Summary of Contents for Planar PXL2471MW
- Page 1 PXL2471MW LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Rear View of the Product ..............................8 Quick Installation ................................9 Basic Operation and Calibration/Reset Instructions..................10 Advanced Operation—OSD Menu......................... 12 About the Stand ................................15 Supporting Timing Modes ............................16 Technical Information ..............................17 Wall-Mount Installation Instructions........................18 Troubleshooting................................19 Planar Support ................................20... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the PXL2471MW LED LCD monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED LCD Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour offrir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.
-
Page 5: Unpacking Instructions
Unpacking Instructions Remove the LED LCD Monitor out of the package and take off the plastic bag and Polystyrene Foam. Remove base from plastic bag and attach to base. Adjust the display between -5° and 15°. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. - Page 6 Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à...
-
Page 7: Package Overview
Package Overview LED LCD Monitor Base Power Cord VGA Cable Display Port Cable Audio Cable User’s Guide... -
Page 8: First Setup
First Setup Install the stand base 1. Lay the LED LCD Monitor flat on a table with the LED screen face down. To prevent the LED LCD Monitor from being scratched, put a piece of soft cloth on the table on which the screen will be set. -
Page 9: Front View Of The Product
Front View of the Product ① ② ③ ④ ⑤ ⑥ ① OSD Turn On/ Off ② Scroll Down/ Adjust Decrease/ Audio Adjust/ Auto * ③ Scroll UP/ Adjust Increase/ Picture Mode * ④ Input select/ Confirm Selection ⑤ Power On/ Off ⑥... -
Page 10: Rear View Of The Product
Rear View of the Product ① ② ③ ④ ⑤ ⑥⑦ ① Power Input ② Cable Management ③ DisplayPort Input (DisplayPort 20 pin) ④ HDMI input (HDMI 19 pin) ⑤ VGA Input (D-Sub 15 pin) ⑥ Audio Input ⑦ Headphone Jack... -
Page 11: Quick Installation
Quick Installation Connect either VGA, HDMI or DisplayPort Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Please note. The monitor ships with DisplayPort and HDMI cables only. VGA cable may be sourced separately from a cable supplier. -
Page 12: Basic Operation And Calibration/Reset Instructions
Basic Operation and Calibration/Reset Instructions Before using the LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the LED LCD Monitor on/off: Press button on the front. The power LED indicator light will be blue when the LED LCD Monitor is on. - Page 13 Option 2: OSD & Power button lock – all 5 buttons including the “POWER” button are locked. Press and hold the 1 button and the ▼ button for 3 seconds to lock all 5 buttons. The LED LCD Monitor will show a “Power Button Locked” message for 3 seconds and the message will disappear automatically.
-
Page 14: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your LED LCD Monitor. Press the 1 button to display the OSD Menu, and use ▲ or ▼ to select the desired OSD menu. Short Cuts Function from the button(s) AUTO IMAGE ADJUST: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 15 INPUT SELECT: When Input Select is pressed, change Input signal to VGA, HDMI, DISPLAY PORT or AUTO. AUDIO ADJUST: To adjust the audio functions. VOLUME: To adjust the volume of speaker output. MUTE: To turn the Mute ON/OFF. AUDIO INPUT: When in HDMI input, select where the audio source comes from AUDIO IN or HDMI.
- Page 16 VIDEO MODE ADJUSTMENT: To select the video mode from FULL SCREEN or ASPECT RATIO. SETUP MENU: To set up LANGUAGE SELECT, OSD POSITION, OSD TIME OUT, OSD BACKGROUND and LED mode. LANGUAGE SELECT: To allow users to choose from available languages. Press ▲...
-
Page 17: About The Stand
About the Stand The stand allows you to easily adjust the height, swivel, tilt, and portrait mode of your monitor to provide maximum ergonomic comfort. 1) Height adjustment 2) Swivel 45° 45° 110mm 3) Tilt 4) Pivot -5~15° 90° 90°... -
Page 18: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 19: Technical Information
Technical Information Panel 23.6” TFT (with LED backlight) On: 32 Watts (typical), 35 Watts (maximum) Power Management Standby Mode: < 0.5 Watt Off: < 0.5 Watt Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.2715 x 0.2715 mm Display Color 16.7M... -
Page 20: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Preparing to Install the Optional Wall Mount Arm (not included) This LED LCD Monitor can be attached to a wall mounting arm purchased separately. Turn the power OFF then disconnect the cables from the LED LCD Monitor before performing the procedure below. 1. -
Page 21: Troubleshooting
Troubleshooting No power Make sure A/C power cord is securely connected to the power adapter and the power supply is firmly connected to the LED LCD Monitor . Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. -
Page 22: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 23 2014 2001132475T...
