LeCroy WaveJet 300A Specification
Oscilloscopes
Hide thumbs
Also See for WaveJet 300A:
- Getting started manual (67 pages) ,
- Manual (60 pages) ,
- Quick reference manual (13 pages)
Advertisement
Quick Links
Portable Performance for Debug
and Validation
100 MHz – 500 MHz
Key Specifications
Bandwidth
100 MHz, 200 MHz, 350 MHz, 500 MHz
Channels
2 or 4
Memory
500 kpts/Ch
Sample Rate
Up to 2 GS/s
Display
7.5" VGA
Connectivity
USB Host, USB Device, GPIB, LAN
WaveJet 300A Oscilloscopes
•
Performance — 500 kpts/Ch and
up to 2 GS/s
•
Replay Mode — Isolate anomalies
and see how a waveform has
changed over time
•
Connectivity — Remote control via
USB, GPIB or LAN plus USB mass
storage and printing
•
Big Display, Small Footprint
— A large 7.5" display and a form
factor only 4" dee
p
For more information, please contact:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LeCroy WaveJet 300A
Summary of Contents for LeCroy WaveJet 300A
- Page 1 WaveJet 300A Oscilloscopes Portable Performance for Debug and Validation 100 MHz – 500 MHz • Performance — 500 kpts/Ch and up to 2 GS/s • Replay Mode — Isolate anomalies and see how a waveform has changed over time •...
-
Page 2: Ordering Information
Go back in time to isolate runts, glitches or other anomalies with Replay Mode. Turn any PC into a Mixed Signal Oscilloscope by connecting a Teledyne LeCroy WaveJet and LogicStudio for up to 4 analog and 16 digital channels. Ordering Information...
