- Page 1 ZD-SI-610 / ZD-SO-610 User Manual 10 YEAR LIFE / 10 YEAR LIFE TOAST PROOF SMOKE ALARM...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ALARM SMART SILENCE™ AUTOMATIC POWER ENGAGE ROUTINE MAINTENANCE SENSOR TECHNOLOGY WHAT TO DO IN CASE OF FIRE IN YOUR HOME APPLICATION REPAIR POSITIONING TROUBLESHOOTING LIMITATIONS DISPOSAL HOW TO INSTALL YOUR SMOKE ALARM HOW TO MAKE YOUR HOME 1 Preparation SAFER 2 Install mounting plate 3 Fit your smoke alarm... -
Page 3: Introduction
INTRODUCTION AUTOMATIC POWER ENGAGE This user manual covers the following two products, Zeta ZD-SI-610 (Ionisation) Smoke Your 10 year life smoke alarm is powered by Alarm and ZD-SO-610 Toast Proof (Optical) an internal lithium-ion power pack. To avoid Smoke Alarm. unnecessary use of the power pack prior to installation, and to ease disposal when the Congratulations! You’ve made a wise... -
Page 4: Sensor Technology
SENSOR TECHNOLOGY APPLICATION WARNING: Your Zeta smoke alarm There are two main types of smoke alarm. The can be installed into a new build property ZD-SI-610 Standard Smoke Alarm uses an as additional protection to an existing ionisation type sensor to detect the presence of smoke. - Page 5 homes. Construction and layout of individual a primary fire detection system that meets dwellings will vary, so this should be regulatory requirements for common areas regarded only as a guide. Check with your such as lobbies and hallways. local fire station for further guidance. Institutions and Hotels This includes motels, hospitals, day care facilities, long-term health care facilities,...
-
Page 6: Positioning
POSITIONING contaminate the sensing chamber, making it over sensitive or impairing smoke entry. • In areas where the ambient temperature Ionisation type smoke alarms are generally is not controlled and may regularly drift more effective at detecting fast, flaming fires below 4°C (40°F) or above 38°C (100°F) which consume combustable materials rapidly e.g. -
Page 7: Limitations
WHAT ARE THE 1 METRE DEAD (3 FEET) LIMITATIONS OF MY AIR SPACES SMOKE ALARM? Your Zeta smoke alarm is designed to alert you by sounding an alarm when it senses smoke, i.e. it can only sense smoke and alert you if smoke reaches it! If a fire develops in an area remote from the location of the smoke alarm, such as another room or another level,... - Page 8 WARNING: Your smoke alarm will not types of fire within sufficient time to alert you operate without sufficient power. of the danger and provide adequate time for your escape. In order to maximise your As the alarm’s power pack reaches the end level of safety always test your smoke alarm of its life a low power warning chirp will be frequently to ensure it is in full working order.
-
Page 9: How To Install Your Smoke Alarm
HOW TO INSTALL YOUR 1 Preparation SMOKE ALARM IMPORTANT: Make sure you have read and understood this manual before installing your smoke alarm. Preparation Fixing slots Attach the mounting plate to a ceiling or wall. If the alarm is to be mounted on a wall, ensure the mounting plate is aligned correctly. -
Page 10: Fit Your Smoke Alarm
Fit Your Zeta Smoke Alarm Test Your Zeta Smoke Alarm The alarm will only lock into place in one After fitting the alarm to the base plate, wait particular position. Position the smoke alarm for 5 seconds for the alarm to settle then test over the mounting plate lining up the central the alarm. -
Page 11: Operation
OPERATION ALARM TEST Normal condition The red LED on the front should flash every 40 seconds to show the alarm is active. Low Power Pack Condition IMPORTANT: Your smoke alarm requires the power pack to have sufficient capacity of power to operate correctly. Should your Zeta smoke alarm enter a low power pack condition, the unit will emit an audible ‘chirp’... -
Page 12: Alarm Smart Silence
ALARM SMART SILENCE™ DANGER: If your Zeta smoke alarm emits the full alarm signal and you are not testing the unit, the smoke alarm is warning you of a potentially dangerous situation that requires your immediate attention. Only c The red LED on your alarm will flash use the alarm silence function after making rapidly during the audible signal. - Page 13 c During the reduced sensitivity reset cycle, the red LED on your alarm will flash more rapidly than normal, approximately once every 10 seconds. a Press and release the silence button, the alarm sound will shortly stop. d Your alarm will automatically return to full sensitivity on completion of the reset cycle and the red LED will revert to flashing once every 40 seconds.
-
Page 14: Routine Maintenance
ROUTINE MAINTENANCE IMPORTANT: Do not use solvents or cleaners on your Zeta smoke alarm, as they may cause damage to the sensor or Your Zeta smoke alarm has been designed to circuitry. The unit can be wiped with a slightly be as maintenance-free as possible, however damp cloth. -
Page 15: What To Do In Case Of
WHAT TO DO IN CASE OF • Call the Fire brigade on 999 as soon as possible from outside your house. If A FIRE IN YOUR HOME possible use a neighbours phone or call box rather than a mobile phone (as the •... -
Page 16: Repair
REPAIR DO NOT attempt to repair your Zeta smoke alarm doing so will invalidate your warranty. If your smoke alarm is not operating properly, see the next section ‘Troubleshooting’. If you cannot solve the problem, please call the Technical Support Line. If your Zeta smoke alarm is no longer under warranty, replace immediately with a comparable Zeta brand smoke alarm. -
Page 17: Troubleshooting
TROUBLESHOOTING Problem Solution Your Zeta smoke alarm does not sound • Make sure alarm has been rotated during testing clockwise as far as it can go and is securely located on mounting plate (this means the power pack has been activated). - Page 18 Your Zeta smoke alarm chirps intermittently • Check the location of your smoke alarm (see ‘Application & Positioning’). • Check that your smoke alarm is definitely the source of chirping; make sure the noise isn’t coming from another alarm (smoke/carbon monoxide/burglar/gas alarm) by process of elimination.
- Page 19 If the alarm fails to operate correctly, the If you have any questions about the advice of the manufacturer should be sought operation of your alarm, please contact Zeta Technical Support Team between 9am - 5pm Monday – Friday. Telephone: +44 (0) 1792 455 175 or e-mail: support@zetaalarmsystems.com You can also visit the support section of our website www.zetaalarmsystems.com...
-
Page 20: Disposal
DISPOSAL HOW TO MAKE YOUR HOME SAFER Waste electrical products should not be disposed of with household waste. Installing smoke alarms is only one step in protecting your family from fires. You must Please recycle where facilities exist. Check also take steps to reduce the chances of fires with your local authority, retailer or contact our starting in your home. - Page 21 barbecue grills grease free. Make sure alternative exit if the door is hot and they are properly installed, away from should not be opened. any combustible materials. • Decide on a meeting place a safe • Keep portable heaters and open flames distance from your house.
-
Page 22: Warranty
WARRANTY with the user manual. It does not cover events and conditions outside of Zeta Alarm Systems’ control, such as Acts of God (fire, severe Zeta Alarm Systems warrants to the original weather etc.). It does not apply to retail stores, purchaser that its enclosed smoke alarm be service centres or any distributors or agents. -
Page 23: Returns
RETURNS PRODUCT RANGE We recommend that you contact the Zeta Zeta Alarm Systems provide an extensive Technical Support Line in the first instance on range of Fire Alarm Systems, Gas Detection +44 (0) 1792 455 175 as we may be able &... -
Page 24: Notes
NOTES... - Page 25 GN0504/R2...
- Page 26 Technical Support Line +44 (0) 1792 455 175 Email support@zetaalarmsystems.com www.zetaalarmsystems.com ZD-SI-610 ZD-SO-610 Zeta Alarm Systems Detection House 72-78 Morfa Road Certificate No.330j/02 Certificate No.330j/04 ZD-SI-610 / ZD-SO-610 Swansea, SA1 2EN to BS EN 14604:2005 to BS EN 14604:2005 GN0504/R2...
