AXIS Q1656-DLE Radar-Video Fusion Camera
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q1656-DLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axis Q1656-DLE

Summary of Contents for Axis Q1656-DLE

  • Page 1 AXIS Q1656-DLE Radar-Video Fusion Camera User Manual...
  • Page 2 For example, if an object appears at 50 m (164 ft), it may be too small for the video analytics to detect, but the radar sees it. In that case, the radar detections are fused into the image plane and can be used to trigger alarms inside AXIS Object Analytics.

  • Page 3: Find The Device On The Network

    Get started Find the device on the network To find Axis devices on the network and assign them IP addresses in Windows®, use AXIS IP Utility or AXIS Device Manager. Both applications are free and can be downloaded from axis.com/support.

  • Page 4: Webpage Overview

    Verify that no one has tampered with the firmware To make sure that the device has its original Axis firmware, or to take full control of the device after a security attack: 1. Reset to factory default settings. See Reset to factory default settings on page 65.
  • Page 5 If more than 8 radars are mounted close together, they may interfere with each other. To avoid interference from other AXIS Q1656-DLE Radar-Video Fusion Cameras, see Install multiple radar-video fusion cameras on page 5 . Install multiple radar-video fusion cameras The radio waves continue beyond the detection area, and can interfere with other radars up to 350 m (380 yd) away.
  • Page 6 If in an installation contains more than 8 AXIS Q1656-DLE, and many of the devices are pointing away from each other then there is less risk of inference. In general, radar interference will not cause the radar to stop functioning. There is a built-in interference mitigation algorithm that suppresses false detections due to interference.

  • Page 7: Basic Settings

    AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device Configure your device Basic settings Adjust the image This section includes instructions about configuring your device. If you want to learn more about how certain features work, go to Learn more on page 55.
  • Page 8 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device Benefit from IR light in low-light conditions by using night mode Your camera uses visible light to deliver color images during the day. But as the visible light diminishes, color images become less bright and clear.
  • Page 9 4. If you still have problems, go to Exposure and adjust the Exposure zone to cover the area of interest. Find out more about WDR and how to use it at axis.com/web-articles/wdr. Stabilize a shaky image with electronic image stabilization (EIS) Electronic Image Stabilization (EIS) can be used in environments where the product is mounted in an exposed location and subject to vibrations, for example, wind or passing traffic.
  • Page 10 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device 1. Go to Video > Installation > Image correction. 2. Turn on Electronic image stabilization (EIS). Hide parts of the image with privacy masks You can create one or several privacy masks to hide parts of the image.
  • Page 11 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device 2. To start a recording, click If you haven’t set up any storage, click . For instructions on how to set up network storage, see Set up network storage on page 11 3.
  • Page 12 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device 3. Type the IP address of the host server. 4. Type the name of the shared location on the host server under Network share. 5. Type the username and password. 6. Select the SMB version or leave it on Auto.
  • Page 13 AXIS Radar Autotracking for PTZ, to use multiple PTZ cameras with multiple radars. Download AXIS Radar Autotracking for PTZ from axis.com, and follow the instructions in the application to install it on your VMS server (or another computer with access to both the camera and the radar).
  • Page 14 Control several PTZ cameras with one radar. Control one PTZ camera with several radars. Only one of the radars can be an AXIS Q1656-DLE. Control several PTZ cameras with several radars. The PTZ camera will track objects in the order they are placed in the control queue.
  • Page 15 Provide visual indication of an ongoing event You have the option to connect the AXIS I/O Indication LED to your network camera. This LED can be configured to turn on whenever certain events occur in the camera. For example, to let people know that video recording is in progress.
  • Page 16 8. Create a second rule and select the same Condition as in the first rule. 9. In the list of actions, select Toggle I/O while the rule is active, and then select the port the AXIS I/O Indication LED is connected to.
  • Page 17 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device 7. Click Save. Note If you update the overlay text it will be automatically updated on all video streams dynamically. Record video when a PIR detector senses motion Required hardware • 3-wire cable (ground, power, I/O) •...
  • Page 18 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device 1. Set up the stream profile to include audio, see Add audio to your recording on page 19. Turn on audio detection: 1. Go to System > Detectors > Audio detection. 2. Adjust the sound level according to your needs.
  • Page 19 AXIS Q1656-DLE Radar-Video Fusion Camera Configure your device 7. Click Save. Audio Add audio to your recording 1. Go to Video > Stream > Audio and include audio. 2. If the device has more than one input source, select the correct one in Source.
  • Page 20 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface The device interface To reach the device interface, type the device’s IP address in a web browser. Note Support for the features and settings described in this section varies between devices. Show or hide the main menu.
  • Page 21 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Video Click to play the live video stream. Click to freeze the live video stream. Click to take a snapshot of the live video stream. The file is saved in the ‘Downloads’ folder on your computer. The image file name is [snapshot_YYYY_MM_DD_HH_MM_SS.jpg].
  • Page 22 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface • Refresh: Click to refresh the still image in the live view. Click to show the live view at full resolution. If the full resolution is larger than your screen size, use the smaller image to navigate in the image.
  • Page 23 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Scene profile : Select a scene profile that suits your surveillance scenario. A scene profile optimizes image settings, including color level, brightness, sharpness, contrast, and local contrast, for a specific environment or purpose.
  • Page 24 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Wide dynamic range WDR: Turn on to make both bright and dark areas of the image visible. Local contrast : Use the slider to adjust the contrast of the image. A higher value makes the contrast higher between dark and light areas.
  • Page 25 • Move the slider towards Dark to increase the threshold for the IR-cut filter. The camera changes to night mode later. IR light If your device doesn’t have built-in illumination, these controls are only available when you have connected a supporting Axis accessory.
  • Page 26 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface • Flicker-free 60 Hz : The camera adjusts the aperture and gain automatically, and uses the shutter speed 1/60 s. • Flicker-reduced : This is the same as flicker-free, but the camera might use shutter speeds faster than 1/100 s (50 Hz) and 1/120 s (60 Hz) for brighter scenes.
  • Page 27 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Lock aperture : Turn on to keep the aperture size set by the Aperture slider. Turn off to allow the camera to automatically adjust the aperture size. You can, for example, lock the aperture for scenes with permanent light conditions.
  • Page 28 Zipstream: A bitrate reduction technology, optimized for video surveillance, that reduces the average bitrate in an H.264 or H.265 stream in real time. Axis Zipstream applies a high bitrate in scenes where there are multiple regions of interest, for example in scenes with moving objects.
  • Page 29 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Lower limit : Enter a value to adjust the frame rate between minimal fps and the stream default fps based on scene motion. We recommend you to use lower limit in scenes with very little motion, where the fps could drop to 1 or lower.

  • Page 30: View Areas

    AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Appearance: Select the text color and background color, for example, white text on a black background (default). : Select the position of the overlay in the image. • Image: Select to show a static image superimposed over the video stream. You can use .bmp, .png, .jpeg, or .svg files.
  • Page 31 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Radar Settings General Radar transmission: Use this to turn off the radar module completely. Channel: If you have problems with multiple devices interfering with each other, select the same channel for up to four devices that are close to each other.

  • Page 32: Device Settings

    Locate device: Click to play a sound that helps you identify the speaker. For some products, a LED will flash on the device. Calibrate : Click to calibrate the speaker. Launch AXIS Audio Manager Edge: Click to launch the application. Device settings Input: Turn on or off audio input. Shows the type of input.

  • Page 33: Audio Clips

    AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Audio clips Add clip: Click to add a new audio clip. Click to play the audio clip. Click to stop playing the audio clip. The context menu contains: • Rename: Change the name of the audio clip.
  • Page 34 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Recordings Click to filter the recordings. From: Show recordings done after a certain point in time. To: Show recordings up until a certain point in time. Source : Show recordings based on source.
  • Page 35 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Click to stop the recording.
  • Page 36 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Click to show more information and options about the recording. Set export range: If you only want to export part of the recording, enter from when to when. Click to delete the recording.

  • Page 37: Date And Time

    • Activate license with a key: If the app requires a license, you need to activate it. Use this option if your device doesn’t have internet access. If you don’t have a license key, go to axis.com/applications. You need a license code and the Axis product serial number to generate a license key.
  • Page 38 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Network IPv4 Assign IPv4 automatically: Select to let the network router assign an IP address to the device automatically. We recommend automatic IP (DHCP) for most networks. IP address: Enter a unique IP address for the device. Static IP addresses can be assigned at random within isolated networks, provided that each address is unique.
  • Page 39 One-click cloud connection One-click cloud connection (O3C) together with an O3C service provides easy and secure internet access to live and recorded video from any location. For more information, see axis.com/end-to-end-solutions/hosted-services. Allow O3C: • One-click: The default setting. Press and hold the control button on the device to connect to an O3C service over the internet.
  • Page 40 Authentication failed: Sends a trap message when an authentication attempt fails. Note All Axis Video MIB traps are enabled when you turn on SNMP v1 and v2c traps. For more information, see AXIS OS Portal > SNMP. • v3: SNMP v3 is a more secure version, which provides encryption and secure passwords. To use SNMP v3, we recommend you to activate HTTPS, as the password is then sent through HTTPS.
  • Page 41 To install test firmware or other custom firmware from Axis on the device, you need a custom-signed firmware certificate. The certificate verifies that the firmware is approved by both the device owner and Axis. The firmware can only run on a specific device which is identified by its unique serial number and chip ID.
  • Page 42 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Users Add user: Click to add a new user. You can add up to 100 users. Username: Enter a unique username. New password: Enter a password for the user. Passwords must be 1 to 64 characters long. Only ASCII printable characters (code 32 to 126) are allowed in the password, for example letters, numbers, punctuation, and some symbols.
  • Page 43 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Add a condition: Click to add an additional condition. Action: Select an action from the list and enter its required information. For information about specific actions, see Get started with rules for events.
  • Page 44 RSA is the preferred method during negotiation, followed by ECDSA, ED25519, and DSA. Make sure to enter the right MD5 host key that is used by your SFTP server. While the Axis device supports both MD5 and SHA-256 hash keys, we recommend using SHA-256 due to stronger security over MD5. For more information on how to configure an SFTP server with an Axis device, go to the AXIS OS Portal.
  • Page 45 IoT integration and is used in a wide variety of industries to connect remote devices with a small code footprint and minimal network bandwidth. The MQTT client in Axis device firmware can simplify integration of data and events produced in the device to systems which are not video management systems (VMS).
  • Page 46 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Connect message Specifies if a message should be sent out when a connection is established. Send message: Turn on to send messages. Use default: Turn off to enter your own default message.
  • Page 47 DNS. Windows SMB/CIFS names are not supported. • Network share: Enter the name of the shared location on the host server. Several Axis devices can use the same network share, since each device gets its own folder.
  • Page 48 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Important Risk of data loss and corrupted recordings. Do not remove the SD card while the device is running. Unmount the SD card before you remove it. Unmount: Click to safely remove the SD card.
  • Page 49 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface • SIP port: The network port used for SIP communication. The signaling traffic through this port is non-encrypted. The default port number is 5060. Enter a different port number if required. • TLS port: The network port used for encrypted SIP communication. The signaling traffic through this port is encrypted with Transport Layer Security (TLS).

  • Page 50: Stream Profiles

    AXIS Q1656-DLE Radar-Video Fusion Camera The device interface • Name: Enter a descriptive name. This can, for example, be a first and last name, a role, or a location. The name is not unique. • User ID: Enter the unique extension or phone number assigned to the device.
  • Page 51 Delete user: Delete the user. You can’t delete the root user. By creating an ONVIF user, you automatically enable ONVIF communication. Use the username and password for all ONVIF communication with the device. For more information see the Axis Developer Community at axis.com. ONVIF media profiles An ONVIF media profile consists of a set of configurations that you can use to change media stream settings.

  • Page 52: Video Out

    AXIS Q1656-DLE Radar-Video Fusion Camera The device interface The camera tampering detector generates an alarm when the scene changes, for example because the lens is covered, sprayed or severely put out of focus, and the time in Trigger after has passed. The tampering detector only activates when the camera has not moved for at least 10 seconds.
  • Page 53 AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Supervised : Turn on to make it possible to detect and trigger actions if someone tampers with the connection to digital I/O devices. In addition to detecting if an input is open or closed, you can also detect if someone has tampered with it (that is, cut or shorted).

  • Page 54: Ssh Server

    AXIS Q1656-DLE Radar-Video Fusion Camera The device interface Plain config Plain config is for advanced users with experience of Axis device configuration. Most parameters can be set and edited from this page. SSH server Secure Shell (SSH): Turn on to allow a user to securely log on and perform shell and network services over the network.
  • Page 55 Capture modes What capture mode to choose depends on the requirements for the frame rate and resolution of the specific surveillance setup. For specifications about available capture modes, see the product’s datasheet at axis.com. Remote focus and zoom The remote focus and zoom functionality allows you to make focus and zoom adjustments to your camera from a computer. It is a convenient way to ensure that the scene’s focus, viewing angle and resolution are optimized without having to visit the camera’s...

  • Page 56: Streaming And Storage

    H.264 or MPEG-4 Part 10/AVC Note H.264 is a licensed technology. The Axis product includes one H.264 viewing client license. To install additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller. H.264 can, without compromising image quality, reduce the size of a digital video file by more than 80% compared to the Motion JPEG format and by as much as 50% compared to older MPEG formats.
  • Page 57 AXIS Q1656-DLE Radar-Video Fusion Camera Learn more Bitrate control Bitrate control helps you to manage the bandwidth consumption of your video stream. Variable bitrate (VBR) Variable bitrate allows the bandwidth consumption to vary depending on the level of activity in the scene. The more activity, the more bandwidth you need.
  • Page 58 Applications With applications you can get more out of your Axis device. AXIS Camera Application Platform (ACAP) is an open platform that makes it possible for third parties to develop analytics and other applications for Axis devices. Applications can be preinstalled on the device, available for download for free, or for a license fee.

  • Page 59: Tpm Module

    AXIS Object Analytics AXIS Object Analytics is an analytic application that comes preinstalled on the camera. It detects objects that move in the scene and classifies them as, for example, humans or vehicles. You can set up the application to send alarms for different types of objects. To find out more about how the application works, see the user manual.

  • Page 60: Product Overview

    AXIS Q1656-DLE Radar-Video Fusion Camera Specifications Specifications Product overview Weather shield Window Radar Light sensor IR illumination LED Optical unit Cable cover Intrusion alarm sensor Safety wire 10 Intrusion alarm magnet NOTICE TICE TICE Do not lift the product in the cable cover.

  • Page 61: Led Indicators

    AXIS Q1656-DLE Radar-Video Fusion Camera Specifications 11 I/O connector 12 RS485/422 connector 13 Power connector 14 Network connector (PoE) 15 microSD card slot 16 Audio out 17 Audio in 18 Status LED 19 Control button 20 Cable gasket M20 (2x)

  • Page 62: Sd Card Slot

    AXIS Q1656-DLE Radar-Video Fusion Camera Specifications SD card slot For SD card recommendations, see axis.com. microSD, microSDHC, and microSDXC Logos are trademarks of SD-3C LLC. microSD, microSDHC, microSDXC are trademarks or registered trademarks of SD-3C, LLC in the United States, other countries or both.

  • Page 63: Power Connector

    AXIS Q1656-DLE Radar-Video Fusion Camera Specifications 6-pin terminal block Function Notes Specifications DC ground 0 V DC DC output Can be used to power auxiliary equipment. 12 V DC Note: This pin can only be used as power out. Max load = 50 mA 3–6...
  • Page 64 AXIS Q1656-DLE Radar-Video Fusion Camera Specifications RS485/RS422 connector Two 2-pin terminal blocks for RS485/RS422 serial interface used to control auxiliary equipment such as pan-tilt devices. The serial port can be configured to support: • Two-wire RS485 half duplex • Four-wire RS485 full duplex •...

  • Page 65: Upgrade The Firmware

    Using firmware from the active track is recommended if you want to access the newest features, or if you use Axis end-to-end system offerings. The LTS tracks are recommended if you use third-party integrations, which are not continuously validated against the latest active track.

  • Page 66: Technical Issues, Clues, And Solutions

    Axis device. Check all cabling and reinstall the device. Possible IP address conflict The static IP address in the Axis device is used before the DHCP server sets a dynamic address. with another device on the...

  • Page 67: Performance Considerations

    • Make sure that the scene is well lit to maximize detection probability of video analytics • Set the sensitivity to Low in AXIS Object Analytics. This requires that video and radar analytics agree before triggering an alarm. • Use exclude areas in the radar to mask known sources of false detections, such as swaying vegetation, and buildings.
  • Page 68 User Manual Ver. M1.20 AXIS Q1656-DLE Radar-Video Fusion Camera Date: December 2022 © Axis Communications AB, 2022 Part No. T10180975...
