Summary of Contents for Planar PXL2760MW
- Page 1 PXL2760MW LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Front View of the Product ............................5 Rear View of the Product ..............................6 Quick Installation ................................7 Basic Operation.................................8 Advanced Operation—OSD Menu......................... 10 Supporting Timing Modes ............................13 Technical Information ..............................14 Wall-Mount Installation Instructions........................15 Care and Maintenance ............................16 Troubleshooting................................16 Planar Support ................................17... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the PXL2760MW LED LCD monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Safety Precautions
Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. Turn off the product before cleaning. LED Display screen surface may be cleaned using a soft clean cloth moistened with mild window glass commercial cleaners or 50/50 mixture of water and isopropyl alcohol. -
Page 5: Package Overview
Package Overview Congratulations on your purchase of this high performance LED edge lit, LCD monitor. This LED LCD Monitor comes with the following accessories: LED LCD Monitor Base Power Cord VGA Signal Cable Audio-in Cable HDMI Cable User’s Guide... -
Page 6: First Setup
First Setup Install the stand base 1. Lay the LED LCD Monitor flat on a table with the LED screen face down. To prevent the monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set. 2. -
Page 7: Front View Of The Product
Front View of the Product ① ② ③ ④ ⑤ ① OSD Turn On/ Off ② Scroll Down/ Adjust Decrease/ Picture Mode/ Auto * ③ Scroll UP/ Adjust Increase/ Audio Adjust/ Mute * ④ Input select/ Confirm Selection ⑤ Power On/Off / LED Indicator * Hot keys Instructions please see “Using the OSD Menu”... -
Page 8: Rear View Of The Product
Rear View of the Product ① ②③ ④ ⑤ ⑥ ① Power Input ② Audio Input ③ Headphone Jack ④ DisplayPort Input (DisplayPort 20 pin) ⑤ VGA Input (D-Sub 15 pin) ⑥ HDMI input (HDMI 19 pin) -
Page 9: Quick Installation
Quick Installation Connect either VGA, HDMI or DisplayPort Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Please note: The monitor ships with only VGA and HDMI cables. DisplayPort cable may be sourced separately from a cable supplier. -
Page 10: Basic Operation
Basic Operation Before using the LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD Monitor on/off: Press Power button on the front of LED LCD Monitor. The power LED indicator light will be blue when the LED LCD Monitor is on. - Page 11 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 5 seconds to lock all 5 buttons. The LED LCD Monitor will show a “Locking Power Button” message for 3 seconds and the message will disappear automatically.
-
Page 12: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use ▼ or ▲ to select the desired OSD menu. Short Cuts Function from the button(s) Auto Image Adjust: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 13 Input Select: When Input Select is pressed, change Input signal to VGA, HDMI, DisplayPort or Auto. Audio Adjust: To adjust the audio functions. Volume: To adjust the volume of speaker output. Mute: To turn the Mute ON/OFF. Audio: When in HDMI input, select where the audio source comes from Line-In or HDMI.
- Page 14 To adjust the clarity of a non-Full HD Resolution (1920x1080) signal with ▲ Sharpness: or ▲ button. Setup Menu: To set up Language Select, OSD Position, OSD Time Out, OSD Background and LED mode. Language Select: To allow users to choose from available languages. Press ▲...
-
Page 15: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 16: Technical Information
Technical Information Panel 27” TFT (with LED backlight) Power Management On: 40 Watts (typical), 50 Watts (maximum) Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.3114 x 0.3114 mm Display Color 16.7M... -
Page 17: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Preparing To Install The Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm you can purchase separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. -
Page 18: Care And Maintenance
Care and Maintenance Care Avoid exposing your LED LCD Monitor directly to sunlight or other heat source. Place your LED LCD Monitor away from the sun to reduce glare. Put your LED LCD Monitor in a well ventilated area. Do not place any heavy things on top of your LED LCD Monitor. Make certain your LED LCD Monitor is installed in a clean and moisture-free area. -
Page 19: Planar Support
Planar Support Cables, Replacement Lamps, Accessories To find cables, replacement lamps and accessories for your Planar projector, monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com or find other stores who carry Planar products at http://www.planar.com/howtobuy Technical Support Visit Planar at http://www.planar.com/support for product registration, operations manuals,... - Page 20 2012 2001132384T...
