Once loaded, the Axis cameras are found under Security Devices in the project browser.

3. Using the camera families

The key features of Axis' parametric camera families are:
>
Support for different mounting options
>
Interactive visualization of camera field of view in floor plans, sections and 3D views.
> Detailed AXIS Security Device Schedule listing all cameras and mounting options
>
Product data for BIM

3.1 Mounting options

Each camera family supports the mounting options supported by the camera out of the box, or using
optional AXIS T91A-series accessories. The available mounting options depend on which versions were
selected when loading the family.
Some mounting options using the indoor models from the P33-series are shown below:
Ceiling mount
Surface wall mount
Use the type selector in the Revit properties palette to switch between mounting options and camera
models.
Surface ceiling mount
Corner mount
Recessed ceiling mount
Pole mount
Wall mount
Parapet mount
4
