qty. Description 100109 4L-650 V-Belt (to idler assembly) 100701 3/16” x 3/16” x 1” Key 101139 5/8” x 2-3/4” Motor Pulley 120200 3/8” x 90° Connector 181003 1/2 hp 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled Motor (56Z frame) 150501 5/16-18 x 3/4”...

  • Page 22: Sensor Bracket Assemblies

    Sensor Bracket Assemblies JLA Limited 450592 - 3...
  • Page 23 Illus. No. Part No. Qty. Description 880251 1/4” Temperature Sensor Probe Assembly (includes illus. nos. 1 and 5 through 8) 130103 225° Hi-Limit Thermostat 153010 #6 Star Washer 152000 #6-32 Hex Nut 121028 Insulated Terminal ONLY 122701 Socket Terminal ONLY 122605 4-Pin Socket Connector ONLY 154007...

  • Page 24: Direct Spark Ignition Burner Assembly

    Direct Spark Ignition Burner Assembly JLA Limited 450592 - 3...
  • Page 25 (includes illus. nos. 1 through 5 and 7 through 30) 817209* Liquid Propane Gas Burner Assembly (includes illus. nos. 1 through 5 and 7 through 30) 883299 D75 Liquid Propane Conversion Kit 141105 Large Tube Burner 141210 3/4” Direct Spark Ignition Manifold (4-port)

  • Page 26: Hot Surface Ignition Burner Assembly

    Hot Surface Ignition Burner Assembly JLA Limited 450592 - 3...
  • Page 27 Illus. No. Part No. Qty. Description 817110* Natural Gas Burner Assembly Complete Less Orifices For Models Manufactured with Natural Gas ONLY (includes illus. nos. 1 through 9 and 11 through 31) 817111* Liquid Propane Gas Burner Assembly Complete Less Orifices For Models Manufactured with Liquid Propane Gas ONLY (includes illus.

  • Page 28: Air-Operated Steam Damper Assembly

    Air-Operated Steam Damper Assembly JLA Limited 450592 - 3...
  • Page 29 Illus. No. Part No. Qty. Description 165009 Steam Coil Assembly 153002 5/16” Lock Washer 152004 5/16-18 Hex Nut 152002 1/4-20 Hex Nut 153007 1/4” Lock Washer 820321 Steam Damper Hinge Assembly 803415 Steam Damper Assembly (includes illus. nos. 7, 10, and 11) 153007 1/4”...

  • Page 30: Electric Oven Assembly

    Electric Oven Assembly JLA Limited 450592 - 3...
  • Page 31 Illus. No. Part No. Qty. Description 803005 Large Electric Oven Box ONLY ––––––* Electric Oven Assembly Complete ––––––* – Electric Element 150300 #10-16 x 1/2” Hex Washer TEK Screw 802800 Sail Switch Box with Bracket and Cover ONLY 802801 Sail Switch Box Assembly Complete (includes illus.

  • Page 32: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 319203 Sail Switch Mounting Bracket 319202 Sail Switch Damper (flat) 319201 Sail Switch Box Cover 319200 Sail Switch Box 154004 Twin Speed Nut 154002 1/8” Push-On Fastener 150309 #10-16 x 1/2” Hex Head TEK Crimptite Screw 150303 #4 x 3/4”...

  • Page 33: Rear Electric Relay Panel Assembly

    Illus. No. Part No. Qty. Description 151000 #6-32 Pal Nut 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120716 2-Position Terminal Block 322812 Rear Electric Mounting Plate ONLY 830469 Rear Electric Panel Assembly Complete – 230 Volt 1ø (for gas direct spark ignition models Only) (includes illus.

  • Page 34: Reversing Electric Relay Panel Assembly

    Reversing Electric Relay Panel Assembly JLA Limited 450592 - 3...
  • Page 35 Illus. No. Part No. Qty. Description 150300 #10-16 x 1/2” Hex Washer TEK Screw 150008 #6-32 x 1-1/4” Phillips Pan Head Machine Screw 120701 4-Position Terminal Block 132497 3-Pole Reversing Contactor 132082 Transformer Assembly – 380-416 Volt 3ø 136008 Fuse Holder ONLY 136057 1/2-Amp (Slo-Blo) Fuse ONLY 150301...

  • Page 36: S.a.f.e. Temperature Probe Assembly

    S.A.F.E. Temperature Probe Assembly Illus. No. Part No. Qty. Description 822752 Sensor Activated Fire Extinguishing Temperature Probe Assembly (includes illus. nos. 1 through 5) 154007 Push-On Fastener 390390 Sensor Bracket ONLY 150301 #8-18 Phillips Pan Head TEK Screw 122647 Connector ONLY JLA Limited 450592 - 3...

  • Page 37: S.a.f.e. Solenoid And Piping Assembly

    Illus. No. Part No. Qty. Description 165114 Sensor Activated Fire Extinguishing Solenoid Valve 24V 50/60 Hz 143220 3/8” F.P.T. Brass Tee 143251 3/8” M.P.T. Brass Plug 143208 3/8” Comp x 3/8” M.P.T. Brass Connector 143099* 6’ 3/8” OD x 0.035 Wall Copper Tubing 311588 Sprinkler Head Mounting Plate 143303...

  • Page 38: Outer Top / Back Guard Assemblies For Models Mfd. As Of January 5, 2003

    Outer Top / Back Guard Assemblies For Models Mfd. as of January 5, 2003 Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 314534 Top Back Guard (for gas models Only) 314540 Top Back Guard (for electric models Only) 150301...

  • Page 39: Outer Top / Back Guard Assemblies For Models Mfd. Prior To January 5, 2003

    Illus. No. Part No. Qty. Description 322809 Back Electrical Box Cover 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 323738 Top Back Guard (for gas models Only) 320008 Top Back Guard (for electric models Only) 150301 #8-18 x 7/16” Phillips Pan Head TEK Screw 150300 #10-16 x 1/2”...

  • Page 40: Microprocessor Electric Oven Component Application Chart

    ø ø ø ø ø * Consult factory for oven assemblies not listed. . y t . y t . y t...

  • Page 41: Additional Parts Available

    Part No. Description 114533 “Black/White/Green Ground” Label 112280 “Clean Lint Screen” Label 114001 “CAUTION – Exhaust/Lint Screen” Label 114043 “Phase 7 OPL Program Location Summary” Label 114006 “WARNING – Fire Hazards” Label 114094 “MOP HEAD WARNING” Label 121499 5-1/2” Wire Tie 121500 8”...
  • Page 42 Part No. 450592 3 - 01/28/08 - 0...
